Fujimoto Lucky CP32 Operation Manual

Paper processor
Hide thumbs

Advertisement

Table of Contents

Lucky CP32: Operation Manual
Product Name
Transport Method
Compatible Paper
Processing Size
Processing Method
Transport Speed
Processing Time
Number of Processing Tanks
Tank Capacity
Liquid Temperature Control
Agitation
Paper Detection
Standby
Ventilation Fan
Chemical Liquid Overwork
Prevention
Liquid Drain
Power Supply / Electricity
Display Method
Dimensions (mm)
Dry Weight (kg)
Accessories
Options
Lucky CP32 Paper Processor
Opposite direction transport method
RC type paper (Fiber-based paper cannot be processed)
Small size cut (12×16 inches 305×406mm) ~ Hand size
(83×108mm)
Chromogenic color prints
Color prints (P30)
Monochrome
42 to 420mm/min (transport speed displayed digitally)
Regular processing time 30 seconds ~ 5 minutes (per tank)
3 tanks (single-deck)
Each tank 2 liters
Automatic constant temperature by microcomputer for
each tank (20~40°C accuracy ±0.1°C)
Can be set for each tank in increments of 0.1°C
Liquid temperature: Digital display
Circulation by magnetic pump
Equipped with infrared sensor at the entrance of tank 1
If not used for more than 45 minutes roller drive stops
automatically and resumes every 15 seconds for 3
seconds
When paper is inserted standby is automatically canceled
Humidity exhaust and ventilation fan attached
Equipped with prevention mechanism against liquid
exhaustion
Drainage via each tank drain pipe
AC100V 50/60Hz 350W
Single unit control via control panel
Display with backlight liquid crystal indicator
Automatically adjusts indicator brightness according to
room brightness
600 (W) × 610 (D) × 250 (H)
29.0 kg
5A fuse 1, rollers 2, drain hoses 3, overflow hoses 4
Automatic replenishment unit, WD module

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lucky CP32 and is the answer not in the manual?

Questions and answers

Related Manuals for Fujimoto Lucky CP32

Summary of Contents for Fujimoto Lucky CP32

  • Page 1 Lucky CP32: Operation Manual Product Name Lucky CP32 Paper Processor Transport Method Opposite direction transport method Compatible Paper RC type paper (Fiber-based paper cannot be processed) Processing Size Small size cut (12×16 inches 305×406mm) ~ Hand size (83×108mm) Processing Method...

  • Page 2: Installation

    Installation • CP32 Paper Processor (and optional WD module) requires space as shown in the diagram to the right. • Keep a distance of about 30 cm on the right side of the main unit. This will make it easier to open the preparation cover. •...
  • Page 3 4. Paper Insertion Indicator
 Indicates when paper feeding is possible. When this indicator is ON, you can insert paper within 30 seconds. 5. Brightness Detection Sensor
 If the room becomes dark or the sensor detects insufficient lighting, the digital display section and the alert lamp will automatically illuminate. 6.
  • Page 4 2. Remove Parts from the Main Unit
 Following the sequence, remove the top cover, inlet rack, Crossover Guides 1 and 2, and racks 1 and 2 from the main unit. After raising the crossover guide to the left, remove it as shown in Figure 2. 3.
  • Page 5 5. Start the Main Unit
 After connecting the power cord and turning the power switch ON, check if the rollers and pumps are functioning properly. Important! Never turn the power ON if there is no water or processing solution in the tanks. If a mistake happens and the machine runs dry, immediately turn off...
  • Page 6 2. Viewing the Liquid Temperature and Rotation Speed of Each Tank
 By pressing the "Up/Down" switch (2), you can view the liquid temperature for Tank 1, Tank 2, Tank 3, and the rotation speed. 3. Setting the Liquid Temperature and Rotation Speed for Each Tank
 When the display shows the current liquid temperature and rotation speed, press the "Mode Switch"...
  • Page 7 Press the "Mode Switch" again to return to the liquid temperature/rotation speed display mode. 4. Returning to Factory Default Settings
 To return to the factory default settings, select "Initial Settings" on the display. The default settings for liquid temperature (35.0°C) and rotation speed (280 mm/ min) will be restored.
...
  • Page 8 Test Run (Rack, Crossover Guide, Top Cover Installation) The settings from steps P-6 to P-8 are complete. Before pouring in the processing solution, it is recommended to check the operation using water. 1. Set the Parts in the Main Unit (Refer to Figures 1, 2, 3) •...
  • Page 9 3. Install the Top Cover (Refer to Figures 5, 6) • After confirming the position of the positioning pins (2 on the left side), attach the top cover. After lifting the cover, open the light-shielding cover and insert the paper, ensuring the emulsion side is up.
  • Page 10 Pouring the Processing Solution 1. Confirm Power Switch is OFF (Refer to Figures 1, 2, 3) • Ensure the power switch is OFF. Remove the top cover, inlet rack, and crossover guides, as well as each rack. If there is water in the tanks, drain it following the steps outlined in P-11.
  • Page 11 7. Reinstall the Inlet Rack and Crossover Guides (Refer to Figures 6, 7) • Reinstall the inlet rack and plug its connector back into the main unit. Make sure the rollers are free from water residue. • Reinstall the crossover guides in sequence and confirm they are free from water, as moisture can affect image processing quality.

