Summary of Contents for Samsung AIRDRESSER DF24 9900 Series
- Page 1 Clothing Care System (AIRDRESSER) User manual DF24**9900**/DF18**8700**/DF18**8600** Untitled-1 1 Untitled-1 1 2024-10-08 2024-10-08 10:24:02 10:24:02...
-
Page 2: Table Of Contents
Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions General warnings Electrical warnings Installation warnings Cleaning warnings Instructions about the WEEE Before you start Installation Turning on Wi-Fi (for network models only) Product overview Control panel Cycle overview... - Page 3 Specifications Standby power consumption Specification sheet Contact information QUESTIONS OR COMMENTS? English 3 Untitled-1 3 Untitled-1 3 2024-10-08 2024-10-08 10:24:02 10:24:02...
-
Page 4: Safety Information
Safety information Congratulations on your new Samsung product. This manual contains important information on the installation, use and care of your product. Please take some time to read this manual to take full advantage of your product’s many benefits and features. -
Page 5: Important Safety Precautions
As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate this product, familiarise yourself with its operation and exercise care when using it. Important safety precautions To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. -
Page 6: General Warnings
Safety information CAUTION : In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility. 6. - Page 7 • Do not touch or disassemble the electrical outlet of the product. In the event of a gas leak, make sure to ventilate the location and immediately contact a Samsung service centre. • To avoid damaging the glass panel, make sure to protect the front at all times.
-
Page 8: Electrical Warnings
• Do not use a damaged power cord or power plug. Do not attempt to repair, disassemble, or modify the power cord or power plug. For any repairs, contact your nearest Samsung service centre. • Plug the power cord into a wall socket that meets local electrical specifications. Use the socket for this appliance only, and do not use an extension cord. -
Page 9: Installation Warnings
• Only install the product in a stable, well-floored location. Do not install the product in locations prone to vibrations or where the product may tip over, such as ships or airplanes. Contact a Samsung service centre if you are unsure of the installation location. -
Page 10: Instructions About The Weee
This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product regulatory obligations, e.g. REACH, WEEE or Batteries, visit our sustainability page available via www.samsung.com Product disposal in France REPRISE À... -
Page 11: Before You Start
Before you start Installation Install the product according to the instructions in this manual and local codes. WARNING • Do NOT use an extension cord. Use only the power cord that comes with the product. • Do NOT connect the ground wire to plastic plumbing, gas lines, or hot water pipes. Improperly connected grounding conductors may cause electric shock. - Page 12 AIRDRESSER to raise it from the carpet (A), and then insert the tray. 4. Plug in the product to a grounded outlet. If you do not have grounded outlets, contact a Samsung service centre for alternative methods to ground the product. NOTE •...
-
Page 13: Setting The Language
Securing AIRDRESSER with the anti-tip strap (optional) AIRDRESSER may tip-over by external force or children. If necessary, use the anti-tip strap to secure AIRDRESSER and prevent tip-over. (Refer to the figure.) CAUTION You must unplug the product before securing AIRDRESSER with the anti-tip strap. NOTE •... -
Page 14: Product Overview
Before you start Product overview 3-item capacity 01 Air hole 02 Dust filter 03 Fresh Finish 04 Lint filter 05 Drain tank 06 Refill tank 07 Water tray English Untitled-1 14 Untitled-1 14 2024-10-08 2024-10-08 10:24:06 10:24:06... - Page 15 5-item capacity 01 Extra-length zone 02 Multi Hanger 03 Water tray 04 Air hole 05 Dust filter 06 Fresh Finish 07 Lint filter 08 Drain tank 09 Refill tank English 15 Untitled-1 15 Untitled-1 15 2024-10-08 2024-10-08 10:24:06 10:24:06...
- Page 16 Before you start Accessories Multi Hanger (Applicable Water tray Air hanger models only) Anti-tip strap Screw (for anti-tip strap) Screw anchor (for anti-tip strap) Rear levelling feet English Untitled-1 16 Untitled-1 16 2024-10-08 2024-10-08 10:24:07 10:24:07...
-
Page 17: Control Panel
Control panel • Tap to turn the power on or off. • If the product is operating, you must tap to pause the operation before turning the power off. 01 Power • If no buttons are pressed for 10 minutes after powering on, the product will automatically turn off. -
Page 18: Cycle Overview
Before you start • Tap to turn Smart Control on or off. • If the AIRDRESSER is connected to a wireless router without activating the Smart Control function, you can only monitor the current status or set the 08 Smart Control desired cycle. - Page 19 Cycle Description For refreshing blouses or summer dress (such as sleeveless dress, short sleeve Blouses dress with thin fabric). Outdoor For outdoor or active wear. Eliminates moisture and dust from cashmere items. • Operating noise may be louder during this cycle. Fur/Leather •...
- Page 20 Before you start Delicate Drying cycles CAUTION Do not use any of the following items for Delicate Drying cycles. • Leather, fur, feather, velvet, silk. • Any items containing rubber or sponge. • Items made of wool blended fabrics, water-repellent fabrics, silk-blended, or hemp-blended fabric. •...
