Summary of Contents for Winpower RP-01
- Page 1 Shenzhen China www.winpower.com.cn E-mail: phc@winpower.com.cn HAND-HELD ULTRASONIC OXYGEN ANALYZER User Instruction Model ： RP-01 catalog page...
- Page 2 Shenzhen China www.winpower.com.cn E-mail: phc@winpower.com.cn 1 Introduction Purpose Functional Description Important instructions for use and safety 2 Operation Switching on the device Display Modes Flow/concentration measurement Pressure measurement Battery Charging 3 Technical data 4 NOTE...
-
Page 3: Functional Description
1.3 Important instructions for use and safety Do not calibrate the RP-01 with 100% oxygen! The RP-01 and all accessories that come into contact with oxygen should be kept free of oil and grease. The RP-01 should be protected from moisture. -
Page 4: Operation
2 operation 2.1 Switching on the device Before switching on for the first time, the RP-01 should be charged using a charger. To do this, connect the charger and the RP-01. To switch on, press the POWER key. Pressure... -
Page 5: Display Modes
Oxygen concentrator and the RP-01, no humidifier may be connected. 2.4 Pressure measurement For pressure measurement, the pressure line must be connected to the pressure port on the RP-01. The pressure can be displayed in Kpa. 2.5 Battery Charging... -
Page 6: Technical Data
Length Including Inlet Fittings: 19.5 cm Thickness: 3.5 cm 4 NOTE: 4.1The RP-01 must not be used to monitor life support systems. 4.2The oxygen concentration measurement may only be performed in an oxygen-nitrogen gas mixture (e.g., oxygen concentrator). 4.3Before detecting, please take off the humidifier bottle.
