  • Page 2: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp ASRock Incorporation e-mail: info@asrock.com.tw...

  • Page 3: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Motherboard Layout I/O Panel Block Diagram Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM) Connecting the Front Panel Header Installing the I/O Panel Shield Installing the Motherboard Installing SATA Drives Installing a Graphics Card Connecting Peripheral Devices...
  • Page 4 2.16 M.2 SSD Installation Guide (M2_1 and M2_2)

  • Page 5: Chapter 1 Introduction

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 6: Specifications

    8333+(OC)* • Supports Clocked Unbuffered DIMM (CUDIMM) • Max. capacity of system memory: 128GB • Supports Intel® Extreme Memory Profile (XMP) 3.0x * Please refer to Memory Support List on ASRock's website for more information. (http://www.asrock.com/) Expansion CPU: • 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*...
  • Page 7 B860M-H2 Audio • 7.1 CH HD Audio (Realtek ALC897 Audio Codec) • Gigabit LAN 10/100/1000 Mb/s • Realtek 8111H CPU: • 1 x USB 3.2 Gen2x2 Type-C (Rear) Chipset: • 1 x USB 3.2 Gen1 Type-C (Front) • 5 x USB 3.2 Gen1 Type-A (3 Rear, 2 Front) • 6 x USB 2.0 (2 Rear, 4 Front)
  • Page 8 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 9: Motherboard Layout

    B860M-H2 1.3 Motherboard Layout...
  • Page 10 No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) AIO Pump Fan Connector (AIO_PUMP) Addressable LED Header (ADDR_LED1) Addressable LED Header (ADDR_LED2) ATX Power Connector (ATXPWR1) USB 3.2 Gen1 Header (USB32_4_5) Front Panel Type C USB 3.2 Gen1 Header (USB32_TC2) SATA3 Connectors (SATA3_2)(Upper), (SATA3_3)(Lower) SPI TPM Header (SPI_TPM_J1)

  • Page 11: I/O Panel

    B860M-H2 1.4 I/O Panel No. Description No. Description LAN RJ-45 Port* BIOS Flashback Button Line In (Light Blue)** USB 3.2 Gen1 Type-A Port (USB32_3) Front Speaker (Lime)** USB 3.2 Gen2x2 Type-C Port (USB32_TC1) Microphone (Pink)** HDMI Port USB 2.0 Ports (USB_12) HDMI Port USB 3.2 Gen1 Type-A Ports (USB32_12)
  • Page 12 ** Function of the Audio Ports in 7.1-channel Configuration: Port Function Light Blue (Rear panel) Rear Speaker Out Lime (Rear panel) Front Speaker Out Pink (Rear panel) Central /Subwoofer Speaker Out Lime (Front panel) Side Speaker Out...

  • Page 13: Block Diagram

    B860M-H2 1.5 Block Diagram...

  • Page 14: Chapter 2 Installation

    Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 15: Installing The Cpu

    B860M-H2 2.1 Installing the CPU 1. Before you insert the 1851-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket.
  • Page 16 Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 17: Installing The Cpu Fan And Heatsink

    B860M-H2 2.2 Installing the CPU Fan and Heatsink...

  • Page 18: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides two 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2.
  • Page 19 B860M-H2...

  • Page 20: Connecting The Front Panel Header

    2.4 Connecting the Front Panel Header Front Panel Wires System Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 21: Installing The I/O Panel Shield

    B860M-H2 2.5 Installing the I/O Panel Shield...

  • Page 22: Installing The Motherboard

    2.6 Installing the Motherboard...

  • Page 23: Installing Sata Drives

    B860M-H2 2.7 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 24 SATA Power Connector SATA Data Connector...

  • Page 25: Installing A Graphics Card

    B860M-H2 2.8 Installing a Graphics Card CLICK!
  • Page 26 Expansion Slots (PCIe Slots) There are 3 PCI Express slots on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 27: Connecting Peripheral Devices

    B860M-H2 2.9 Connecting Peripheral Devices...

  • Page 28: Connecting The Power Connectors

    2.10 Connecting the Power Connectors...

  • Page 29: Power On

    B860M-H2 2.11 Power On...

  • Page 30: Jumpers Setup

    2.12 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Clear CMOS Jumper (CLRMOS1) (see p.5, No. 15) CLRMOS1 allows you to clear the data in CMOS.