-
Page 21: Settings
Settings Using Settings 1. Tap 2. Tap to select the desired setting. For detailed information on each setting, refer to the ‘ Settings menu description’ section. 3. Follow the on-screen instructions to change the desired option. Settings menu description Options Description Use this function to keep items fresh and dry if you won't be able to remove them immediately after the cycle has finished. - Page 22 Before you start Options Description This function allows the AIRDRESSER to learn your usage habits and remember the cycles you use most frequently. NOTE AI Pattern • The default setting is On . Set it to Off if you do not want to use this function. •...
-
Page 23: Fabric Care Guide
Fabric care guide • Fabrics have different care management depending on how they were processed and finished. This fabric care guide does not cover all materials and therefore use it for just a reference. Make sure to check the care label on your clothing before using with AIRDRESSER to prevent any damage. •... - Page 24 Before you start Fabric care guide table Natural fibres - vegetable fibres Cycles Clothing Care Fabric Clothes / Remarks Delicate Drying Reducing Deodorising wrinkles Towels, socks, underwear, jeans, sportswear, t-shirts, blankets Cotton Wrinkles on 100 % cotton fabrics may remain. Iron after cycle if desired.
- Page 25 Artificial fibres Cycles Clothing Care Fabric Clothes / Remarks Delicate Drying Reducing Deodorising wrinkles Acetate Suit lining, blouses, neckties, pyjamas Thermal underwear, knitwear Acrylic Lay clothes on shelf. Stockings, lingerie ...
-
Page 26: Fabric Care Chart
Before you start Fabric care chart The following table contains some of the symbols that may help you choose appropriate items for AIRDRESSER. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow care label directions to maximize garment life and reduce laundering problems. NOTE * : Some clothing that does not recommend washing (such as fur or leather fabrics) can be used with AIRDRESSER. - Page 27 Drying Symbol Meaning Use with AIRDRESSER Tumble drying / Drying at a temperature of 80 °C with a normal drying process. Tumble drying / Drying at a temperature of 60 °C with a mild drying process. Do not tumble dry Line drying.
- Page 28 Before you start Ironing Symbol Meaning Use with AIRDRESSER Iron at maximum sole plate temperature of 200 °C. Iron at maximum sole plate temperature of 150 °C. Iron at maximum sole plate temperature of 110 °C. Caution when using steam irons (work without steam). Do not iron.
-
Page 29: Smart Control
• The reception sensitivity of a wireless network may be affected by surrounding wireless environments. • If your Internet provider has registered the MAC address of your PC or the modem module for permanent use, your Samsung AIRDRESSER may fail to connect to the Internet. If this is the case, contact your Internet provider •... - Page 30 Before you start Registering your appliance to SmartThings 1. Make sure your smartphone is connected to a wireless network. If not, go to Settings , turn on the wireless connection, and then select an AP (Access Point). 2. Open SmartThings on your smartphone. 3.
- Page 31 UK. The full text of the EU declaration of conformity and the UK declaration of conformity is available at the following internet address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support > Support Home and enter the model name.
-
Page 32: Product And Accessory Use
Product and accessory use Using a cycle 1. Make sure the Refill Tank (A) is filled with water. 2. Make sure the lint filter (B) is clean. 3. Input clothes as instructed in the Using the accessories section. 4. Tap 5. - Page 33 Usage guidelines Before use • This product cannot be used to clean items. For best results, wash and dry all items before using the product. • Before using the product, we recommend washing items with strong odours or items that have been stored for a long time.
-
Page 34: Using The Accessories
Product and accessory use Using the accessories Air hangers Hang an item on the Air hanger and securely place it into the air hole. • If the Air hanger is not properly secured in the air hole, it may cause vibration and noise. •... - Page 35 Multi Hanger (Applicable models only) You can use the Multi Hanger for clothing or accessories that cannot be hung on a regular hanger. Attach the Multi Hanger securely to the mount located on the left and right walls inside the product. NOTE •...
- Page 36 Product and accessory use Correct usage of the Multi Hanger Incorrect usage of the Multi Hanger CAUTION • Ensure that clothing or accessories do not touch the internal base of the product when using the Multi Hanger. • Do not drape clothing or accessories over the Multi Hanger. NOTE •...
-
Page 37: Refill Tank
Refill Tank NOTE • Before using the product, make sure there is water in the Refill Tank. • The product consumes more water the first time the product is used. • It is recommended to use filtered water. • If you are not going to use the product for a long time, empty the Refill Tank. •... - Page 38 Product and accessory use Drain Tank Before using the product or if you are not going to use the product for a long time, make sure to empty the Drain Tank. To empty the Drain Tank 1. Pull out the Drain Tank. 2.
- Page 39 2. Remove the used Fresh Finish™. 3. Insert the new Fresh Finish™ as shown in the figure. 4. Close the Fresh Finish™ compartment. NOTE • If you use the Fresh Finish™ or perfume, the scent may linger inside the AIRDRESSER. •...
