MOMENTO FULL AUTO COFFEE MAKER
MODEL NO. 47815
Thank you for choosing this Morphy Richards product and
for placing your trust in our brand. This super-automatic
coffee-maker has a maximum performance pressure pump
(18 Bar) to offer you the best professional espresso coffee in
the comfort of your home. With the touchscreen technology,
you can easily select the espresso you prefer by pressing
directly on the digital screen. This high-tech coffee-maker
displays the selection you have made with the appropriate
graphic on the screen. Its menu is highly intuitive and easy
to use so that you can adapt the machine to your personal
preferences without any great complications.
We recommend you read this instruction book carefully to
discover all the options the Momento has to offer. We hope
you enjoy this coffee maker and the delicious coffee it
makes. Keep this instruction book in a safe place, so that you
can refer to this whenever you need to.
Please note: cups not included with this product
IMPORTANT SAFETY INSTRUCTIONS
The use of any electrical appliance requires the following
common sense safety rules. Primarily there is danger of
injury or death and secondly the danger of damage to the
appliance. These are indicated in the text by the following
two conventions:
WARNING:
Danger to the person!
IMPORTANT: Damage to the appliance!
In addition we offer the following safety advice.
LOCATION
• Remove all the packaging and retain for future reference.
• Ensure the coffee maker is used on a firm, flat surface.
• Do not use the coffee maker outdoors or in a bathroom.
• Do not place the coffee maker on a highly polished wooden
surface as damage may occur to the surface.
• Do not place the coffee maker on or near hot surfaces such
as a hot plate or radiant rings or near a naked flame.
WARNING:
•
Do not place the coffee maker onto a metal tray
or metal surface whilst in use.
• Do not lift the coffee maker by gripping the water reservoir.
Hold the body of the coffee maker.
1
Advertisement
Table of Contents
Related Manuals for Morphy Richards MOMENTO 47815
Summary of Contents for Morphy Richards MOMENTO 47815
-
Page 1: Important Safety Instructions
MOMENTO FULL AUTO COFFEE MAKER MODEL NO. 47815 IMPORTANT SAFETY INSTRUCTIONS Thank you for choosing this Morphy Richards product and for placing your trust in our brand. This super-automatic The use of any electrical appliance requires the following coffee-maker has a maximum performance pressure pump common sense safety rules. -
Page 2: Electrical Requirements
• The use of attachments or tools not recommended or sold by Morphy Richards may cause fire, electric shock or injury. ELECTRICAL REQUIREMENTS • Do not use abrasive cleaners on the outside of the coffee maker, they may scratch the surface. - Page 3 1 IMPORTANT 2 PRECAUTION • Do not leave the cable hanging over the edge of the table • Remove all the used elements to protect the product or in contact with hot surfaces. during transport, as well as all material used for promotions, •...
-
Page 4: Safety Standards
4 SAFETY STANDARDS • The mains plug must not be damaged, hanging or placed on hard surfaces. In the event of an emergency • Do not use the power cable to move the coffee-maker by pulling on it under any circumstances. Unplug the coffee-maker immediately. - Page 5 5 PARTS...
- Page 6 Coffee bean tank cover Grind level adjustment Coffee bean compartment Ground coffee tank/ sugar cube compartment Water tank cover Cup-warmer Water tank Standby switch Steam regulator Information screen Touchscreen Steam nozzle H e i g ht- a djus t a b l e coffee outlet Tray water level Handles...
- Page 7 6 ACCESSORIES 7 BREWING UNIT, THE HEART OF THE COFFEE-MAKER For your convenience, all the accessories are in a box with the instructions handbook: This coffee-maker has a professional 1. Ground coffee dispensing spoon. Capacity 8 g, approx. unit manufactured and developed by the best manufacturer of professional 2.
-
Page 8: Installation
9 INSTALLATION 6. The first time you use the coffee-maker, its internal circuits need to be filled with water. The steam jet/hot If you find coffee grounds, it is because the coffee-maker has water regulator icon appears on the LCD screen to been tested to make sure it works perfectly. -
Page 9: Chapter 18 Programming Your Coffee-Maker
15. The coffee-maker will indicate when it is Important! If you grind the coffee too finely (grinding level ready with a beep and a hand will be regulator full to the left), the coffee will brew very slowly. displayed on the screen. N.B. - Page 10 B) Adjusting the amount of coffee Espresso Large Before dispensing the coffee, choose the amount of coffee coffee coffee you want to make, depending on whether you want a strong or weak coffee. 1 coffee cup If you want a weak coffee, press the button: 2 coffee cups If you want a strong coffee, press the selector: 12 OBTAINING THE COFFEE...
- Page 11 5. Next, the coffee-maker performs a preliminary infusion of 2. Use the dispensing spoon to calculate the amount of the ground coffee. The coffee is injected with hot water, ground coffee. IMPORTANT! The maximum amount is which is distributed evenly around the coffee. The one flat spoonful of coffee (8 g).
-
Page 12: Hot Water
13 HOT WATER 14 STEAM 1. Check that the coffee-maker is ready. 1. Check that the coffee-maker is ready. 2. Place the glass or cup under the steam 2. Place a glass or jug under the steam nozzle. nozzle. 3. Press the ‘steam’ button. The frame around the steam 3. - Page 13 7. Press the ‘steam’ or ESCAPE button to turn off the steam. 5. Open the steam nozzle, turning the steam regulator. The frame surrounding the steam will disappear. 8. The coffee-maker automatically stabilises the temperature inside the system. This automatic process takes approximately 25 seconds, during which water is expelled through the coffee outlet.
