- Page 1 DK Hardware v.0.9.0 User Guide 4536_001 / 2024-08-29...
-
Page 2: Table Of Contents
Contents Revision history ........Environmental and safety notices . - Page 3 Regulatory information ......Glossary ........Recommended reading .
-
Page 4: Revision History
Revision history Date Description August 2024 First release 4536_001... -
Page 5: Environmental And Safety Notices
Environmental and safety notices Environmental and safety notices for the DK and power supply requirements. Note: The nRF9151 DK must be powered by a PS1 class (IEC 62368-1) power supply with maximum power less than 15 W. Skilled persons The nRF9151 DK is intended for use only by skilled persons. -
Page 6: Introduction
Introduction The nRF9151 DK is a hardware development platform used to design and develop application firmware on the nRF9151 System in Package (SiP). The nRF9151 SiP supports DECT NR+ or Long-Term Evolution (LTE) and Global Navigation Satellite System (GNSS) depending on the installed network protocol firmware. -
Page 7: Kit Content
Kit content The nRF9151 DK includes hardware, preprogrammed firmware, documentation, hardware schematics, and layout files. Figure 1: nRF9151 DK kit content Hardware files The hardware design files include the following resources: • Schematics • PCB layout files • Bill of materials •... -
Page 8: Operating Modes
The nRF9151 DK has two main modes of operation. 3.1 Firmware development mode The primary interface for programming and debugging the nRF9151 DK is the Universal Serial Bus (USB) port (J6). The USB port is connected to an interface MCU which embeds a... -
Page 9: Performance Measurement Mode
3.2 Performance measurement mode The nRF9151 DK has flexible configuration options for performance testing and operation analysis. The combination of solder bridges and parameter settings in the interface MCU define the DK's operation mode. -
Page 10: Hardware Description
Hardware description The nRF9151 DK features an onboard programming and debugging solution. 4.1 Hardware drawings The nRF9151 DK hardware drawings show both sides of the DK. Figure 4: nRF9151 DK, front view Figure 5: nRF9151 DK, back view 4.2 Block diagram The block diagram illustrates the functional architecture of the nRF9151 DK. -
Page 11: Power Supply
The DK has a flexible and configurable power supply system to allow software development and testing using different power sources and to facilitate accurate power consumption measurements. The nRF9151 DK is powered by either of the following sources: • USB connector J6 (5 V) •... -
Page 12: Nrf9151 Sip Supply Rail
Hardware description By default, the nRF9151 SiP is supplied from USB through a jumper. To supply other power domains on the board, nPM1300 IC is used. The output voltage of the nPM1300 can be controlled through the board controller. The startup voltage for BUCK1 can be set with resistor R36 and for BUCK 2 with resistor R37. For more information, see Board control on page 14 and... -
Page 13: Antenna Interfaces
The GNSS signal is RX only. A Low-Noise Amplifier (LNA) with integrated filters amplifies and filters the signal before it is fed to the GNSS RF port on the nRF9151 DK. An external active GNSS antenna can be connected to J2. When using an external antenna, the LNA should be disabled. -
Page 14: Gpio Interfaces
GPIO signals are also available on connectors P7, P8, P9, P10, P12, and P27 which are on the back of the DK. By mounting pin headers on the connector footprints, the nRF9151 DK can be used as a shield for Arduino motherboards. - Page 15 Hardware description All features on the nRF9151 DK have a default setting that is applied at the first boot. The configuration of the board controller can be changed through nRF Connect for Desktop's Board Configurator application. For more information, see nRF Connect Board Configurator.
- Page 16 Hardware description Feature Configuration State Default state IMCU pin Description P1.10 VCOM 0 True Disconnected Connected Connect or disconnect the pins for the virtual COM port. False Connected When disconnected, the UART0 GPIO pins can be used for other purposes. P0.20 VCOM0 True...
