- Page 1 BirdBlocker BB200 Installation manual www.birdblocker.com...
-
Page 2: Table Of Contents
5. What’s in the box 6. Installing standard clips 7. Starting the installation 8. Cutting inside corners 9. Cutting outside corners 10. Mounting systems 11. Installing BirdBlocker on conventional frames 12. Installing BirdBlocker on box-design frames 13. Connecting strips 14. General considerations... -
Page 3: Before You Start
BirdBlocker products offer reliable protection against intrusive birds. To optimize this protection, it is instrumental to use the correct BirdBlocker length. As the design-differences are purpose-engineered for its application, it is important to measure prior to ordering BirdBlocker from the bottom of the panel-frame to the deepest part of the roofing material. -
Page 4: What Do I Need
THE RIGHT CLIPS BirdBlocker clips fit on the vast majority of all solar panels. In recent years, we have seen a steep increase in popularity of the box-design for the short sides of the panel. Contingent on the used panels, your installation could require box-design clips. -
Page 5: Safety Disclaimer
The BirdBlocker system is easy to install, but the common field of application should not be underestimated. BirdBlocker is under no circumstances liable for the safety of its users, the installation quality or safeguarding the legal framework. -
Page 6: Installing Standard Clips
Saves time and money! STARTING THE INSTALLATION When all the safety- and climbing gear has been taken care off, the BirdBlocker install is started in the far-corner from your access point. The installation of BirdBlocker moves from the starting point towards the point of access. -
Page 7: Cutting Inside Corners
The rounded edge cuts better, cleaner, and easier then straight tinsnips or cutters. CUTTING OUTSIDE CORNERS For outside corners: • Miter cut the back segment of the strip • Add an extra clip before and after the corner for extra stability BirdBlocker BB200 | Installation manual... -
Page 8: Mounting Systems
It is instrumental to create a continuous enclosure with BirdBlocker. Under the frame-ends of the mounting system, Birdblocker will provide a continuous protection: • Cut the back segment of the BirdBlocker strip twice with two or three needles in between (depending of the width of the mounting frame) •... -
Page 9: Installing Birdblocker On Box-Design Frames
The Datasheet of your panels usually displays a cross section of your frame-design. For box-designs you require additional clips for the right height (usually 30mm or 35mm) and width (8-13mm or 14-18mm). BoxClip 50s - 8-13mm BoxClip 50s - 14-18mm BirdBlocker BB200 | Installation manual... -
Page 10: Connecting Strips
• Zip until it provides a sturdy connection between the bridges/strips • Cut of excess length • Rotate the closing mechanism to the back for a clean look Variation 2: • Connect without using tie-wraps BirdBlocker BB200 | Installation manual... -
Page 11: General Considerations
• BirdBlocker is not resistant to martens, rats, etc. It is however our experience that presence of birds/ eggs/ chicks can give them sufficient cause to be problematic. Bird proofing removes the incentive for vermin and helps keep your installation safe. - Page 12 Check all our online manuals at www.birdblocker.com/manuals BirdBlocker B.V. Leemolen 46 2678 MH de Lier The Netherlands +31 (0)174 725 725 info@birdblocker.com www.birdblocker.com...
