MODERN SHADE IG10600041 Owner's Manual

12'x12'wedgewood cedar framed hard top gazebo

Advertisement

Quick Links

MODEL:IG10600041
OWNER´S MANUAL
12´x12´Wedgewood Cedar Framed Hard Top Gazebo
TABLE OF CONTENTS
ASSEMBLY GUIDE·································02
USING YOUR PRODUCE·························04
IMPORTANT:
This insteuction manual contains important
information necessary for the proper assembly and safe
use of the product.
Read and follow all warnings and instructions before
assembling and using the product.
Follow all warnings and instructions when using the
product.
Keep this manual for future reference.
Installer/Assembler:Leave these instructions with the consumer.
CONTACT CUSTOMER SUPPORT BEFORE RETURNING PRODUCT TO RETAILER.
Questions?
E-mail:support@modernshade.org
Toll Free:1-888-666-3070
Mon-Fri:9:00---17:00 PST.
SAFETY ALERT KEY
DANGER
Indicates a hazardous situation that,if
not avoided,will result in death or
serious injury.
CAUTION
Indicates a hazardous situation that,if
not avoided,could result in minor or
moderate injury.
WARNING
Indicates a hazardous situation that,if
not avoided,could result in death or
serious injury.
NOTICE
Indicates information considered
important,but not hazard-related
(e.g.messages related to property
damage).
01

Advertisement

loading
Need help?

Need help?

Do you have a question about the IG10600041 and is the answer not in the manual?

Questions and answers

Summary of Contents for MODERN SHADE IG10600041

  • Page 1 MODEL:IG10600041 OWNER´S MANUAL 12´x12´Wedgewood Cedar Framed Hard Top Gazebo Questions? TABLE OF CONTENTS E-mail:support@modernshade.org ASSEMBLY GUIDE·································02 Toll Free:1-888-666-3070 USING YOUR PRODUCE·························04 Mon-Fri:9:00---17:00 PST. SAFETY ALERT KEY IMPORTANT: DANGER WARNING This insteuction manual contains important information necessary for the proper assembly and safe...
  • Page 2: Assembly Guide

    MODEL:IG10600041 ASSEMBLY GUIDE PARTS LIST Post Foot Base Foot Cover Cross Beam 1 Cross Beam 2 Herringbone (4 Piece) (4 Piece) (4 Piece) (4 Piece) (4 Piece) Beam 1 (4 Piece) P0008008604 P0008008605 P0008008606 P0008008607 P0008008608 P0008008609 Herringbone Herringbone Herringbone...
  • Page 3 MODEL:IG10600041 Roof Plate 4 Roof Plate 5 Roof Plate 6 Roof Plate 7 Roof Plate 8 Hook (4 Piece) (4 Piece) (4 Piece) (4 Piece) (4 Piece) (1 Piece) P0008008640 P0008008641 P0008008642 P0008008643 P0008008644 P0008008645 HARDWARE Bolt M10*65 Bolt M5*25...
  • Page 4 MODEL:IG10600041 ASSEMBLT INSTRUCTIONS •For ease of assembly,it is recommended to have at least 3-4 •Please carefully unpack each of the components and people and allow enough time to completely finish the assembly. hardware.check the components against the parts list and assembly can take 6-8 hours.
  • Page 5 MODEL:IG10600041 STEP 05 = Use two (2) bolts, two (2) bolts, two (2) screw STEP 06 = Use four (4) bolts and four (4) flat washers to attach one nuts and six (6) flat washers to attach one (1) cross beam assembly...
  • Page 6 MODEL:IG10600041 STEP 09 = Attach six (6) bolt pins to herringbone support bracket STEP 10 = Attach herringbone beam to herringbone support bracket . Use two (2) bolts, two (2) screw nuts and four (4) Repeat with the other eighteen (18) bolt pins.
  • Page 7 MODEL:IG10600041 STEP 13= Use one (1) bolts and one (1) flat washers to attach STEP 14 = Use twelve (12) bolts and twelve (12) flat washers to roof top support 1 with each other. attach roof top support assembly to roof rib...
  • Page 8 MODEL:IG10600041 STEP 17 = Use one (1) bolts and one (1) flat washers to STEP 18 = Use one (1) bolts and one (1) flat washers to attach one (1) attach one (1) connector 5 to protector middle cross beam...
  • Page 9 MODEL:IG10600041 STEP 21= Use one (1) bolts and one (1) flat washers to attach STEP 22 = Use two (2) bolts, two (2) flat washers to attach roof plate one (1) roof top support 2 to roof rib 2 to roof rib...
  • Page 10 MODEL:IG10600041 STEP 25 = Use one (1) bolt and one (1) flat washer to attach one (1) roof support 1 to roof rib . Use one (1) bolt to attach roof support to herringbone beam assembly E1 E2 Use one (1)
  • Page 11 MODEL:IG10600041 STEP 27= Use two (2) bolts, two (2) flat washers and two (2) STEP 28 = Use one (1) bolt and one (1) flat washer to attach one (1) [TT] sealant washers to attach one (1) roof rib cover 2...
  • Page 12 MODEL:IG10600041 STEP 30 = Use two (2) expansion bolts to anchor each post foot base...
  • Page 13: Limited Warranty

    MODEL:IG10600041 Outdoor Structure anchoring guide for anchoring gazebo to •Our components are intended for privacy, decorative wood or concrete:If step 30, on page 12 in the assembly and ornamental use only. instructions is not properly completed , this will void the •Product is NOT INTENDED for the following:...