  • Page 31: Onboard Headers And Connectors

    B860M-H2 2.13 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.5, No.
  • Page 32 Power LED and Speaker Header (7-pin SPK_PLED1) (see p.5, No. 12) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED- Serial ATA3 Connectors Vertical: (SATA3_0) (see p.5, No. 17) (SATA3_1) (see p.5, No.
  • Page 33 B860M-H2 USB 2.0 Headers (9-pin USB_3_4) (see p.5, No. 19) (9-pin USB_5_6) (see p.5, No. 18) There are two headers on this motherboard. Each USB 2.0 header can support two ports. USB_3_4 USB_PWR DUMMY USB_PWR USB_5_6 USB_PWR DUMMY USB_PWR USB 3.2 Gen1 Header (19-pin USB32_4_5) (see p.5, No.
  • Page 34 Front Panel Type C USB 3.2 Gen1 Header (20-pin USB32_TC2) (see p.5, No. 9) There is one Front Panel Type C USB 3.2 Gen1 Header on this motherboard. This header is used for connecting a USB 3.2 Gen1 module for additional USB 3.2 Gen1 ports.
  • Page 35 B860M-H2 Chassis Fan Connectors (4-pin CHA_FAN1) (see p.5, No. 23) (4-pin CHA_FAN2) (see p.5, No. 21) This header allows you to connect Case or Radiator fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3.
  • Page 36 CPU Fan Connector (4-pin CPU_FAN1) (see p.5, No. 2) This header allows you to connect CPU fan or Water Pump. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CPU_FAN1 FAN_VOLTAGE CPU_F AN_SPEED FAN_SPEED_CONTROL AIO Pump Fan Connector (4-pin AIO_PUMP) (see p.5, No.
  • Page 37 B860M-H2 ATX Power Connector (24-pin ATXPWR1) (see p.5, No. 7) This motherboard provides a 24-pin ATX power connector. To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATXPWR1 ATX 12V Power Connector (8-pin ATX12V1) (see p.5, No. 1) This motherboard provides a 8-pin ATX 12V power connector.
  • Page 38 SPI TPM Header (13-pin SPI_TPM_J1) (see p.5, No. 11) This connector supports SPI Trusted Platform Module (TPM) system, which can securely store keys, digital certificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity.
  • Page 39 B860M-H2 RGB LED Header (4-pin RGB_LED1) (see p.5, No. 14) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 40 Addressable LED Headers (3-pin ADDR_LED1) (see p.5, No. 5) (3-pin ADDR_LED2) (see p.5, No. 6) (3-pin ADDR_LED3) (see p.5, No. 20) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects. Caution: Never install the Addressable LED cable in the wrong orientation;...
  • Page 41 B860M-H2 1. Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your Addressable LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.

  • Page 42: Smart Switches

    2.14 Smart Switches The motherboard has one smart switch: BIOS Flashback Button, allowing users to flash the BIOS. BIOS Flashback Button (BIOS_FB1) (see p.7, No. 7) BIOS Flashback Button allows users to flash the BIOS. BIOS_FB1 USB BIOS Flashback port...
  • Page 43 B860M-H2 ASRock BIOS Flashback feature allows you to update BIOS without powering on the system, even without CPU. Before using the BIOS Flashback function, please suspend BitLocker and any encryp- tion or security relying on the TPM. Make sure that you have already stored and backup-ed the recovery key.

  • Page 44: Wifi/Bt Pcie Wifi Module Installation Guide

    2.15 M.2 WiFi/BT PCIe WiFi Module Installation Guide The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT PCIe WiFi module. * The M.2 socket does not support SATA M.2 SSDs. Installing the WiFi/BT module Step 1 Prepare a type 2230 WiFi/BT PCIe...
  • Page 45 B860M-H2 Step 3 Gently insert the WiFi/BT PCIe WiFi module into the M.2 slot. Please be aware that the module only fits in one orientation. Step 4 Tighten the screw with a screwdriver to secure the module into place. Please do not overtighten the screw...
  • Page 46 2.16 M.2 SSD Installation Guide (M2_1 and M2_2) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Blazing M.2 Socket (M2_1, Key M) supports type 2280 PCIe Gen5x4 (128 Gb/s) mode. The Hyper M.2 Socket (M2_2, Key M) supports type 2280 PCIe Gen4x4 (64 Gb/s) mode.
  • Page 47 B860M-H2 Step 3 Align and gently insert the M.2 SSD into the M.2 slot. Please be aware that the M.2 SSD only fits in one orientation. Step 4 Ensure that the notch at the end of the M.2 SSD aligns with the nut.

  • Page 48: Copyright Notice

    (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock has been advised of the possibility of such damages arising from any defect or error in...
  • Page 49 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You...
  • Page 50 U.S. GOVERNMENT RESTRICTED RIGHTS. The Software is a commercial item (as defined in 48 C.F.R. 2.101) consisting of commercial computer software and commercial computer software documentation (as those terms are used in 48 C.F.R. 12.212), consistent with 48 C.F.R. 12.212 and 48 C.F.R 227.7202-1 through 227.7202-4. You will not provide the Software to the U.S.

  • Page 51: Fcc Compliance Statement

    FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 52 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 53 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
  • Page 54 BSMI 限用物質及元素清單 限用物質及其化學符號 單元 鉛 (Pb) 鎘 (Cd) 汞 (Hg) 六價鉻 (Cr 多溴聯苯 (PBB) 多溴聯苯醚 (PBDE) 電路板 電子元件 線材 配件 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含量 基準值。 備考 2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。 備考 3.〝－〞係指該項限用物質為排除項目。...
  • Page 55 China RoHS 电子信息产品污染控制标示 依据中国发布的「电子信息产品污染控制管理办法」及 SJ/T 11364-2006「电子信息产 品污染控制标示要求」，电子信息产品应进行标示，藉以向消费者揭露产品中含有的 有毒有害物质或元素不致发生外泄或突变从而对环境造成污染或对人身、财产造成严 重损害的期限。依上述规定，您可于本产品之印刷电路板上看见图一之标示。图一中 之数字为产品之环保使用期限。由此可知此主板之环保使用期限为 10 年。 图一 有毒有害物质或元素的名称及含量说明 若您欲了解此产品的有毒有害物质或元素的名称及含量说明，请参照以下表格及说明。 有害物质或元素 部件名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 印刷电路板 及电子组件 外部信号连 接头及线材 以上表格依据 SJ/T 11364-2014 的规定编制。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出...
