PrimeLight Design VoxBox Air VB3-2001 Operating Instructions Manual

Hide thumbs Also See for VoxBox Air VB3-2001:
Table of Contents

Advertisement

Quick Links

Download this manual
Operating Instructions
MODEL: VB3-2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VoxBox Air VB3-2001 and is the answer not in the manual?

Questions and answers

Related Manuals for PrimeLight Design VoxBox Air VB3-2001

Summary of Contents for PrimeLight Design VoxBox Air VB3-2001

  • Page 1 Operating Instructions MODEL: VB3-2001...

  • Page 3: Table Of Contents

    Table of contents Chapter 1 Introduction and Caution .......................4 Chapter 2 Packing order and parts ......................5 Chapter 3 Assembling the main unit ......................6 Chapter 4 Collapsing the main unit ......................7 Chapter 5 Choose a mounting option ....................8 5.1. Mounting to existing 15mm rails ................9-11 5.2.

  • Page 4: Chapter 1 Introduction And Caution

    1. Introduction and Caution The VoxBox Air is a mirror box which is positioned in front of the camera lens. It allows film makers to shoot down-the-lens interviews while maintaining eye contact between the interviewer and the subject. The tablet holder accessory allows the unit to be converted into a Teleprompter.

  • Page 5: Chapter 2 Packing Order And Parts

    2. Packing order and parts 1 - Beamsplitter glass 2 - Foam pad 3 - Side mirror 4 - Foam pad 5 - Main unit - note the orientation of the L-bracket mounting slot (A)- it must be facing you when packing. 6 - 16mm adaptor 7 - L-bracket 8 - Tablet holder...

  • Page 6: Chapter 3 Assembling The Main Unit

    3. Assembling the main unit 1 - Place the main unit on a firm surface. 2 - Lift the top of the main unit to allow the bottom and side panels to unfold. 3 - Finally, align the panels and magnetic column to complete assembly.

  • Page 7: Chapter 4 Collapsing The Main Unit

    4. Collapsing the main unit 1 - Remove the L-bracket (if using). To do this, push both quick release buttons at the same time and pull the L-bracket to release. 2 - On a firm surface, push the front sides of the main unit to the position as shown.

  • Page 8: Chapter 5 Choose A Mounting Option

    5. Choose a mounting option There are two mounting options: OPTION 1: MOUNT TO EXISTING 15MM OPTION 2: MOUNT ON A LIGHT STAND RAILS Recommended for DSLR cameras or if Recommended for full-size cameras you do not have 15mm rails, or if your having existing 15mm rails and tripod is unable to support the weight medium/heavy duty tripod.

  • Page 9: Mounting To Existing 15Mm Rails

    5.1. Mounting to existing 15mm rails 1 - Attach the L-bracket ensuring that it clicks firmly into place. Note the orientation of the L-bracket as shown. 2 - Remove your matte box (if using) and ensure the 15mm rails do not extend beyond the front of the lens.
  • Page 10 5.1. Mounting to existing 15mm rails 4 - Slide the main unit onto the rails. The front of the lens should be in line with the hole in the main unit (or may be pushed through if a wider focal length is used).
  • Page 11 5.1. Mounting to existing 15mm rails If extra height is needed between the railblock and the lens, it is possible to invert the railblock. 1 - Loosen the height adjust knob enough to allow free movement of the railblock assembly. 2 - Rotate the railblock 180°...

  • Page 12: Mounting To A Light Stand

    5.2. Mounting to a light stand If your camera does not have 15mm rails, or if you are using a DSLR, the main unit can be mounted onto a standard light stand having a 16mm spigot. 1 - Attach the 16mm receiver into the 3/8ths inch thread on the main unit.

  • Page 13: Chapter 6 Inserting The Beamsplitter Glass

    6. Inserting the beamsplitter glass CAUTION: Handle the beamsplitter glass with extreme care; it will shatter on impact. Treat the surfaces like you would a lens. Handle only by the edges. 1 - Pull the glass retainer to release it (do not attempt to completely remove the glass retainer).

