Summary of Contents for BLUE FROG ROBOTICS Buddy
- Page 1 Carte Blanche DOCKING STATION Guide Utilisateur V1.01 User Guide EN V1.0...
-
Page 2: Summary
1 - SUMMARY... -
Page 3: Table Of Contents
3 - MOUNTING THE BASE ON THE WALL 3.1 - ADHESIVE BONDING 3.2 - SCREW MOUNTING 4 - STATION CONNECTION 5 - BUDDY MENU CONFIGURATION 6 - RELOADING PROCESS 6.1 - TRIGGERING THE RELOADING PROCESS 6.2 - WARNING 7 - CONTACT... -
Page 4: Content
2 - CONTENT... -
Page 5: Items Supplied With The Charging Station Package
2.1 - ITEMS SUPPLIED WITH THE CHARGING STATION PACKAGE Packaging The charging station < Fastener installation guide and 1:1 scale template APPLY TAPE ALL OVER THE BACK SURFACE OF THE SUPPORT 2 Fixing screws and plate a wall-mount FLOOR 32MM FLOOR 53MM... -
Page 6: Mounting The Base On The Wall
3 - MOUNTING THE BASE ON THE WALL... -
Page 7: Adhesive Bonding
3.1 - ADHESIVE BONDING 1 - Apply double-sided tape 2 - Hang base from attachment to charging station 3 - Remove th double-sided tape protection and press the assembly firmly against the wall 3.2 - SCREW MOUNTING Cut out template Apply to baseboard edge... -
Page 8: Station Connection
4 - STATION CONNECTION... - Page 9 Connect the station to power supply supplied with the robot...
-
Page 10: Buddy Menu Configuration
5 - BUDDY MENU CONFIGURATION... - Page 11 1 - Access the Buddy menu 2 - Go to the «Companion» tab 3 - Activate the «Base station» button...
-
Page 12: Reloading Process
6 - RELOADING PROCESS... -
Page 13: Triggering The Reloading Process
6.1 - TRIGGERING THE RELOADING PROCESS 1 - Battery level down to 20% The robot automatically launches the search mission for the recharge 2 - The user says one of the following voice commands : «GO TO THE DOCKING STATION», «GO TO THE CHARGING STATION», «GO (RECHARGE | RECHARGING)», «GO (CHARGE | CHARGING)»,... -
Page 14: Contact
7 - CONTACT... -
Page 15: Contact Information
7.1 - CONTACT INFORMATION If you wish to contact us for further information, please refer to the following address: SUPPORT service-client@buddytherobot.com GENERAL INFORMATION info@bluefrogrobotics.com...
