- Page 1 Non-contact Forehead Infrared Thermometer User Manual Manual Ver.: V1.0 Issuing Date: 2022/09/28...
- Page 2 Introduction Thank you for purchasing this Non-contact forehead Infrared Thermometer. It has been carefully developed for accurate, safe and fast temperature measurements in the forehead. Please read these instructions carefully before using this product and keep the instructions and the thermometer in a safe place. Package Contents Name Quantity...
-
Page 3: Table Of Contents
Contents 1. WARNINGS AND PRECAUTIONS..................1 2. Product Description......................2 1) Overview..........................2 2) Structure..........................2 3) Operating principle......................2 4) Indications for use......................2 3. Features..........................3 4. Product Structure.......................3 5. Display description......................3 6. How to use your thermometer....................4 1) Take your forehead temperature..................4 2) Take room/object temperature...................4 3) After a measurement......................4 4) Read your temperature.....................5 5) Switching between mute and un-mute................5... -
Page 4: Warnings And Precautions
1. WARNINGS AND PRECAUTIONS 1) Keep out of reach of children under 12 years. 2) Never immerse the thermometer into water or other liquids (not waterproof). For cleaning and disinfecting please follow the instructions in the “Care and cleaning” section. 3) Never use the thermometer for purposes other than those it has been intended for. -
Page 5: Product Description
2. Product Description 1) Overview Infrared Thermometer measures the body temperature based on the infrared energy emitted from the forehead. Users can quickly get measurement results after properly scanning the forehead. Normal body temperature is a range. The following tables show that this normal range also varies by site. -
Page 6: Features
3. Features • Non-Contact Design, Safe and more hygienic to use. • Quick measurement, less than 1 second • Accurate and reliable • Easy operation, one button design • Multi-functional, can measure forehead, room, milk, water and object temperature. • 35 sets of memories, easy to recall •... -
Page 7: How To Use Your Thermometer
6. How to use your thermometer When using the thermometer for the first time, please load the batteries. 1) Hold the thermometer within 0-1.5 inches (0-3 cm) of the forehead and aim it at the center, start measuring 0-1.5 inches (0-3 cm) with a short press of “Measure”... -
Page 8: Read Your Temperature
4) Read your temperature To indicates a temperature reading. In forehead mode. 1. If 89.6°F≦T≦99.2°F(32°C≦T≦37.3°C), the green light will last for 3 seconds, with one long beep. 2. If 99.3°F≦T≦100.3°F(37.4°C≦T≦37.9°C), the orange light will last for 3 seconds, with 3 short beeps, and the value in LCD flickers, which is a warning that you may have a light fever. -
Page 9: Temperature Taking Tips
Disposal： For environmental reasons, do not dispose of the device in the household waste at the end of its useful life. Dispose of the unit at a suitable local collection or recycling point. Observe the local regulations for material disposal. Please dispose of the device in accordance with EC Directive –... -
Page 10: Care And Cleaning
8.Care and cleaning 1) Cleaning and user maintenance must not be performed by children unless supervised. 2) Cleaning the device use an alcohol swab or cotton swab moistened with 70% alcohol to clean the thermometer casing and the measuring probe. 3) After the alcohol has completely dried out, you can take a new measurement (minimum of 10 minutes). -
Page 11: Error And Troubleshooting
9. Error and Troubleshooting Symptom Possible Cause Description & Solution The battery level is too low. Replace with a new battery Failed to Polarities of the batteries are Ensure the batteries are in the right power on. reversed. position The thermometer is damaged Contact dealer The lens of the probe is dirty. -
Page 12: Specifications
10. Specifications： Product name Infrared thermometer Power supply DC1.5V×2 Forehead: 89.6°F–109.2°F (32.0°C–42.9°C) Measurement range Object: 32°F–212°F (0°C–100°C) Forehead mode ±0.4°F/±0.2°C Accuracy (Laboratory) Object mode ±1.8°F/±1.0°C Display resolution 0.1°F/0.1°C Measuring distance 0 -1.5 inches (0-3cm) Automatic shutdown 10s±1s Memory 35 groups of measured temperature. Battery 2*AAA, can be used for more than 3000 times Weight &... -
Page 13: Emc Information
Warning: Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the Infra-red Thermometer (FC-IR202), including cables specified by the manufacturer. Otherwise, degradation of the performance of this equipment could result. - Page 14 Table 1 Guidance and manufacturer’s declaration - electromagnetic emissions Emissions test Compliance RF emissions CISPR 11 Group 1 RF emissions CISPR 11 Class B Harmonic emissions IEC 61000-3-2 Voltage fluctuations/ flicker emissions IEC 61000-3-3 Table 2 Guidance and manufacturer’s declaration - electromagnetic Immunity Immunity Test IEC 60601-1-2 Test level Compliance level...
- Page 15 Table 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Radiated IMMUNI- Test Band Modulat- Modulat- Distance TY TEST Frequency Service IEC61000 (MHz) ion (W) LEVEL (MHz) -4-3 (V/m) (Test spe- Pulse TETRA cifications 380 –390 modulat- for ENCL- ion 18 Hz OSURE GMRS PORT...
-
Page 16: Warranty And After-Sale Service
13. Warranty and After-Sale Service The device is under warranty for 12 months from the date of purchase. The batteries, the packaging, and any damage caused by improper use are not covered by the warranty. Excluding the following user-caused failures: 1.Failure resulting from unauthorized disassembly and modification.
