- Page 1 AGD924 Pedestrian LED Wait Indicator PRODUCT MANUAL AGD924R LED Solutions AGD-SYSTEMS.COM...
-
Page 2: Installation
AGD924 INSTALLATION Pedestrian LED Wait Indicator Use existing M3 hole Note orientation Note logo orientation existing M3 hole Note Note logo orientation orientation The bracket (BR-230) and pcb (CB-277/CB-318) are 1. Identify existing bulb unit as Option 1-4 designed to cover a range of bulb wait housing options. 2. - Page 3 LED pcb and M3 Shk Proof 5. Refit the pcb to the bracket noting the orientation comprises: of the AGD logo on the pcb on the relevant diagram M3x6 Pan Head 6. Connect wiring per the table below ...
-
Page 4: Safety Precautions
AGD924 INTRODUCTION Pedestrian LED Wait Indicator SAFETY PRECAUTIONS Important note: Do not touch the surface of the LED’s. For maintenance purposes users should take particular care and avoid exposure to the high intensity LED light output. Although the LED’s are not laser devices they have a high brightness and thus to ensure maintenance engineer “eye-safety”, DO NOT LOOK DIRECTLY INTO THE LEDS when opening the unit or powering the pcb. - Page 5 Warranty All AGD products are covered by a 12 month return to factory warranty. Products falling outside this period may be returned to AGD Systems for evaluation, repair, update or re-calibration, any of which may be chargeable.