  • Page 14: Cleaning Advice

    6. Inserting the beamsplitter glass 4 - Firmly push the glass retainer to clamp the glass into place. There should be a positive click to confirm it is secure. ALWAYS CHECK THE GLASS IS SECURE AFTER FITTING. NOTE: the beamsplitter glass has special reflective coating on one side, indicated by the sticker.

  • Page 15: Chapter 7 Positioning The Interveiwer

    7. Positioning the interviewer The VoxBox Air allows the interviewer Fig 1 to sit at one of four possible positions, depending on the layout of the filming area or whether the interviewer is also operating the camera. The interviewer’s position is determined by the position of the L-bracket (or the 16mm receiver, if using) and the optional use of the side mirror.
  • Page 16 7. Positioning the interviewer 1 - The photo illustrates the point-of- view of the interviewer, viewing the subject through the mirror (in this case, the subject is demonstrated using a still photograph). The eyeline of the subject is incorrect. The main box can be rotated to adjust this.
  • Page 17 7. Positioning the interviewer Interviewing while operating the Fig 3 camera 1. Fit the L-bracket so the beamsplitter glass is positioned as shown in fig 3. 2. Attach the side mirror to the main unit using the thumbscrew. 3. Position the side mirror until you can see the subject through it;...
  • Page 18 7. Positioning the interviewer Fourth position for the interviewer Fig 4 1. Fit the L-bracket or 16mm receiver so the beamsplitter glass is positioned as shown in fig 4. 2. Attach the side mirror to the main unit using the thumbscrew. 3.

  • Page 19: Further Notes And Tips

    7.1. Positioning the interviewer Further notes and tips If the interviewer is not operating the camera, it is recommended that the VoxBox Air is used without the side mirror. This allows a much bigger viewing area for the subject and interviewer though the beamsplitter glass, and also allows the interviewer more distance away from the camera crew.

  • Page 20: Adjusting The Friction Hinge

    7.2. Positioning the interviewer Adjusting the friction hinge on the side mirror The amount of friction (or torque) on the hinge may need to be adjusted periodically. 1 - The lateral friction can be adjusted using a hex key. 2 - The tilt friction can be adjusted using a hex key.

  • Page 21: Chapter 8 Using Filters With The Voxbox Air

    8. Using filters with the VoxBox Air The integral filter tray system allows the use of standard 4X4” and 4X5.6” PV filters. 1 - Position the filter at a 45° angle. Firmly push in to engage the two spring retainers. 2 - Push downwards and slide filter into the tray.

  • Page 22: Chapter 9 Using The Voxbox Air As A Teleprompter Device

    9. Using the VoxBox Air as a Teleprompter device The VoxBox Air can quickly be converted into a Teleprompter or used to conduct remote interviews over video calling applications. NOTE: We do not provide apps with this product. 1 - Position your device in the tablet holder and clamp the device firmly.

  • Page 23: Chapter 10 Warranty

    10. Warranty Warranty provisions for this product are listed below • Guarantee this product for one year against defects in product and components, under normal installation and usage to the final customer who purchased from the manufacturer or reseller. • During the warranty period, repair the defects using new or renovated parts without any charge, or exchange the defective product with a new product or a product which has been manufactured by new or refurbished components...

  • Page 24: Chapter 11 Support And Parts

    Designed and manufactured in the UK by Design PrimeLight Design is a trading style of PrimeLight Films Ltd. Registered in England & Wales: 06036110. Ilkley, LS29 9JB, United Kingdom.  VoxBox Air is protected by:...
  • Page 25 Notes...
  • Page 26 Notes...
  • Page 27 Notes...
  • Page 28 Instruction manual version 1.1. Images and text © 2024 PrimeLight Design. Printed in the United Kingdom.
