THOR XRF24CFZ User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USE & CARE MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XRF24CFZ and is the answer not in the manual?

Questions and answers

Related Manuals for THOR XRF24CFZ

Summary of Contents for THOR XRF24CFZ

  • Page 1 USE & CARE MANUAL...
  • Page 2 USER MANUAL REFRIGERATOR Freezer : XRF24CFZ Refrigerator : XRF24CRF...

  • Page 3: Table Of Contents

    Table Of Contents 1 Important Instructions Regarding Safety and Environment----------------------------------------5 1.1 General Safety -------------------------------------------------------------------------------------------------5 1.2 Intended Use---------------------------------------------------------------------------------------------------7 1.3 Children's Safety----------------------------------------------------------------------------------------------- 7 1.4 Compliance with the WEEE Directive and Disposing the Waste Product-----------------------7 1.5 Compliance with the RoHS Directive----------------------------------------------------------------------8 1.6 Packaging Information----------------------------------------------------------------------------------------8 1.7 Hydrocarbon (HC) Warning----------------------------------------------------------------------------------8 1.8 For Products with a Water Dispenser/Ice Machine----------------------------------------------------9 2 Storage features--------------------------------------------------------------------------------------------------10...
  • Page 4 Please read this manual before using the product! Dear Valued Customer, We wish you to get the best results from your product that has been manufactured meticulously at modern plants and tested with detailed quality control checks. For this reason, we recommend that you read this user manual thoroughly before starting the product.

  • Page 5: Important Instructions Regarding Safety And Environment

    1 Important Instructions Regarding Safety and Environment This chapter contains safety information that will help you avoid the risk personal injury or property damage. Failure to follow these instructions shall render any product warranty void. 1.1 General Safety • This product can be used by children at age 8 and above and those people who have limited physical, sensory or mental capabilities and people who lack experience and information on the condition that they have been given the instructions about the safe use of the product,...
  • Page 6 1 Important Instructions Regarding Safety and Environment • Never use steam or steam cleaners to clean or defrost the refrigerator. Steam gets into contact with the live parts in your refrigerator, causing short circuit or electric shock! • " – Risk of fire or explosion. Flammable refrigerant used. Do not use DANGER mechanical devices to defrost refrigerator.

  • Page 7: Intended Use

    1 Important Instructions Regarding Safety and Environment 1.2 Intended Use • This product has been designed for domestic use. It is not suitable for commercial use and it must not be used out of its intended use. • It must be used only for storing food. •...

  • Page 8: Compliance With The Rohs Directive

    1 Important Instructions Regarding Safety and Environment 1.5 Compliance with the RoHS Directive: The unit you have purchased conforms to the EU RoHS Directive (2011/65/AB). It does not contain harmful or prohibited materials specified in the Directive. 1.6 Packaging Information •...

  • Page 9: For Products With A Water Dispenser/Ice Machine

    1 Important Instructions Regarding Safety and Environment If the product is damaged and if you see gas leak, please keep away from the gas. It may cause frostbite when it gets into contact with the skin. (including R134 Ignore this warning if the cooling system of your product contains R134a.

  • Page 10: Storage Features

    2 Storage features XRF24CFZ Shelving Soft close small Door bin Ice maker Soft close ice bin Soft close big bin Freezer components • Selectable shelf heights. Shelving • Heat treated safety glass.. • Ice maker Removable ice container. • (if applicable) Hygienic ice scoop.
  • Page 11 2 Storage features XRF24CRF Door bin Shelving Gallon bottle door bin Soft close small REF. TEMP. Door bin zone SPE. TEMP. zone Water Soft close big bin dispense Refrigerator components • Selectable shelf heights. Shelving • Heat treated safety glass. •...

  • Page 12: Display Panel

    3 Display Panel XRF24CFZ Serves to switch the whole appliance On and Off. Press the button to switch on the product, On/Off button the product will be switched on in 5 seconds. Press the on/off button for 1.5 seconds to switch off.
  • Page 13 3 Display Panel Press the MENU button till the holiday symbol illuminates, then press the SELECT button to enable the function. When the Holiday Mode function is enabled, freezer temperature set at 0° F (-18° C)automatically. Before leaving Holiday mode - Turn the ice maker to OFF on the control panel.
  • Page 14 3 Display Panel Press the MENU button till the Celsius and Fahrenheit Temperature selection symbol illuminates to change between Celsius unit and Fahrenheit. After that press the SELECT button to confirm. Press the MENU button till the show room symbol illuminates, then press the SELECT button to enable the function.
  • Page 15 3 Display Panel XRF24CRF Serves to switch the whole appliance On and Off. Press the button to switch on the product, On/Off button the product will be switched on in 5 seconds. Press the on/off button for 1.5 seconds to switch off. Press REF.
  • Page 16 3 Display Panel Press the MENU button till the holiday symbol illuminates, then press the SELECT button to enable the function. When the Holiday Mode function is enabled, Holiday mode the REF. TEMP and SEP.TEMP will be set at 63° F (17° C) automatically. NOTE: Do not place food in the fresh food compartment when Holiday Mode is enabled.
  • Page 17 3 Display Panel Press the MENU button till the show room symbol illuminates, then press the SELECT button to enable the function. This mode is used when the refrigerator is on display Show room in a retail store or if you want to turn the cooling off mode and deactivate all other functions except interior lighting.

