Summary of Contents for iBasso Audio DX340
- Page 1 Audio USER GUIDE...
-
Page 2: Table Of Contents
Contents Package Components Main Features Specifications Names of Parts & Functions 10-14 Android Basic Features Introduction 15-27 16-17 WiFi Connection/Bluetooth Connection Application (APP) Installation/App， to Uninstall/USB Connections 18-21 System Settings 22-26 Power Off/Reboot/System Switching iBasso Mango Music Player Application 28-62 Playback Screen (home screen) Music Screen 29-43... -
Page 3: Package Components
Package Components DX340 Player Leather Case Coaxial Cable Balanced Burn-in Cable USB-C cable 12V AC Adapter... -
Page 4: Leather Case
Quick Start Guide Screen Protector Warranty Card Leather Case： Use the leather case to protect the DX340 chassis from scratches. Coaxial Cable： Connect the coaxial cable to an external DAC, to allow the DX340 to work as a digital transport. -
Page 5: Screen Protector
Balanced Burn-in Cable： Plug the burn-in cable into the output socket and keep playing music to burn-in the DX340. The burn-in process helps the DX340's sound reach its full potential by forming the capacitors and stabilizing the electronic components used. - Page 6 It is also not mandatory to use the burn-in cable, we supply it as a convenience for when you are not listening to the DX340 and you would like to get your dap conditioned as soon as possible.
-
Page 7: Main Features
Main Features - In-house developed discrete DAC, consisting of 16 sets of cascaded 8E PWM-DACs. - Support of PCM up to 32bit/768kHz. - Support of Native DSD up to 512x. - 6.0″ I080P AMOLED (1080*2160), with In-Cell capacitive touch panel. - Support of QC3.0 and PD3.0 quick charge. - Page 8 - Support of SDXC and SDHC Micro SD cards. - Support of USB3.1 Superspeed transfer. - 4 settings for hardware gain control. - 100 steps for volume control. - Patented replaceable AMP card design. - Audio Formats Supported: APE, FLAC, WAV, WMA, AAC, ALAC, AIFF, OGG, MP3, DFF, DSF, and DXD.
-
Page 9: Specifications
Specifications 4.4mm Balanced Phone Port： Maximum output level： 8.3Vrms (12V DC-IN) 6.23Vrms (Battery) Output Power： 2150mW + 2150mW @32ohm，THD＜1% (12V DC-IN) 1200mW + 1200mW @32ohm，THD＜1% (Battery) Frequency Response： 10Hz-22kHz -0.7dB 10Hz-40KHz -2.2dB S/N： 123dB Dynamic Range： 123dB THD+N： -119dB (A-wt, 600ohm load) -117dB (A-wt, 300ohm load) -106dB (A-wt, 32ohm load) Crosstalk：... - Page 10 4.4mm Balanced Line Out： Maximum output level： 2Vrms Frequency Response： 10Hz-22kHz -0.7dB 10Hz-40KHz -2.2dB S/N： 123dB Dynamic Range： 123dB THD+N： -119dB Crosstalk： -145dB 3.5mm Single Ended Line Out： 1Vrms Maximum output level： 10Hz-22kHz -0.7dB Frequency Response： 10Hz-40KHz -2.2dB 118dB S/N： 118dB Dynamic Range：...
-
Page 11: Names Of Parts & Functions
12V DC-IN Coaxial Output Port: Use the coaxial cable to play music stored in the DX340 on an external device with a coaxial input port. Mini coaxial output has the highest output priority which would close the phone out or line out when coaxial cable plugged in. - Page 12 USB-C Port Connect the DX340 to a computer or a USB charger to charge the DX340. Connect the DX340 to a computer to allow the DX340 to work as a card reader or an external storage. Connect the DX340 to an OTG storage device to play music files stored in this OTG storage device.
