- Page 1 INSTALLATION AND MAINTENANCE MANUAL FOR DIESEL ENGINE FIRE PUMP CONTROLLERS MODEL AFD...
- Page 2 The diesel engine fire pump controller includes two battery chargers to maintain the engine batteries continuously charged. Types of Diesel Engine Fire Pump Controllers FIRE PUMP CATALOG NUMBER MODEL No. EXAMPLE : AFD-12-220 Model Prefix AFD Battery Voltage 12:12V, 24:24V Incoming Voltage 220: 208/240V 50/60Hz Methods of Starting/Stopping The controllers are available as combination automatic / non-automatic with provision for manual shutdown only.
-
Page 3: Installation
The mounting feet provide the necessary 12 in. (305 mm) clearance for current carrying parts. Storage If the controller is not installed and energized immediately, Tornatech recommend following the instructions from the chapter 3 of the NEMA ICS 15 standard. Wiring and Connections Water Connections The controller must be connected to the pipe system according to AS 2941 –... - Page 4 Energy Consumption Diesel Controller with charger per battery Model / State Current VDC Output Float / Boost 12VDC Low charge (Float) 13.7V / 14.4V 12VDC Full charge (Boost) 24VDC Low charge (Float) 27.4V / 28.8V 24VDC Full charge (Boost) Sizing Wiring between controller and engine (terminals 11,13,14 on controller engine terminal) must be stranded #10 AWG or 6mm2 as minimum.
- Page 5 Quick Start-Up Guide The rating label is the most important label. It must be read carefully to ensure the compatibility between the controller and the installation. Verify that the controller is installed securely on the wall, or optionally on the mounting stand. Verify the Main Selector Switch is in the Left position labelled “CRANK ISOLATE.
- Page 6 Open the controller's door and verify that the disconnect switch and all circuit breakers are in the “OFF” position. Verify and/or install the proper water connections for the water input and the drain. They must be securely installed and tightened. Refer to the silkscreen markings on the plastic cover.
- Page 7 Connect all cables between the engine control panel and the controller engine terminals with the 16 pins quick connect connector. Connect the AC main line and ground to the AC terminal in the controller. Activate the disconnect switch (if present) and all breakers by setting them to the "on" position. The controller will boot up for the first time.
- Page 8 Once the controller has booted up, the “First Start Up” page appears. Press “User Login” and enter a valid authorization code. Once logged in, press “Power”. The “Power” page will automatically validate the power if no alarm is detected and if the power meets the requirements.
- Page 9 Press “Engine First Startup” and turn the Main Selector Switch to the “NORMAL” position. Note: Before starting the engine, verify that the engine has been officially commissioned (by an authorized engine representative or service dealer) and that the exhaust pipe is connected properly. You can choose to skip this step completely by selecting “Skip engine validation step”.
- Page 10 Press “Pressure”. - Verify that the pressure reading on the screen matches with the calibrated pressure gauge installed on the sensing line. - Choose the desired units of measurement for pressure reading. - Adjust, if required, the range of the digital pressure gauge at Max. Pres. - Insert the Cut-Out and Cut-In pressure values of the fire pump.
- Page 11 should be enabled with AHJ’s approval only. On this page we can also configure the Diesel Card connector J104 pin 012 for a ‘’Engergize to Stop solenoid’’ or a ‘’Energize to Start solenoid’’. Others parameter related to Energize to stop could be found in Control Timers menu. From the “Home”...
-
Page 12: Main Features
The “First Start up” is now completed. The controller is fully installed and configured. Main Features The ViZiTouch A: Power LED 3 colors: Green for power available and red for AC power fail.. B: Crank 1- START BATTERY button: Used to manually crank the starter from the Start battery while in "NORMAL" mode. - Page 13 Alarm Bell The alarm bell is activated under default faulty conditions stated by the AS 2941 – 2013 standard. Any of these conditions will energize the alarm bell but may be silenced, except in some cases, by pressing on the the “Silence bell”...
- Page 14 Home Home (Menu) Home The home page displays all controller statuses and important values of the controller. This includes all voltages, currents, pressure, engine state and status, as well as all timers and cranking sequences. A- Navigation bar: B- Name of the page. D- Battery chargers 1 (START) and 2 (CONTROL): The state of 1- Go to Home page...
- Page 15 E- Alternative current status: Red when there is a failure and green otherwise. F- Ammeter: Displays the actual current between the charger and the battery in amps. G- The battery: The battery will be red if it is in failure and green otherwise. The data shows the actual voltage of the battery and the charger in volts.