  • Page 18: Before Using The Refrigerator

    4 Before Using the Refrigerator 4.1 Things to do for energy saving Connecting your refrigerator to systems that save energy is dangerous as they may cause damage on the product. • Do not leave the doors of your refrigerator open for a long time. •...

  • Page 19: Initial Use

    4 Before Using the Refrigerator 4.3 Initial use Before using the product, make sure that all preparations have been made in accordance with the instructions given in the "Important instructions regarding safety and environment" and "Installation Instruction" chapters. • Clean the interior of the refrigerator as recommended in the “Maintenance and cleaning”...

  • Page 20: Equipment

    5 Equipment Door bin To remove, lift up the door bin and then pull out straight. Glass shelves To remove a shelf - Fully open the corresponding door. - Hold the front of the shelf, and then gently lift up and slide out. To reinsert - hold the shelf at an angle so the front is higher than the back, and then insert the top hook into the top shelf notch.

  • Page 21: Bins

    5 Equipment Bins To remove the bin - Pull the bin until it stops. - Slightly unclip the front section of the bin and take it out completely. To install the bin - Pull the rails completely. - Place the gap at the rear corners of the bin to the detail located at the rear corners of the rails.

  • Page 22: Hinge Adjustment

    5 Equipment 5.5 Hinge Adjustment When adjusting the hardness of the hinge: Hardness of the lower and upper door hinges of the fresh food compartment is performed with the help of a drill. Set the hinge adjustment screw to position "1" from position "0". 5.6 Changing the Direction of the Door Please see the installation instructions provided in the bag.

  • Page 23: Care And Cleaning

    6 Care and Cleaning Service life of the product will extend and frequently encountered problems will decrease if the product is cleaned periodically. Never use gasoline, benzene or similar substances for cleaning purposes. Never use any sharp abrasive instruments, soap, household cleaners, detergent or wax polish for cleaning.

  • Page 24: Cleaning The Inner Surface

    6 Care and Cleaning 6.3 Cleaning the Inner Surface To clean the inner surfaces and all removable parts, wash them with a mild solution comprising soap, water and carbonate. Rinse and dry thoroughly. Prevent the water from contacting the lighting means and control panel. 6.4 Stainless Steel Outer Surfaces Use a stainless steel cleaning agent that is non- abrasive and apply it with a lint-free, soft cloth.

  • Page 25: Replacement Water Filter

    7 Replacement water filter 7.1 Water filter cartridge The water filter cartridge is located in the bottom part of the unit. Regarding as replace the filter cartridge The filter cartridge should be replaced every six months or earlier if 170 gallons of water has been dispensed or the flow of water to the dispenser or icemaker decreases.

  • Page 26: When After Replacing The Filter Cartridge

    7 Replacement water filter 7.3 When after replacing the filter cartridge In refrigerators, run 2 gallons of water to remove air from the system. A newly installed filter cartridge will cause water to spurt and dribble until the air is out of the system. In freezers, the icemaker may not immediately produce ice.

  • Page 27: Trouble Shooting

    8 Trouble Shooting Please review this list before calling the service. This will save you time and money. This list contains frequently encountered problems that are not results of faulty workmanship or material use. Your product may not have some of the features described here. The refrigerator is not operating.
  • Page 28 8 Trouble Shooting • The floor may not be stable or level. The operation noise increases when the refrigerator is running. Operating performance of the refrigerator may vary based on the ambient temperature changes. This is normal and not a fault. Vibration or noise.
  • Page 29 8 Trouble Shooting There is a bad odour inside the refrigerator. • No regular cleaning may have been performed. >>>Clean the inside of the refrigerator sponge, lukewarm water or carbonated water. • Some vessels or packaging materials may cause the odour. >>>Use another vessel, or packaging materials from another brand.

  • Page 30: Warranty And Service

    9 Warranty And Service Warranty and Service This product has been manufactured by Thor International, 4651 E Airport Drive, California 91761. For Customer Service, please call (877) 288 - 8099 For the most up to date warranty and service policy, please refer to our website WWW.THORKITCHEN.COM/WARRANTY-REGISTRATION...

  • Page 31: Warranty Registration

    WELCOME TO THE CLUB You chose THOR Kitchen to enhance your culinary journey and we’re stoked to have you in the club. Think of it as a secret society of really savvy people, such as yourself, choosing professional power and performance at an affordable price.

This manual is also suitable for:

Xrf24crfXrf24crf-ssXrf24cfz-ss