- Page 13 Micro SD Card Slot Insert a Micro SD card into the DX340 to access its stored files. 6.0inch AMOLED USB-C Micro SD Coaxial Output Port Power/Volume Next/Fast Forward Play/Pause Previous/Rewind...
- Page 14 Power： Short Press - Power the LCD screen on and off. Long Press - To display the pop up window with three options that are Power off, Reboot, and To Mango. Volume： Rotate the wheel clockwise to increase the volume. Rotate the wheel counter clockwise to decrease the volume.
-
Page 15: Basic Operation
Power on/off: 1. Press and hold the power button to power on. 2. After the DX340 is powered on, a long press of the Power button to display the pop up window, press Power Off button to power off the DX340. -
Page 16: Android Basic Features Introduction
Android Basic Features Introduction WiFi Harmonic Battery indicator Volume Time... -
Page 17: Wifi Connection/Bluetooth Connection
WiFi Connection: ① On the Android desktop, from the top, swipe down the screen to display the notification bar. ② Press the Wireless local area network(WLAN) to turn on the WiFi function. The first time you enter the WLAN, you need to choose the hot spot you will be using and enter the password. -
Page 18: Bluetooth Connection
The DX340 will automatically search for the nearby Bluetooth device. At the same time, the DX340 will be visible to the nearby devices. Choose the device that you would like to pair with. After the device has been paired, you can use the... -
Page 19: App Installation
APP Installation: Method 1: ① Google Play and Aptoide are pre-installed on the DX340. ② Launch one of them. ③ Search for the APP that you would like to install. ④ Download the APP and install it. Method 2: ① Press the internet browser on the desktop. - Page 20 App, to Uninstall: ① Press the Settings icon on the desktop and scroll down and press APPs. ② Press the APP that you would like to uninstall. ③ Press uninstall to delete the APP.
-
Page 21: Usb Connections
USB Connections: Connect the DX340 to the computer using the furnished USB-C cable. The DX340 will show on the computer as an external storage. Users can transfer files by copying and pasting. *If you are using a Mac computer, please make sure the... - Page 22 DX340. USB Soundcard: The DX340 can work as a USB DAC for Windows PC, Mac computer, and Linux computer. It is driver free on Mac computer and Linux computer. With Mac computers, the DX340 Supports PCM up to 32bit/384kHz and DoP DSD up to 128x.
-
Page 23: System Settings
System Settings: Press Settings icon on the DX340 desktop to go into system settings. -
Page 24: Audio Settings
AC adapter is plugged. The output power will be greatly increased with this option ON. ⑧ Car Mode: When this option is enabled, the DX340 will power on upon connection to a USB power source. Upon booting into the OS, the audio playback will be automatically started. -
Page 25: Firmware Update
DX340 DX340 DX340 Online Update: ① Make sure the DX340 is connected to WiFi. ② After online update is selected, press Check Update. ③ Press Download, the DX340 will start downloading the available update package. ④ After the download is complete, press Update Now to... - Page 26 DX340 DX340 Local Update: ① Download the firmware file from our website. If it is a rar file, extract it. ② Press the icon located on the top right corner, then press Local Update. ③ Browse the folder where the firmware file is saved, and select the firmware file.
-
Page 27: Firmware Version
Firmware Version: ① Press Settings icon, System, About DX340. ② Scroll down the page, the Build number is the firmware version. -
Page 28: Power Off/Reboot/System Switching
Power Off, Reboot, And System Switching: ① Long press the power button for 3 seconds. ② There is a pop up window with three options. ③ When To Mango is selected, system will be switched to Mango OS. -
Page 29: Ibasso Mango Music Player Application
Mango Music Player Application iBasso Audio Mango music player is composed of the Playback screen (home screen), Music screen and Settings. When on the playback screen, one can swipe left and right on the Album artwork area ③ to switch a song: Press the icon on the top left corner ①... - Page 30 Playback Screen (home screen): Sample Rate Equalizer WiFi Harmonic L/R Balance Battery indicator Volume Settings Music screen Now Playing Track title Artist name Play Mode Music info Next/Fast Forward Previous/Rewind Play/Pause...