-
Page 14: Lime Scale Removal
10. The coffee-maker is ready to make coffee. 1. The coffee-maker will indicate when the lime scale needs to be removed from the circuits by displaying the following symbols on the screen: 11. Place the cup with the frothy milk under the coffee outlet. -
Page 15: Cleaning And Maintenance
a) To confirm the lime scale removal process, press the ‘P’ 12. Once the lime scale removal process has finished, the button. system must be rinsed to make sure that all remains of the removal agent are removed. To rinse the appliance, press b) To exit the process, press the ‘ESC’... -
Page 16: Brewing Unit
4. Remove the drip tray and empty it. Wash it with water. 2. Remove the grounds compartment. 5. Remove the grounds compartment (used coffee) and empty it. Wash it with water. 6. Unscrew the steam nozzle together with the outlet and clean all the parts. If it is blocked, clean the air inlet hole of the steam nozzle with a needle to opti- mise the steam function. - Page 17 6. Remove the unit. 10. Move the unit lever to the right. 7. Wash the unit under the tap with plenty of hot water. 11. Screw the unit back on at the top. 8. Wait until the unit is completely dry. 12.
- Page 18 14. Close the side cover. does not contain any traces of water left in the pipes from coffee made previously. 2) Before turning off and to prevent the coffee outlet from being blocked with coffee remains, the coffee-maker expels a little water and cleans the coffee outlet. This function has been designed to save you from having to carry out this cleaning process manually.
- Page 19 The following is a detailed explanation of how to use the programming menu: A) ADJUSTING THE AMOUNT OF WATER FOR AN ESPRESSO COFFEE Sequence Press the button Message on screen 1. The coffee-maker is ready. 2. Press the ‘P’ button to enter the programming menu. 3.
- Page 20 B) ADJUSTING THE AMOUNT OF WATER FOR 1 LARGE COFFEE Sequence Press the button Message on screen 1. The coffee-maker is ready. 2. Press the ‘P’ button to enter the programming menu. 3. The first programme is for adjusting the amount of water per cup. You can programme the amount for each type of coffee you can obtain.
- Page 21 C) ADJUSTING THE AMOUNT OF WATER FOR 2 ESPRESSOS Sequence Press the button Message on screen 1. The coffee-maker is ready. 2. Press the ‘P’ button to enter the programming menu. 3. The first programme is for adjusting the amount of water per cup. You can programme the amount for each type of coffee you can obtain.
- Page 22 D) ADJUSTING THE AMOUNT OF WATER FOR 2 LARGE COFFEES Sequence Press the button Message on screen 1. The coffee-maker is ready. 2. Press the ‘P’ button to enter the programming menu. 3. The first programme is for adjusting the amount of water per cup. You can programme the amount for each type of coffee you can obtain.
-
Page 23: Energy Saving
E) ENERGY SAVING Sequence Press the button Message on screen 1. The coffee-maker is ready. 2. Press the ‘P’ button to enter the programming menu. 3. Press the ‘>’ button until the ‘auto-off’ symbol appears on the screen. 4. To programme this function, press ‘P’. 5. -
Page 24: Water Hardness
F) WATER HARDNESS The hardness of the tap water varies with each region and you should test the hardness of the water you are going to use in your coffee-maker. Once the coffee-maker has been programmed with the hardness of the water, it will indicate when the lime scale should be removed from the system. - Page 25 G) DIGITAL SCREEN CONTRAST Sequence Press the button Message on screen 1. The coffee-maker is ready. 2. Press the ‘P’ button to enter the menu. 3. Press the ‘>’ icon until the ‘contrast’ icon is displayed. 4. To programme the screen contrast, press ‘P’. 5.
- Page 26 H) BEEPS Sequence Press the button Message on screen 1. The coffee-maker is ready. 2. Press the ‘P’ button to enter the programming menu. 3. Press the ‘>’ icon until the ‘beep’ icon is displayed. 4. To enter the beeps programme, press ‘P’. 5.
- Page 27 19 MESSAGES Function Icon on display Comment Fill the system The coffee-maker needs to fill its internal circuits with water. Before with water. transporting the coffee-maker, the circuits are emptied to prevent the forming of bacteria and must then be refilled. To fill the system, use the steam regulator.
- Page 28 Function Icon on display Comment Lime scale removal. SELECT COFFEE/LIME SCALE REMOVAL. The coffee-maker will con- tinue to make coffee but indicate that the lime scale needs to be removed from the machine. Cleaning the tray EMPTY THE DRIP TRAY AND FILL THE WATER TANK WITH CLEAN at the end of WATER.
-
Page 29: Troubleshooting
20 TROUBLESHOOTING PROBLEM CAUSE SOLUTION The coffee-maker does not come on. The coffee-maker is not connected to Press the switch, position ‘I’ (on). the mains. Check the cable and the plug. If it still does not come on, take the cof- fee-maker to an authorised technical service centre. - Page 30 PROBLEM CAUSE SOLUTION Part of the ground coffee may have Use the brush included with the acces- been left in the inlet. sories to make the coffee drop or use the back of the dispensing spoon. No steam or hot water is obtained. The steam nozzle is blocked.
- Page 31 All Morphy Richards products are individually tested before leaving the factory. In the unlikely event of any appliance 5 Morphy Richards are not liable to carry out any type of proving to be faulty within 28 days of purchase it should be servicing work, under the guarantee.
- Page 32 Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice in your country. The After Sales Division Morphy Richards Ltd Mexborough, South Yorkshire, England, S64 8AJ Consumer helpline (office hours): 0870 060 2607 Website: www.morphyrichards.com...