-
Page 17: Buttons And Leds
Table 1: Configurable features on the nRF9151 DK 4.8 Buttons and LEDs The nRF9151 DK has four LEDs and four buttons for user interaction. By default, they are connected to the nRF9151 GPIOs as shown in the following table. Part... -
Page 18: I/O Expander
UM6X1NA 120R L0603G LED4 UM6X1NA Figure 14: LEDs 4.8.1 I/O expander The nRF9151 DK has an I/O expander that can optionally be used to interface the LEDs and buttons. Signal GPIO Description P0.30 I2C data line P0.31 I2C clock line IOEXP_IRQ P0.19... -
Page 19: External Memory
Not mounted 100k BTN4_EXT 1.0µF LED1_EXT LED2_EXT LED3_EXT LED4_EXT Figure 15: I/O expander 4.9 External memory The nRF9151 DK has a 256 Mb (32 MB) external flash memory. The memory is connected to the IC using the following GPIOs. 4536_001... -
Page 20: Debug Input And Trace Options
4.10 Debug input and trace options The primary debug interface on the nRF9151 DK is the Segger OB debugger available through the USB port. If a power supply other than USB is used on the DK, this functionality is disabled. -
Page 21: Debug Out For Programming External Boards
Series, and nRF70 Series System on Chip (SoC)s and nRF91 Series SiPs. The interface MCU on the nRF9151 DK runs SEGGER J-Link OB Debugger interface firmware and is used to program and debug the firmware of the nRF9151 SiP by default. - Page 22 Hardware description Figure 19: Connecting an external board to P19 It is recommended to power the external board separately from the DK. The voltage of the SWD interface on the external board must match that of the DK. The default voltage is 1.8 V. When the interface MCU detects GND of the external board on pin 3 (SELECT) of P19, it programs or debugs the target chip on the external board instead of the onboard nRF9151 SiP.
-
Page 23: Programming A Board With Custom Connections
Hardware description Pin number Signal Description EXT_VDD By default not connected, for configuration see SB15 and SB16 in Solder bridge configuration on page 28 SWDIO SWD data input/output SELECT Select pin for the interface MCU, should be connected to GND on the external board SWDCLK Serial wire clock line Ground... - Page 24 Note: If the interface MCU detects connection on P19 and P20, it programs or debugs the target connected to P19 by default. If there is no separate power supply on the external board, the nRF9151 DK can supply power through pin 2 (VDD) of P20.
- Page 25 Pin number Signal Description VDD_GPIO Supply for the nRF9151 GPIO pins Main nRF9151 DK GPIO level power domain Voltage supply from the external target, used as a select pin for the interface MCU to enable this port SWDIO SWD data line...
-
Page 26: Signal Routing Switches
4.13 SIM and eSIM The nRF9151 DK is designed to support regular SIM and eSIM. For this purpose, it has a pluggable SIM card socket (J5) that takes a nano-sized SIM (4FF) and a non-populated footprint for an eSIM (MFF2). -
Page 27: Additional Interfaces
GNSS LNA of the nRF9151 DK. The nRF9151 DK has an interface allowing the modem to control external RF applications, such as antenna tuner devices. There are three MIPI RFFE interface pins, namely, VIO, SCLK, SDATA, and three MAGPIO interface pins, namely, MAGPIO0, MAGPIO1, and MAGPIO2. -
Page 28: Enable
R1. 4.16 Solder bridge configuration The nRF9151 DK has a range of solder bridges for enabling or disabling functionality on the DK. Changes to these are not needed for normal use of the DK. - Page 29 Hardware description Solder bridge Default Function SB15 Open Short to connect external board power to VIO_REF SB16 Open Short to use VDD rail as power source for the external board Cut to disable P20 pin 3 (VTG) as select pin SB17 Closed SB18...
