- Page 1 ProSense SC6 Series Signal Conditioners User Manual This product manual covers the following part numbers: 0068060 SC6-1100 SC6-1110 SC6-2200 SC6-3220 SC6-5200 SC6-7102 0068061 SC6-1101 SC6-1111 SC6-2220 SC6-4102 SC6-6102 SC6-PCU1 0068062 SC6-1102 SC6-1112 SC6-3200 SC6-4112 SC6-6200...
- Page 2 User Manual - ProSense SC6 Series Signal Conditioners ProSense SC6 Series Signal Conditioners User Manual Please include the Manual Number and the Manual Issue, both shown below, when communicating with Technical Support regarding this publication. Manual Number: ProSense SC6 Series Signal Conditioners Manual...
-
Page 3: Table Of Contents
ProSense SC6 Series Signal Conditioners User Manual 1 - Warnings � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 4 2 - Symbol Identification �... -
Page 4: Warnings
User Manual - ProSense SC6 Series Signal Conditioners 1 - Warnings To avoid the risk of electric shock and fire, the safety instructions of this guide must be observed and the guidelines followed. The specifications must not be exceeded, and the device must only be applied as described in the following. -
Page 5: 3�4 - Cleaning
User Manual - ProSense SC6 Series Signal Conditioners The device is provided with field wiring terminals and shall be supplied from a Power Supply having double or reinforced insulation. A power switch should be readily accessible and close to the device. -
Page 6: Supply Voltage Options
User Manual - ProSense SC6 Series Signal Conditioners 4 - Supply Voltage Options The technical specifications specify the maximum required power at nominal operating values, e.g. 24V supply voltage, 60°C ambient temperature, 600 Ω load, and 20mA output current. Power rail solution #2:... -
Page 7: Installing And Uninstalling The Sc6 Series
User Manual - ProSense SC6 Series Signal Conditioners 5 - Installing and Uninstalling the SC6 Series Picture 1: Installing on DIN rail / power rail. Click the device onto the rail. Picture 2: Uninstalling from DIN rail / power rail. -
Page 8: 6�1 - In-Rail-Bus-Set Installation
User Manual - ProSense SC6 Series Signal Conditioners If you want to install a SC6 Series device with power rail connectors on a standard DIN rail, the head of the screws holding the 7.5 mm DIN rail shall be no more than 3.5 mm high in order to avoid short circuit between the power rail connectors on the SC6 Series device and the screws. -
Page 9: Side Label
User Manual - ProSense SC6 Series Signal Conditioners Carrier rail cover Bus PCB mounted in carrier profile Safety end cap DIN rail (order separately) Safety end cap KN-EB7-10 SC6-PCU1 power end bracket connection unit (order separately) SC6 signal conditioners 7 - Side Label... -
Page 10: Common Technical Specifications
User Manual - ProSense SC6 Series Signal Conditioners 8 - Common Technical Specifications SC6 Series Common Technical Specifications Environmental Conditions Operating Temperature -25°C to +70°C (-13°F to +158°F) Storage Temperature -40°C to +85°C (-40°F to +185°F) Calibration Temperature +20°C to +28°C (+68 to +82�4°F) Relative Humidity <... -
Page 11: 4-Wire, External Powered Analog Signal Input Modules - Technical Specifications
User Manual - ProSense SC6 Series Signal Conditioners 9 - 4-Wire, External Powered Analog Signal Input Modules - Technical Specifications 4- Wire, External Powered Analog Signal Input Modules - Technical Specifications Part No. SC6-1100 SC6-2200 SC6-1110 SC6-2220 SC6-3200 SC6-3220 Application... -
Page 12: 2-Wire, Loop Powered Analog Signal Input Modules - Technical Specifications
User Manual - ProSense SC6 Series Signal Conditioners 10 - 2-Wire, Loop Powered Analog Signal Input Modules - Technical Specifications 2-Wire, Loop Powered Analog Signal Input Modules - Technical Specifications Part No. SC6-1101 SC6-1111 SC6-4102 SC6-4112 SC6-1102 SC6-1112 Application One channel... -
Page 13: Temperature Input Modules - Technical Specifications
User Manual - ProSense SC6 Series Signal Conditioners 11 - Temperature Input Modules - Technical Specifications Temperature Input Modules - Technical Specifications Part No. SC6-5200 SC6-6200 SC6-7102 SC6-6102 Application One channel One channel One channel One channel DIP switch configurable Supply voltage 16�8 - 31�2 VDC (terminals or bus rail) -
Page 14: Power Connector Module - Technical Specifications
User Manual - ProSense SC6 Series Signal Conditioners 12 - Power Connector Module - Technical Specifications Power Connection Module - Technical Specifications Part No. SC6-PCU1 Supply voltage 16�8-31�2 VDC Internal power 0�25 W max� dissipation Required external fuse 2�5 A... -
Page 15: Wiring Diagrams
User Manual - ProSense SC6 Series Signal Conditioners 14 - Wiring Diagrams Note: The SC6 2-wire Transmitter Input is a current input which provides an excitation voltage to the input device, otherwise known as an active or sourcing input, while the SC6 Current Input requires the input device be provided with an external excitation voltage, otherwise known as a passive or sinking input. - Page 16 User Manual - ProSense SC6 Series Signal Conditioners SC6-3200 SC6-2220 2-wire Current Voltage Voltage Current Current Voltage Voltage Current Transmitter input input output output input input Output Output input (±) (±) Loop Input Output Input Output 1 Loop+ Supply +...
- Page 17 User Manual - ProSense SC6 Series Signal Conditioners SC6-1111 SC6-4112 2-wire transmitter Current output input Current input Current output +V supply Loop + 0...20 mA 4...20 mA Input Output Input Output ch. 1 ch. 1 Loop - ch. 1 ch. 1...
- Page 18 User Manual - ProSense SC6 Series Signal Conditioners SC6-5200 SC6-6200 Current Voltage Current Voltage output output Input output output TC J & K Supply + Supply + Supply - Supply - Optional External CJC (2- or 3-wire Pt100) No connection...
-
Page 19: Dip Switch Settings
User Manual - ProSense SC6 Series Signal Conditioners 15 - DIP Switch Settings The part numbers listed below are configured with DIP switches which are located on the side of the module and can be adjusted with a small screw driver or other implement. -
Page 20: Led Indication For Analog Input Modules (Sc6-1100, -1110, -2200, -2220, -3200, -3220)
User Manual - ProSense SC6 Series Signal Conditioners SC6-5200, SC6-6200, SC6-6102, SC6-7102 Models: Temperature Range Programming DIP S2 • = ON Temperature Range ºC (°F) Start Temp� End Temp� 5 6 7 8 9 10 End Temp� 5 6 7 8 9 10 End Temp�... -
Page 21: Led Indication For Temperature Input Modules (Sc6-5200, -6200)
User Manual - ProSense SC6 Series Signal Conditioners 17 - LED Indication for Temperature Input Modules (SC6-5200, -6200) LED Indication The device is equipped with a green power LED in the front to indicate the operation status, see the table below:...
