Summary of Contents for NGTeco NG-PPS500
- Page 1 User Manual Model: NG-PPS500 Version: 1.0 English Due to the regular upgrades of systems and products, NGTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Important Notes
Important Notes Please read the following instructions to ensure safety before using. Improper use may cause fire, property damage or personal injury. 1.Product use: 1) DO NOT use any inappropriate power cords. 2) DO NOT place the unit close to or in a fire on expose it to heat. Keep out of direct sunlight. - Page 3 -If there is dirt on any plug or outlet surface, use a dry cloth to clean it. Otherwise, it will cause abrasion and result in energy loss or inability to charge. 6) DO NOT put the machine in a microwave oven or in a pressurized container.
-
Page 4: Table Of Contents
Table of contents Important Notes------------------------------------------- 1 Table of contents------------------------------------------ 3 What’s in the box------------------------------------------ 4 Product Overview----------------------------------------- 5 Button Feature --------------------------------------------- 6 LCD Features ----------------------------------------------- 7 Whit It Powers --------------------------------------------- 9 How to charge-------------------------------------------- 10 Operating Instructions---------------------------------- 12 Other Considerations------------------------------------ 13 General Speci cations---------------------------------- 17... -
Page 5: What's In The Box
12V Car Anderson cable X1 connector cable X1 User Manual Model: NG-PS750 Version: 1.0 English Due to the regular upgrades of systems and products, NGTeco could not guarantee exact consistency between the actual product and the written information in this manual. User Manual X1... -
Page 6: Product Overview
7.Anti-collision Strip 8.DC Input 9.PV Input 10.SOS MODE&LED light 11.Folding Handle Side : 12.Air Intake Vent with Cooling 13.Wireless Charger Note: No user-serviceable parts inside.Recommended to fully charge the NG-PPS500 before use. The AC Output port mayvery in different regions. -
Page 7: Button Feature
D:USB Output Power ON/OFF Button E:AC Output Power ON/OFF Button Function Buttons: Button A : NG-PPS500 POWER ON/OFF Button A is the master switch. Press Button A to turn on the power or to shut down the output(s) when not in use. -
Page 8: Lcd Features
"POWER ON/OFF Button to shut down the output(s) when not in use. Cooling Fan NG-PPS500 utilizes an internal cooling fan to ensure the product is operating within the appropriate temperature range. NG-PPS500,when it experiences a higher output load, will automatically turn on the fan during discharge or recharging , the fan may operate intermittently to keep internal temperature within operating range. - Page 9 20%. Note that when you first plug in a power source, whether it's a solar panel or a wall charger, the NG-PPS500 may take a minute to detect and adjust its charge circuitry before it starts drawing power from the source.
-
Page 10: Whit It Powers
With It Powers Laptops(41.4Wh) 32" TV(60W) 7 hours Around 10 Recharges Gopro(5.9Wh) CPAP without heated Around 74 Recharges humidi er(15W) 29 hours Mini Fridge(40W) Floodlight(4W) Around 11 hours Around 110 hours DJ Drone(89.2Wh) Smartphone(10Wh) Around 4.9 Recharges Around 44 Recharges Switch(16Wh) Around 27 Recharges... -
Page 11: How To Charge
From Wall Charger 220V 7-8 hours. Note: Do not connect device via ac output port while charge the NG-PPS500.recommend to disconnect the NG-PPS500 when fully charged. 1. AC Adapter Charging It will take 6-7 hours to charge fully by using the AC adapterwe... - Page 12 2.Solar Panel Charging 1.DO NOT charge the unit via solar panelthat operate voltage outside of DC12-26V . 2.Place Solar Panels in direct sunlight as much as possible. 3.Support 60W/80W/100W/120W Max Solar Panels (Not included), the charging time is determined by the solar light intensit. Recommend to use 120W Solar panel (not included).
-
Page 13: Operating Instructions
DO NOT Connected Device VIA AC Output With Charge the NG-PPS500. 4) Overload Condition If an overload condition occurs on the OUTPUT port, NG-PPS500 will: Automatically turn off AC Output(6)power. The blue indicator light of LCD Screen(1)still illuminated. DC OUTPUT Status J still the same status as usual. -
Page 14: Other Considerations
Other Considerations 1. Cleaning Be sure that NG-PPS500 is disconnected from all input power sources and output devices. Use a clean, dry, soft-lint-free cloth to wipe down it. Remove any debris, dirt, or other blockages on both side vents. When cleaning debris from the side vents, do not allow the debris, dirt, or other blockages to enter the body of NG-PPS500. - Page 15 Ensure that the DC/USB/AC output ports are activated by pressing the Button(s) A & C/D/E for the port(s) in use. Confirm the connected device is suitable for the NG-PPS500 by reviewing the output specifications provided in the GENERAL SPECIFICATIONS section.
- Page 16 5. Maintenance Recharge as needed. There are no pre-designated intervals at which to recharge as long as the NG-PPS500 is being used regularly. Avoid discharging completed on a regular basis, as this can impact overall life. Regularly inspect all ports and wall charger for any debris, dirt, damage and corrosion.
- Page 17 9. Warranty Period The warranty period is 12 months. In each case, the warranty period is measured starting on the date of purchase by the original consumer purchaser. The sales receipt from the first consumer purchase, or other reasonable documentary proof, is required in order establish the start date of the warranty period.
-
Page 18: General Speci Cations
General Specifications... - Page 19 1600 Union Hill Road Alpharetta, GA 30005 E-mail: service.ng@ngteco.com www.ngteco.com Copyright©2022 NGTECO CO., LIMITED. All rights reserved.
