- Page 1 QUICK REFERENCE GUIDE GCB-60 Guarding Capacitor Bank WARNING PLEASE READ CAREFULLY BEFORE INSTALLING OR OPERATING THIS UNIT!
-
Page 2: Product Specifications
Introduction Introducing the GCB-60, Guarding Capacitor Bank designed to enhance your car audio system’s performance. This unit features advanced capacitors paired with the LM5060 controller for precise power management and protection in high-side N-channel MOSFET applications. It stabilizes power supply, reduces distortion, and improves overall efficiency. -
Page 3: Packaging List
The following items should be placed in the box according to the model you purchased. lf there is any missing, please inform the seller or manu- facturer as soon as possible. GCB-60 Unit ·1 Unit Quick Reference Guide ·1 pc Mounting Brackets ·4 pcs... - Page 4 Mechanical Drawing (Nominal Dimension (inch,mm)) Top View Side View 3.5” (89.0) 1.91” (48.5) Quick Reference Guide GCB-60-03...
- Page 5 Mechanical Drawing (Nominal Dimension (inch,mm)) Front View 3.5” (89.0) Rear View Note: The mechanical drawing provided is not to scale 1:1. Please refer to the specified dimensions for accurate measurements. Quick Reference Guide GCB-60-04...
-
Page 6: Panel Layouts
Panel Layouts Front Panel Rear Panel Fuse 40A x2 DC Output DC Input UVLO Setting Charge LED Power LED Quick Reference Guide GCB-60-05... -
Page 7: Technical Specifications
@VIN=12V Current Standby @VIN=8V Current Transient Current Notes: Measurement Conditions: All specifications are measured under standard operat ing conditions (ambient temperature of +25°C and standard voltage levels). Specifications may be subject to change without prior notice. Quick Reference Guide GCB-60-06... - Page 8 Always follow the installation manual for correct connection and charging/discharging procedures. Do not exceed the specified voltage or expose the capacitor to direct sunlight or extreme temperatures. Improper connec- tions can lead to electrical damage to the vehicle and equipment. Quick Reference Guide GCB-60-07...
- Page 9 8.37 or 5.26 (min.) (min.) The positive and negative wires connected to GCB-60 should match the gauge of the amplifier power wires. For optimal performance, high-quality 8 or 10 AWG OFC (Oxygen-Free Copper) power cables are recommended for this application.
- Page 10 POWER-UP PROCEDURES 1. Charge LED Not Lighting Up • Ensure the amplifier is connected to GCB-60 with correct positive and negative polarities. • Verify that GCB-60 is connected to the battery with correct polarities. 2. Charge LED Stays Green •...
- Page 11 Thank you for choosing this BerryBak™ capacitor bank for your application. BerryBak are known worldwide for their reliable performance, advanced features, and affordable price, proving that efficient, high-quality energy storage solutions can be cost-effective.
- Page 12 Designed by: 58-7-2 Wisma Fortune Height, Jalan Cantonment, 10250 Georgetown, Penang, Malaysia. +60 17 344 0643 l info@berrybak.com (Please use phone calls or email instead of WhatsApp or iMessage.) To view our products and purchase, please check the Taobao or Aliexpress website by searching for the product name (example: GCB-60).