-
Page 40: Cleaning And Maintenance
Cleaning and maintenance CAUTION • Unplug the product before cleaning it. • Do not use abrasive or flammable cleaners. • Do not spray water directly onto the product when cleaning it. Exterior Use a smooth cloth to clean the exterior. For stubborn stains, use a damp cloth and then wipe dry. -
Page 41: Water Tanks
Water tanks Clean both tanks on a regular basis. Completely dry before reinserting. Use a damp cloth to clean the exterior. Use a soft brush to clean the interior. Use a soft brush to clean the tanks’ inlet and outlet. English 41 Untitled-1 41 Untitled-1 41... -
Page 42: Water Tray
Cleaning and maintenance Water tray NOTE • Empty the water tray on a regular basis. • Make sure to reinsert the water tray after emptying the water. Correctly insert the water tray as shown in the figures. • Make sure the side with 'TOP' is facing up. English Untitled-1 42 Untitled-1 42... -
Page 43: Dust Filter
Dust filter • The Dust filter traps dust generated inside the product. • You must always keep the Dust filter clean to ensure optimal product performance. Be sure to clean the Dust filter before each use. CAUTION • Clean the filter immediately if it is heavily contaminated with dust or foreign substances (such as oil), as it may cause odors or reduce performance. -
Page 44: Lint Filter
Cleaning and maintenance 5. Press the Dust filter cover to close it. NOTE The design and specifications of the components may change without prior notice to improve the product. Lint filter • For best results, clean the lint filter before or after using the product. •... -
Page 45: Lamp (Light Source)
The lamp(s) and/or control gear(s) are not user-serviceable. To replace the lamp(s) and/or control gear(s) in the product, contact a local Samsung service centre. For detailed instructions on replacing lamp(s) or control gear(s) in your product, visit the Samsung website (http://www.samsung.com), go to Support >... -
Page 46: Descaling
Cleaning and maintenance Descaling Using the steam function causes limestone accumulation and deposition throughout the internal water circulation system due to calcium contents of water. To prevent this, perform descaling regularly to increase the performance and lengthen the lifespan of the product. If you do not perform descaling immediately after getting the notification message, some functions may be restricted for use and may cause performance decrease or even shortens the lifespan of the product. -
Page 47: Troubleshooting
Connect to Wi-Fi network or • Check if the router is off. check your router Turn the router on, and then connect to the Internet. NOTE If a problem persists, contact a local Samsung service centre. English 47 Untitled-1 47 Untitled-1 47 2024-10-08... -
Page 48: Checkpoint
• When opening the door, sounds may come from the Refill Tank when the water is flowing through the pipe. This is normal. • If noises become louder, contact a Samsung service centre. • After plugging in the product, wait for a moment and try again. The... - Page 49 Items are wet after a cycle. the door. If the door gasket is damaged, unplug the power cord and contact a Samsung service centre. • Wash items with strong odours or items that have been stored for a long time.
-
Page 50: Standby Power Consumption
Specifications Standby power consumption Off mode 0.50 W Network standby mode 2.00 W Power consumption Time in networked standby 10 min mode (WI-FI) Specification sheet “*” Asterisk(s) means variant model and can be varied (0-9) or (A-Z). Clothing Care System (AIRDRESSER) Type DF18**8700** / DF24**9900**... -
Page 51: Contact Information
DENMARK 70 70 19 70 www.samsung.com/dk/support FINLAND 030-622 75 15 www.samsung.com/fi/support SWEDEN 0771-400 300 www.samsung.com/se/support AUSTRIA 0800 72 67 864 (0800-SAMSUNG) www.samsung.com/at/support www.samsung.com/ch/support (German) SWITZERLAND 0800 726 786 www.samsung.com/ch_fr/support (French) HUNGARY 0680SAMSUNG (0680-726-7864) www.samsung.com/hu/support CZECH 800 - SAMSUNG (800-726786) www.samsung.com/cz/support... - Page 52 Luni - Vineri: 9 AM - 6 PM ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support 8009 4000 only from landline, toll CYPRUS free www.samsung.com/gr/support 80111-SAMSUNG (80111 726 7864) from mobile and land line GREECE (+30) 210 6897691 from mobile and land line 801-172-678* POLAND http://www.samsung.com/pl/support/ * (opłata według taryfy operatora)
- Page 53 Memo Untitled-1 53 Untitled-1 53 2024-10-08 2024-10-08 10:24:22 10:24:22...
- Page 54 Memo Untitled-1 54 Untitled-1 54 2024-10-08 2024-10-08 10:24:22 10:24:22...
- Page 55 Memo Untitled-1 55 Untitled-1 55 2024-10-08 2024-10-08 10:24:22 10:24:22...
- Page 56 Untitled-1 56 Untitled-1 56 2024-10-08 2024-10-08 10:24:22 10:24:22...