-
Page 31: Now Playing Screen
Now Playing Screen: Press the icon located on the bottom right to display the now playing screen. One can swipe a song to the left to display the Delete button. Press the delete button to remove it from this now playing list. ①... -
Page 32: Music Screen
Music Screen: ② ③ ① Press the Music Screen icon ① will go into the Music Screen②. Swipe from left to right on the Music Screen will bring up the Navigation Menu③. - Page 33 Song sorting② Return to navigation menu① Music order Swipe to trigger Now playing the Navigation ④ Long press Menu③ Track title Music format /Artist name Quickly position the current playing music file⑤ Playback bar ⑥ Thumbnail artwork Play/Pause Track title and artist name of the song that is playing Return: Press the Return button①...
- Page 34 Swipe to trigger the Navigation Menu： Swipe from left to right to bring up the navigation menu. Long Press: Long pressing a song will pop up a window with more options. Quickly position the current playing music file: On the All Music screen, press the Position icon to quickly position the current playing music file.
- Page 35 Sorting: Click the Sorting icon to pop-up the sorting options. You can select "Title/Album/Artist/Time/Folder" to sort the All Music.
-
Page 36: Navigation Menu
Navigation Menu： Swipe from left to right to bring up the Navigation Menu. One can choose among All Music, Album, Artist, Genre, Now Playing, Playlist, Internal Storage, and SD card. Also, the search bar is located at the bottom of the Navigation Menu. - Page 37 Long Press Pop-up: Further Options: Long Press of a song will pop up a window with further options that allows to play this song, add this song to a playlist, or delete this song.
-
Page 38: Album View
Album View: Thumbnail view Artwork view Artist View: Thumbnail view Artwork view... - Page 39 Playlist View:...
- Page 40 New Playlist: Press the New Playlist to create a playlist. On the pop-up window, one can name the playlist and add playlist description. Further Options: A Long press of the playlist will popup a window with further options, which allows renaming the playlist, exporting the playlist, or deletion of the playlist.
- Page 41 Recent Play: 50 recently played tracks are listed.
- Page 42 File： Press Internal Storage or SD Card on the Navigation Menu to go into Directory view. One can browse the music files under internal storage and SD card via folder structure. ①...
- Page 43 ① Press the return button① will move back one page at a time.
-
Page 44: Search Screen
Search Screen: Input the keywords to search a track, an album, or an artist. -
Page 45: Settings Screen
Settings Screen: Press the Settings icon to go into settings screen. Gapless: One can enable the gapless to eliminate the gap between two tracks. DC-IN Super Gain: This option is available after the 12V AC adapter is plugged. The output power will be greatly increased with this option ON. - Page 46 After a full media scan, or rescan the library, you can go to Directory and select a song under a folder. After this folder is played, the DX340 will play the next folder. L/R Balance: Press to go into the L/R balance setting page.
- Page 47 Equalizer: The DX340 has two types of Equalizers, Graphic EQ and Parametric...
-
Page 48: Graphic Equalizer
Graphic Equalizer: Press the button of the Graphic Equalizer to enable the Graphic Equalizer. Pre-set EQ: There are 5 kinds of pre-set EQ and a custom option. One can quickly set the equalizer as desired by selecting them. How to Adjust The EQ Settings: Press on the response curve, the 10 band slide bars will show up. -
Page 49: Parametric Equalizer
Parametric Equalizer: Press the button of the Parametric Equalizer to enable it. Parametric Equalizer: Press the button of the Parametric Equalizer to enable it. How to Go Into The Parametric EQ Setting Screen: Press the response curve to go into the parametric EQ setting screen. - Page 50 Parametric Equalizer Setting Screen: ① ② ③ ④ ⑤ ⑥ ⑦ ① Settings on the Selection Bar: One can swipe left and right to select a setting.
