AOC 27B35HM User Manual

AOC 27B35HM User Manual

Hide thumbs Also See for 27B35HM:

Advertisement

Quick Links

Download this manual
LCD Monitor
User Manual
27B35HM
www.aoc.com
©2024 AOC. All Rights Reserved.
1
®

Advertisement

loading
Need help?

Need help?

Do you have a question about the 27B35HM and is the answer not in the manual?

Questions and answers

Related Manuals for AOC 27B35HM

Summary of Contents for AOC 27B35HM

  • Page 1 LCD Monitor User Manual 27B35HM www.aoc.com ® ©2024 AOC. All Rights Reserved.
  • Page 2 Safety ......................................1 National Conventions ..............................1 Power ....................................2 Installation ..................................3 Cleaning ....................................4 Other....................................5 Setup ......................................6 Contents in Box ................................6 Setup Stand & Base ................................7 Adjusting Viewing Angle ..............................8 Connecting the Monitor ..............................9 Wall Mounting ................................10 Adaptive-Sync function ............................... 11 Adjusting ....................................12 Hotkeys ..................................
  • Page 3 Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system.
  • Page 4 Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the monitor from damage due to power surges.
  • Page 5 Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product.
  • Page 6 Cleaning Clean the cabinet regularly with a water-dampened, soft cloth. When cleaning use a soft cotton or microfiber cloth. The cloth should be damp and almost dry, do not allow liquid into the case. Please disconnect the power cord before cleaning the product.
  • Page 7 Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation.
  • Page 8 Contents in Box Monitor Warranty card Stand Base Quick Start VGA Cable Power Cable Adapter HDMI Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation.
  • Page 9 Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:...
  • Page 10 Adjusting Viewing Angle For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand so you will not topple the monitor when you change the monitor’s angle. You are able to adjust the monitor as below: NOTE: Do not touch the LCD screen when you change the angle.
  • Page 11 Connecting the Monitor Cable Connections In Back of Monitor. 1. HDMI 2. Analog (D-Sub 15-Pin VGA cable) 3. Power Connect to PC 1. Connect the power cord to the back of the display firmly. 2. Turn off your computer and unplug its power cable. 3.
  • Page 12 L=10+0 Dk=8.0±0.2 H=1.8±0.15 - 0.6 Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. Always contact manufacturer for wall-mount installation. 0° 90° -5° * Display design may differ from those illustrated.
  • Page 13 Adaptive-Sync function 1. Adaptive-Sync function is working with DP/HDMI 2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www.AMD.com Graphics Cards • Radeon™ RX Vega series • Radeon™ RX 500 series • Radeon™ RX 400 series •...
  • Page 14 Adjusting Hotkeys Source/Auto/Exit Clear Vision/< Image ratio/> Menu/Enter Power Menu/Enter When there is no OSD, Press to display the OSD or confirm the selection. Power Press the Power button to turn on the monitor. Image ratio When there is no OSD, Press > hotkey to active image ratio , Press < or > to adjust 4:3 or wide. (If the product screen size is 4:3 or input signal resolution is wide format, the hot key is disable to adjust).
  • Page 15 Clear Vision 1. When there is no OSD, Press the “ <” button to activate Clear Vision. 2. Use the “ > ” or “>” buttons to select between weak, medium, strong, or off settings. Default setting is always “off”. 3.
  • Page 16 OSD Setting Basic and simple instruction on the control keys. Luminance Image Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Contrast Gamma Gamma 1 Brightness Eco mode Standard HDR Mode 1). Press the MENU-button to activate the OSD window. 2).
  • Page 17 Luminance Luminance Image Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Contrast Gamma Gamma 1 Brightness Eco mode Standard HDR Mode Contrast 0-100 Contrast from Digital-register. Brightness 0-100 Backlight Adjustment.  Standard Standard Mode.  Text Text Mode.  Internet Internet Mode.
  • Page 18 Image Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Image Setup Luminance Clock H. Position Phase V. Position Sharpness Clock 0-100 Adjust picture Clock to reduce Vertical-Line noise. Phase 0-100 Adjust Picture Phase to reduce Horizontal-Line noise Sharpness 0-100 Adjust picture sharpness...
  • Page 19 Color Setup Color Setup Picture Boost OSD Setup Game Setting Extra Exit Luminance Image Setup DCB Mode Color Temp. Warm Green Color Gamut Panel native DCB Demo Blue LowBlue Mode Warm Recall Warm Color Temperature from EEPROM. Recall Normal Color Temperature from Normal EEPROM.
  • Page 20 Picture Boost OSD Setup Extra Exit Luminance Image Setup Picture Boost Game Setting Color Setup Bright Frame Brightness H. Position Frame Size Contrast V. Position Bright Frame on or off Disable or Enable Bright Frame Frame Size 14-100 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness...
  • Page 21 OSD Setup Extra Exit OSD Setup Game Setting Luminance Image Setup Color Setup Picture Boost Language English H. Position Transparence V. Position Timeout Break Reminder Language Select the OSD language Timeout 5-120 Adjust the OSD Timeout H. Position 0-100 Adjust the horizontal position of OSD V.
  • Page 22 Game Setting Extra Exit Luminance Image Setup Picture Boost OSD Setup Game Setting Color Setup Game Mode Frame Counter Game Color Overdrive Dial Point Shadow Control Adaptive-Sync No optimization by Game Mode. For playing FPS (First Person Shooters) games. Improves dark theme black level details. For playing RTS (Real Time Strategy).
  • Page 23 Extra Exit Picture Boost OSD Setup Game Setting Extra Luminance Image Setup Color Setup Input Select Auto Image Ratio Wide Resolution : 1920(H)X1080(V) Auto Config. H. Frequency : 67KHz DDC/CI Off Timer Reset V. Frequency : 60Hz Input Select Select Input Signal Source Auto adjust the picture to default.
  • Page 24 Exit Picture Boost OSD Setup Luminance Image Setup Color Setup Game Setting Extra Exit Exit Exit the main OSD...
  • Page 25 LED Indicator Status LED Color Full Power Mode White Active-off Mode Orange...
  • Page 26 Press hot-key (AUTO) to auto-adjust. Please refer to Regulation & Service Information which is in the CD manual Regulation & Service or www.aoc.com (to find the model you purchase in your country and to find Regulation & Service Information in Support page.
  • Page 27 Specification General Specification Model name 27B35HM Driving system TFT Color LCD Panel Viewable Image Size 68.6cm diagonal Pixel pitch 0.3114(H)mm x 0.3114(V) mm Display Colors 16.7M 30-85kHz (D-SUB) Horizontal scan range 30-115kHz (HDMI) Horizontal scan Size(Maximum) 597.888mm 48-75Hz (D-SUB) Vertical scan range...
  • Page 28 Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION (+/-1Hz) FREQUENCY(kHz) FREQUENCY(Hz) 640x480@60Hz 31.469 59.94 640x480@72Hz 37.861 72.809 640x480@75Hz 37.500 75.000 MAC MODES VGA 640x480@67Hz 35.000 66.667 IBM MODE 720x400@70Hz 31.469 70.087 800x600@56Hz 35.156 56.25 800x600@60Hz 37.879 60.317 SVGA 800x600@72Hz 48.077 72.188 800x600@75Hz 46.875 75.000...
  • Page 29 Pin Assignments 15-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Video-Red Video-Green Ground Video-Blue N.C. N.C. DDC-Serial data Detect Cable H-sync GND-R V-sync GND-G DDC-Serial clock GND-B 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No.
  • Page 30 Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