  • Page 12: Image Processing

    Image Processing Insert the paper into the machine in a darkroom, close the light-shielding cover, and the automatic image processing will begin. Turn the power switch ON and confirm the following: • The liquid is circulating (the Ready lamp should be green). •...

  • Page 13: Standby Mode

    process the paper in the lightroom after closing the cover. 4. Processing in the Lightroom • After closing the light-shielding cover, the machine will begin processing the image. The room lamp will indicate the status, and the paper will automatically be sent to each tank for processing.

  • Page 14: Cleaning The Parts

    Draining the Liquid After use, be sure to completely drain all liquids from the tanks. Leaving liquid in the tanks can cause crystallization and lead to malfunctions. 1. Turn OFF the Power Switch • Turn the power switch OFF before draining the liquid. If the power switch is ON, the heater or pump may overheat and cause damage.
  • Page 15 3. Never Wash the Inlet Rack with Water (Refer to Figure 1) • Do not clean the inlet rack with water. Instead, wipe it clean using a cloth. Exposure to water can lead to electrical faults. 4. Wash the Racks (Refer to Figure 2) •...
  • Page 16 To Use This Machine Properly 1. About the Crossover Guide • The first crossover guide is equipped with a squeegee to remove excess liquid from the film and prevent dripping. After each use, clean the squeegee thoroughly, place it at the top of the machine, and ensure no liquid is left on it.
  • Page 17 4. About Ventilation • The machine has a ventilation fan for forced air circulation. However, during power-off times, humidity from the processing solution can build up inside. To avoid this, open the top cover whenever the machine is not in use. •...
  • Page 18 Number of Images Processed per Hour by CP32 Notes: • The sizes above are in landscape orientation. • The "Large Cabinet" size is the processing capacity for two rows of paper. • The numbers provided are estimates and do not guarantee the actual number of images that can be processed.
  • Page 19 Processing Solution, Liquid Temperature, and Transport Speed Data The processing solution, liquid temperature, and transport speed (processing time) listed below can be used for general negative color, reversal color, and monochrome processing. Processing Solution Temperature and Transport Speed Note: Forced cooling for processing solution is not available. Please adjust the room temperature to prevent it from rising more than 3°C above the set temperature of the solution during processing.
  • Page 20 Manufacturer Data: CP32 Processing Temperatures and Transport Speeds (Reference) Negative Color Processing (Rapid Processing) Note: The color balance may shift with high-temperature processing (leading to dark black areas). In such cases, adjust the processing speed. For normal color processing, a speed of 190-220 mm/min is recommended. Reversal Color Processing...
  • Page 21 Monochrome Processing Note: For monochrome processing, it is recommended to keep the temperature below 30°C. Using monochrome processing at a higher temperature can cause problems such as excessive fogging. Important Note: Before using a different processing solution, be sure to thoroughly clean the racks, rollers, tanks, and hoses.

  • Page 22: Troubleshooting Checklist

    Troubleshooting Checklist The liquid is not circulating when the There are clear diagonal streaks in the power switch is ON transport direction • The circulation pump may have air • For small paper sizes, is the squeegee trapped inside. In this case, drain the function of the machine disengaged? If processing solution and refill the tanks so, disable standby mode following the...