- Page 51 ② Filter Navigation Bar: There are maximum of 6 filters allowed for each setting. One can swipe left and right to select a filter, then customize it. ③ Status: Status of each filter. One can turn on or turn off the selected filter.
- Page 52 Parametric Equalizer Setting Instruction: Central Frequency (Fc): The central frequency of each filter setting. Gain: The gain for the central frequency. Quality Factor: The range of effect of the filter. As shown on the pictures below, the larger value of the Q factor, the smaller the effect compared the central frequency.
- Page 53 2. High Pass Filter The frequency smaller than the central frequency will be affected. Gain setting is ineffective with high pass filter. 2 3 4 5 6 20 30 100 200 4 5 6 7 8 9 10 30 40 50 200 300 ③.
- Page 54 4. Band Filter There is not a large effect on the central frequency. The frequency beside the central frequency has similar effect. Gain setting is ineffective with band filter. 2 3 4 5 6 20 30 100 200 4 5 6 7 8 9 10 30 40 50 200 300 ⑥.
- Page 55 6. Notch Filter The central frequency has obvious reduction. The frequency beside the central frequency has similar effect. Gain setting is ineffective with notch filter. 2 3 4 5 6 20 30 100 200 4 5 6 7 8 9 10 30 40 50 ⑩.
- Page 56 8. Low Shelf Filter There is a wide effect on the frequency that is lower than the central frequency. 2 3 4 5 6 20 30 100 200 200 300 4 5 6 7 8 9 10 30 40 50 ⑭.
- Page 57 L/R Balance: Slide clockwise to decrease the volume in right channel. Slide in counterclockwise to decrease the volume in left channel.
-
Page 58: Media Scan
Media Scan:... - Page 59 USB DAC: The DX340 can work as a USB DAC for Windows PC, Mac computer, and Linux computer. It is driver free on Mac computer and Linux computer. With Mac computers, the DX340 Supports PCM up to 32bit/384kHz and DoP DSD up to 128x.
- Page 60 Bluetooth DAC: DX340 Bluetooth DAC. After turning on the Bluetooth DAC, Bluetooth devices such as a mobile phone can be paired with the DX340. The DX340 can now stream from the connected Bluetooth device. Note: When in Bluetooth DAC mode, the DX340 supports...
-
Page 61: Display Settings
Display Settings: Ambient mode: Use album artwork as the background picture. Normal mode: Use the selected picture as the background picture. Playback screen album artwork, choose to display rectangular artwork or rounded artwork. Lock screen artwork: Display the album artwork on the lock screen. Year tag: Display year information of the ID3 on the playback screen. -
Page 62: Sleep Timer
Sleep Timer: Set the count down sleep timer to power off the DX340. The left hand side is the value of hours. The right hand is the value of minutes. The DX340 will be powered off after the counter has completed. If there are any operations in the meanwhile, the DX340 will start the counter again after the last operation. -
Page 63: System Info
System Info: One can see the Mango music player APP version on this screen. Also, one can see the space available of the internal memory and micro SD card. -
Page 64: Mango Os
Mango OS To reboot to Mango OS from Android, first of all, long press the power button for 3 seconds to pop up a window with three options. When “To Mango” is selected, the system will switch to the Mango OS. -
Page 65: Mango Os User Interface
The Mango OS User interface is composed of three parts: Music playback screen (homepage), my music, and settings. On the Music playback screen, press the icon① to go to My Music, press the icon② to go to Settings. ① ② * The Mango OS operation is similar to the iBasso Mango APP, please refer to the iBasso Mango APP instruction for any questions. -
Page 66: To Return To The Android System
To return to the Android System, go into the settings menu, press “Android System”, then press “Yes”. -
Page 67: Mtp
MTP (File Transfer) After MTP is turned on, the DX340 can be connected to a computer for file transfer.
