INTRODUCTION
The VE8092 or VE8092-S IP Interactive
Consoles are innovative touchscreen
appliances that send live voice or pre-
recorded audio announcements to Valcom IP
audio gateways, IP speakers/horns, and IP
speakers with text. Pre-loaded text or text on
the fly messages can also be broadcast
simultaneously with the audio. The Consoles
can also initiate and receive intercom calls via
the built-in handset from Valcom IP and SIP
endpoint speakers. The IP Interactive
Consoles can receive broadcasted paging
announcements via the built-in speaker from
other IP Valcom FXO, FXS, or SIP gateways.
The VE8092-S includes basic scheduling
functions to send recorded announcements
and/or text Messages to Valcom IP Endpoints.
Applications
Public Address / Paging Console
Intercom Answering Station
Emergency Alert Terminal
SPECIFICATIONS
Access Methods
Touchscreen activation of announcements
SIP protocol phone calls
Valcom intercom and page group calls
Features
Desktop interactive IP device with 10.1" color
touch screen display, loudspeaker, handset,
and cradle attachment
Sends pre-recorded audio files at the push of
a button
Sends microphone pages, either "Live" or
Record & Send for feedback elimination
Sends text messages to Valcom LED signs
Makes/receives bidirectional voice calls to
Valcom and SIP endpoints
Receives audio pages
Simple configuration via web browser
interface
VE8092 / VE8092-S
INTERACTIVE CONSOLE
1
Adjustable display tilt for glare reduction
Power over Ethernet Plus (PoE+), or external
12 Vdc power adapter
Telephone handset pre-installed
Up to 10 schedules and 100 events can be
defined (VE8092-S)
Dimensions/Weight
Product:
12.00"W x 8.00"H x 5.25"D
(30.5cm W x 20.3cm H x 13.3cm D)
3.80 lbs. (1.7 kg)
Nominal Power Requirements
Power over Ethernet Plus (PoE+):
IEEE 802.3at compliant switch or injector
External via rear panel barrel connector:
Voltage:
Current:
Power Supply included
Environment
Temperature:
Humidity:
0 to 85% non-precipitating
These products are intended for use with a UL
Listed power source marked "Class 2" or "LPS"
rated 12 Vdc, or 48 Vdc (PoE).
PoE and all interconnected ITE are intended for
.
intra-building
Issue 2
12 Vdc
2A
0 to +40° C
947091
