Summary of Contents for lifeSMART LS131
- Page 1 Simply Brilliant Smart Fan Coil Thermostat Model. LS131 Quick User Guide V1.0...
-
Page 2: Product Introduction
PRODUCT INTRODUCTION The LifeSmart smart fan coil thermostat is suitable for household, commercial and industrial temperature control. By comparing the indoor temperature with the set temperature, it controls the fan coil and electric valve, electric ball valve or air valve at the end of the A/C system to adjust the indoor temperature and improve the indoor air quality. -
Page 3: Specifications
SPECIFICATIONS Mode selection Cooling/heating/ventilation Supply voltage AC 230V 50/60Hz Maximum load current Power consumption Temperature setting range 16~32°C Indication mode Simultaneous indication of set temperature and measured temperature on the screen Temperature-sensing element Thermistor B=3380 10K @25°C Housing material Flame retardant PC Wiring mode Terminal crimping Sectional area of conductor... -
Page 4: Part Description
PART DESCRIPTION Mode switch Air speed DOWN Power button... - Page 5 OPERATION INSTRUCTIONS " " controls the power state. The room temperature and "OFF" are displayed in power-off state. " " and " " can be used to adjust the set temperature up and down, as well as corresponding setting items. 3 Press "...
-
Page 6: Wiring Diagram
WIRING DIAGRAM Valve Valve Live Null High Medium Open Close... - Page 7 Scan the following QR code and install the App following the instructions: After configuration of the Smart Station, choose “Add Device” in LifeSmart App, select “Smart Fan Coil Thermostat ” to enter pairing process. Power on the smart fan coil thermostat, press and hold the right "UP"...
-
Page 8: Product Installation
Put the outer frame on and place the panel into the power box. HOW TO UNINSTALL Remove the outer frame and the panel; Remove all the screws and pull out the thermostat. LifeSmart Smart Fan Coil Thermostat is a high precision electronic apparatus. Please treat carefully. - Page 9 FUNCTIONS " " going on indicates that the actuator or the valve is operating. The thermostat keybaord will be locked if " " are pressed and held for 2s at the same time. The screen will display " ". The system will unlock the locked keyboard if "...
-
Page 10: System Menu Settings
SYSTEM MENU SETTINGS In the power-off state, press " " to power on, immediately press " " to enter the advanced function setting, press " " or " " to set other parameters, press " " and " " to change values, and after cycling all the setting items, it will automatically save and exit system menu settings Indication Setting... - Page 11 SYSTEM MENU SETTINGS Indication Setting Range Factory default Temperature -5°C~5°C -2.5℃ calibration Sensor hysteresis 0.2°C~ 5°C 1.0°C Network address 1—255 setting Factory default Restore Factory Settings...
-
Page 12: Warranty Description
WARRANTY DESCRIPTION Thank you for purchasing this LifeSmart product. In order to protect your right, please read the following content carefully: The warranty period of our company’s products is one year from the date of purchase or longer if local laws impose a longer minimum term, in which case the minimum term is the warranty period. - Page 13 Products that have the barcode tampered with or removed; Devices that have been tampered with or customized outside of LifeSmart Terms Of Service as on the LifeSmart APP and website; User-caused damage, such as inappropriate voltage input, high temperature, accidental spillage, physical damage, etc;...
- Page 14 WARRANTY DESCRIPTION Thank you for purchasing this LifeSmart product. In order to protect your rights, please read the following content carefully: The warranty period of our company's products is one year from the date of purchase or longer if local laws impose a longer minimum term, in which case the minimum term is the warranty period.
- Page 15 DECLARATION LifeSmart is a trademark of Hangzhou LifeSmart Technology Co., Ltd. As for the trademarks, product logos and product names from other companies presented within this manual, they are possessed by their own right holders. Without our written permission, no entity or individual shall extract, copy or disseminate in part or the whole of the manual contents in any form.
- Page 16 Copyright © 2020 LifeSmart Inc. All Rights Reserved.