-
Page 30: Current Measurement
Current measurement The current drawn by the nRF9151 SiP can be monitored on the nRF9151 DK. Current can be measured using any of the following test instruments: • Power analyzer • Oscilloscope • Ampere meter • Power Profiler Kit II Power analyzer measurements are not described in this document. -
Page 31: Measure Current Profile With An Oscilloscope
Prepare the DK for current measurements on page 30. Complete the following steps to measure the current profile of the nRF9151 DK: 1. Solder a 0.5 Ω resistor to R82. 2. Set the oscilloscope to differential mode or to a mode that is similar. -
Page 32: Measure Average Current With An Ampere Meter
Current measurement Figure 28: Current measurement with an oscilloscope To reduce noise, do the following: • Use probes with 1x attenuation. • Enable averaging mode to reduce random noise. • Enable high resolution function if available. A minimum of one sample every 5 µs is needed to accurately measure the average current. 5.3 Measure average current with an ampere meter The current drawn by the nRF9151 SiP can be measured using an ampere meter. - Page 33 Note: Use a high-speed, high-dynamic-range ampere meter for the best and most reliable measurements. Switching the current range in the ampere meter can affect the power supply to the nRF9151 DK. High speed and bandwidth are required to detect rapid changes in the current consumption in the nRF9151 DK.
-
Page 34: Rf Measurements
RF measurements The nRF9151 DK is equipped with a small coaxial connector J1 for measuring the LTE or DECT NR+ RF signal. The connector is of Microwave coaxial connector with switch (SWF) type (Murata part no. MM8130-2600) with an internal switch. By default, when no cable is attached, the RF signal is routed to the onboard antenna. -
Page 35: Radiated Performance
698 MHz to 960 MHz and 1710 MHz to 2200 MHz. All antennas on the nRF9151 DK have fixed matching networks, which means that a matching configuration is not needed to switch between the frequency bands. The LTE antenna also supports other frequency ranges, but it is not optimized for operating on these frequency bands. -
Page 36: Regulatory Information
Regulatory information The nRF9151 DK contains an nRF9151 SiP which is FCC certified. For information on the bands supported by the nRF9151 SiP and for FCC regulatory notices, see Regulatory information in the nRF9151 Product Specification. This DK is designed to allow the following: •... -
Page 37: Glossary
Glossary AT command A command used to control the modem. Band-Pass Filter (BPF) An electronic device or circuit that passes frequencies within a certain range and rejects frequencies outside that range. Cat-M1 LTE-M User Equipment (UE) category with a single RX antenna, specified in 3GPP Release 13. Cat-NB1 NB-IoT User Equipment (UE) category with 200 kHz UE bandwidth and a single RX antenna, specified in 3GPP Release 13. - Page 38 Nordic Semiconductor's platform for connecting IoT devices to the cloud, viewing and analyzing device message data, prototyping ideas that use Nordic Semiconductor chips, and more. It includes a public REST API that can be used for building IoT solutions. See nRF Cloud portal (nrfcloud.com).
- Page 39 A signal line in a serial interface that receives data from another device. Request to Send (RTS) In flow control, the transmitting end is ready and requesting the far end for a permission to transfer data. SAW filter A high-performing filter using Surface Acoustic Wave (SAW) technology. This technology employs piezoelectric transducers, which, when excited, produce waves that are used to filter out desired frequencies.
- Page 40 Any device used by an end-user to communicate. The UE consists of the Mobile Equipment (ME) and the Universal Integrated Circuit Card (UICC). U.FL An ultra-small surface-mount coaxial connector designed for high-frequency performance. Universal Serial Bus (USB) An industry standard that establishes specifications for cables and connectors and protocols for connection, communication, and power supply between computers, peripheral devices, and other computers.
-
Page 41: Recommended Reading
Recommended reading In addition to the information in this document, you might need to consult other documents. Nordic documentation • nRF9151 Product Specification • nRF Connect SDK documentation • nRF91x1 Cellular AT Commands • nRF Connect Programmer 4536_001... -
Page 42: Legal Notices
Nordic Semiconductor ASA customers using or selling these products for use in such applications do so at their own risk and agree to fully indemnify Nordic Semiconductor ASA for any damages resulting from such improper use or sale.