- Page 16 of the gauge. Just under of the digital pressure indicator, the actual pressure unit is shown. The maximum allowable pressure is also indicated on the gauge and will scale the gauge accordingly. U- Crank Isolate Indicator: Displays the current mode on mode change. If the mode is crank isolate it will be shown in permanence.
- Page 17 Configuration Config (Menu) Config Two menus have specific detail for the AFD product (Charger and speed setting). Those two specials menu will be cover in detail. Chargers and Batteries Config > Advanced > Chargers and Batteries This page is used to adjust some features of the batteries and chargers.
- Page 18 Engine Speed Config > Advanced > Engine Speed Teeth: The “teeth” input box allows the user to match the number of teeth on the flywheel. This is an important setting to allow a precise calculation of the RPM. Nominal speed: Nominal speed of the motor Engine Run Set/Reset: Speed where we ‘’set’’...
- Page 19 History History (Menu) History This page is used to access all data related to events, statistics, pressure history, power logs and the downloading of this information via one of the two USB ports. -Events: This button leads to the “Events” page, which displays the events from the most recent 500 logs. Each event log contains the date and time of occurrence as well as a brief description of the event.
- Page 20 The “Nameplate Information” page contains all the information found on the nameplate. The Jockey Pump Cut-Out and Cut-In can be set on this page. It is possible to install a custom Service card on this page. Contact Tornatech for more information.
-
Page 21: Wiring Schematic
All right reserved. This drawing and the information contained or depicted herein are the sole property of Tornatech Inc. Copies are communicated to the recipient in strict confidence and may not be retransmitted, published, reproduced, copied or used in any manner, including as the basis for the manufacture or sale of any products, without the express prior written consent of Tornatech Inc. - Page 22 All right reserved. This drawing and the information contained or depicted herein are the sole property of Tornatech Inc. Copies are communicated to the recipient in strict confidence and may not be retransmitted, published, reproduced, copied or used in any manner, including as the basis for the manufacture or sale of any products, without the express prior written consent of Tornatech Inc.
- Page 23 All right reserved. This drawing and the information contained or depicted herein are the sole property of Tornatech Inc. Copies are communicated to the recipient in strict confidence and may not be retransmitted, published, reproduced, copied or used in any manner, including as the basis for the manufacture or sale of any products, without the express prior written consent of Tornatech Inc.
- Page 24 All right reserved. This drawing and the information contained or depicted herein are the sole property of Tornatech Inc. Copies are communicated to the recipient in strict confidence and may not be retransmitted, published, reproduced, copied or used in any manner, including as the basis for the manufacture or sale of any products, without the express prior written consent of Tornatech Inc.
- Page 25 PER QUOTE DRAWING No. Harness for Aline Diesel Engine Fire Pump Controller DD/MM/YY REV. DESCRIPTION DRAWING Model :AFD First Issue 06/05/15 NUMBER Update for Relay PR1 09/09/15 Assembly Update for Wires 14/07/17 5HAR001 Update for IO Board to 2VIZ104 22/09/20...
- Page 26 TECHNICAL DATA - MODBUS COMMUNICATION FOR DIESEL ENGINE FIRE PUMP CONTROLLER To modify IP and SubNet Mask: Go to Config / Advanced / Network Config. Check the "Manual" box. Enter the desired IP address and SubNet Mask. Press Generals Characteristics Apply.
- Page 27 WORD 42011 NFPA Alarms 1 0 Minimum run delay timing high NFPA Alarms 2 0 Pressure start demand high BINARY 1 NA BINARY 1 Remote start demand high 2 High zone delay timing high (option) 2 Deluge start demand high (option) WORD 42012 3 Sequence delay timing high (option) WORD 42013...
-
Page 28: Parts List
PARTS LIST For Model # AFD-24-220 Serial # WD1170094 Project SERT125434-AFD24-220 Customer Aline Group Australasia Pty Ltd P.O. 106653_SPB Reference Spare Parts Kits Components Identification Part Number Circuit Breaker CB2-CB3 BRKLOV0008 Battery Charger Board BC1-BC2 ViziTouch VMB1 ELBTOR0105 Pressure Transducer... - Page 30 Diesel Fire Pump Model DINFLOW 50 - 260 Speed 2600 rpm Diameter 230 mm 90.0 25.0 Std Pump Curve 80.0 Duty Point 1 Power Curve 20.0 70.0 130 % Duty 60.0 15.0 50.0 40.0 10.0 30.0 20.0 10.0 10.0 15.0 20.0 25.0 Flow (l/sec)
