Summary of Contents for FiRA VISION GD10
- Page 1 USER MANUAL Gas Detector-VOC Model: GD10/GD20 We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
- Page 2 Precautions This product is a precision electronic device. Please read this Manual carefully before operating this product. Do not operate beyond the range specified in the technical indicators. • Do not open the housing without authorization for repair or modification. Repairs can only be carried out by qualified professionals of the Company.
- Page 3 • The equipment has been strictly calibrated before leaving the factory. It is recommended to send the equipment back for calibration once a year to ensure the service stability. • Please use the standard battery for operation, and use the standard charger to charge the battery.
-
Page 4: Table Of Contents
Table of Contents GD20 Thermal Imager ........... 6 1.1 In the box ..............6 Description ..............7 Operating Instructions ..........11 Quick Start ............. 11 2.2 Interface ..............12 III. Menu Functions ............13 IV. Analysis Functions ............17 Point Temperature Measurement ......17 Line Temperature Measurement ...... - Page 5 4.16 WIFI connection ............. 34 4.17 Trouble Shooting ............35 We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
-
Page 6: Gd20 Thermal Imager
After receiving the thermal imager, please check that it is complete and intact, and contact the supplier in case of any damage. The package consists of the following components: GD10 (30mm 18.2°x14.5° standard lens) * 1 Lithium battery (8.4V/7000 mA) * 3 Charging base for lithium battery *1... -
Page 7: Description
Description Front view ① LED light ② Visible light CMOS ③ Laser ranging module We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... - Page 8 Left view ① On-off Button: Turn on and off the camera ② NUC Setting Button: This button manually can correct temperature compensation parameters of the machine ③ Mode Button: Switch between different modes ④ Laser Button: Turn on the laser indicator, presse for laser ranging ⑤...
- Page 9 ⑨ SD Card interface: S D port ⑩ USB interface: USB C interface ⑪ HDMI interface: HDMI connector We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
- Page 10 Right view ① ZOOM button: Zoom In or Out ② MAX Button: Calculates the maximum FID / PID value, press again to end calculating a n d to display the maximum value calculated from start to finish ③ M Button: Switch screen modes ④...
-
Page 11: Operating Instructions
Operating Instructions Quick Start Install the fully charged battery into the thermal imager or insert the power adapter into the power socket to supply power to the thermal imager. Open the rear cover and insert the SD card. Press and hold the Start button for two seconds, so that the running indicator will be on and the instrument starts running. -
Page 12: Interface
View and playback: Enter the preview mode, select the picture or video to view, and click to play. After using the equipment, please press and hold the switch for 3 seconds to turn off the camera. 2 .2 Interface Main interface layout The image is displayed on the left of the screen and the instrument mode information is on the right. -
Page 13: Menu Functions
④ Manual/ automatic color code ⑤ Instrument information bar ⑥ Date and time ⑦ Status bar ⑧ ⑨ FID value, PID value III. Menu Functions The system consists of 4 modes: photo, video, preview and settings. Photo mode Video mode We reserve the right to change products and specifications at any time without notice. - Page 14 Preview mode Settings mode We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
- Page 15 We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
- Page 16 Press and hold the five- way key in photo mode to enter the work area: Temperature correction: Points, lines, boxes can be added/ deleted in this mode. Temperature measurement: Parameters can be set Image mode: 4 video modes can be selected Color code switching: 1 2 color palettes Zooom- 1 -8 times We reserve the right to change products and specifications at any time without notice.
-
Page 17: Analysis Functions
IV. Analysis Functions 4 .1 Point Temperature Measurement After entering the work area, select and hold the five- way key to add the point. Press and hold the five- way key again to select the point to be added ( the selected point is yellow) . - Page 18 After selecting the point, click the five-way key to enter the attribute setting menu and select the operation to be performed. We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
-
Page 19: Line Temperature Measurement
4. 2 Line Temperature Measurement Press and hold the five-way key to add the line after selecting. Press and hold the five- way key again to select the line to be added ( the selected line is yellow) . We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... -
Page 20: Area Analysis
After selecting the line, click the five-way key to enter the attribute setting menu and select the operation to be performed. Area Analysis Press and hold the five-way key to add the box after selecting. We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... - Page 21 Press and hold the five- way key again to select the box to be added ( the selected box is yellow) . After selecting the box, click the five-way key to enter the attribute setting menu and select the operation to be performed. We reserve the right to change products and specifications at any time without notice.
-
Page 22: Deteling Analysis Functions
Deteling Analysis Functions Clicking once can clear all added analysis points, lines and areas on the screen. Temperature Correction Modify the parameters of the image by clicking to enter the temperature correction page. We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... -
Page 23: Video Mode
Video Mode Click the icon, there are four video modes in the video area that can be selected, namely IR, CCD, HSE and TR modes. Infrared Mode ( IR) Visible Light Mode ( CCD) We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... - Page 24 Gas Enhanced Infrared Mode ( HSE) TEMP IR Mode (TR) We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
-
Page 25: Nuc Operation
NUC Operation In IR mode, close the lens cover as shown in the following figure, and then press the NUC setting button to manually t o correct the machine to complete zero setting. In TEMP IR( TR) mode, zero setting can be completed by automatic operation inside the machine or manual pressing of NUC setting button. -
Page 26: Palette
4 .8 Palette There are 1 2 color Palettes in the video area that can be selected. Zoom A draggable zoom bar will appear on the infrared video interface, allowing 1X~8X continuous zoom We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... -
Page 27: Temperature Ranges
4 . 1 0 Temperature Ranges Switch ranges by clicking the temperature measurement icon to show temperature measurement ranges menu. We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... -
Page 28: Photo
4.11 Photo In the photo mode, you can click the camera button to freeze the screen, and select to add, save or cancel recording on the frozen screen. 4.12 Video We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... -
Page 29: Preview Mode
In the video mode, you can click the camera button to start video recording, with the recording time displayed at the bottom right of the screen, and click again to finish the video recording. 4.13 Preview Mode Turn the mode button to enter the preview screen, in the preview screen, you can select the corresponding picture for secondary analysis or playback of the recorded video. - Page 30 Temperature Measuring Information Camera Settings We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
- Page 31 System Settings Camera Information We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
-
Page 32: Bluetooth
4.15 Bluetooth Open the camera setting menu, toggle the Bluetooth switch to enter the setting interface. When you enter the Bluetooth interface, the headset is automatically searched: We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024... - Page 33 ( If no result is returned after automatic search, click the Search Headset button manually) The pairable headset searched will appear in the window, and the paired headset model will appear in the right window. When a pairable headset appears, you can manually click the headset model for connection.
- Page 34 4.16 WIFI connection Enter the camera settings interface and toggle the switch to turn on the WIFI function. We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
-
Page 35: Troubleshooting
Trouble Shooting 4.17 Issue Solution Bluetooth headset does not work Repair Bluetooth headset Menu does not respond and cannot Restart the camera be operated Check whether there is condensate vapor in front of the lens and remove it (if any); The equipment is switched in an environment ha a good temperature difference, if so, place it in a new... - Page 36 Images cannot be stored If the SD card has been inserted but cannot be detected, replace with a new card Check the battery power; If the Power- on failure power is sufficient, check connectors We reserve the right to change products and specifications at any time without notice. www.firavision.com V1.1 2024...
