Model No. NTL17915.1 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.nordictrackservice.com/ registration. CUSTOMER CARE For service at any time, go to www.nordictrackservice.com.
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
Page 4
19. Always stand on the foot rails when starting able to safely lift 45 lbs. (20 kg) to move the or stopping the walking belt. Always hold the treadmill. handrails while using the treadmill. 25. When folding or moving the treadmill, make 20.
BEFORE YOU BEGIN Thank you for selecting the new NORDICTRACK ® manual. To help us assist you, note the product model T 6.5 S treadmill. The T 6.5 S treadmill provides an number and serial number before contacting us. The impressive selection of features designed to make your model number and the location of the serial number workouts at home more effective and enjoyable.
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 7. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you fi...
Page 9
2. Make sure that the power cord is unplugged. Wire Press a Base Cap (74) into each side of the Base (6). Identify the Right Upright (90). Have a second person hold the Right Upright near the Base (6). See the inset drawing. Tie the wire tie in the Right Upright (90) securely around the end of the Upright Wire (81).
Page 10
4. Hold the Right Upright (90) against the Base (6). Be careful not to pinch the wires. Partially tighten three 3/8" x 4" Screws (7) with three 3/8" Star Washers (13) into the Right Upright and the Base; do not fully tighten the Screws yet. Attach the Left Upright (not shown) in the same way.
Page 11
6. Identify the Right Handrail (84). Attach the Right Handrail (84) to the Right Upright (90) with two 5/16" x 3" Screws (28) and two 5/16" Star Washers (11); start both Screws, and then tighten them. Make sure not to pinch the Upright Wire (81).
Page 12
8. If there are four screws (C) preattached inside the Handrails (84, 85), remove and discard the screws. IMPORTANT: To avoid damaging the Pulse Crossbar (93), do not use power tools and do not overtighten the #10 x 1 1/4" Screws (9). Orient the Pulse Crossbar (93) as shown.
Page 13
10. Set the console assembly on the Right and Left Handrails (84, 85). Make sure that no wires Console Assembly are pinched. Insert the excess Upright Wire (81) into the Right Upright (90). Attach the console assembly to the brackets on the Handrails (84, 85) with four 1/4"...
Page 14
12. Attach the Right and Left Trays (27, 36) with four #8 x 1/2" Screws (1). 13. Raise the Frame (56) to the upright position. Have a second person hold the Frame until step 15 is completed. Orient the Latch Crossbar (41) as shown. Make Brackets sure that the “This side toward belt”...
Page 15
14. Remove the 5/16" Nut (34) and the 5/16" x 1 3/4" Bolt (62) from the bracket on the Base (6). Orient the Storage Latch (26) so that the decals are facing away from the treadmill as shown. Next, orient the Storage Latch (26) as shown. Attach the lower end of the Storage Latch (26) to the bracket on the Base (6) with the 5/16"...
Page 16
16. Firmly tighten all six 3/8" x 4" Screws (7). Then, slide the Left and Right Base Covers (82, 83) downward. 17. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic on the treadmill decals, remove the plastic.
HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD nominal 120-volt circuit capable of carrying 15 or more amps. To avoid overloading the circuit, do Use a Surge Suppressor not plug other electrical devices, except for low- power devices such as cell phone chargers, into Your treadmill, like other electronic equipment, can be the surge suppressor or into an outlet on the same damaged by sudden voltage changes in your home’s...
CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s sound system while you The treadmill console offers an impressive array of exercise. features designed to make your workouts more effec- tive and enjoyable.
HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
Page 20
5. Follow your progress with the displays. 6. Measure your heart rate if desired. When the manual Before using mode is selected, the hand- the upper half of grip heart the display will rate monitor, show a track that remove the Track represents 1/4 sheets of plas-...
Page 21
HOW TO USE AN ONBOARD WORKOUT At the end of each segment, a series of tones will sound. If a new speed and/or incline setting is 1. Insert the key into the console. programmed for the next segment, the new speed and/or incline setting will flash in the displays for a See HOW TO TURN ON THE POWER on few seconds.
Page 22
HOW TO USE A SET-A-GOAL WORKOUT HOW TO USE AN IFIT WORKOUT 1. Insert the key into the console. Note: To use an iFit workout, you must have an optional iFit module. To purchase an iFit module at See HOW TO TURN ON THE POWER on page 19. any time, go to www.iFit.com or call the telephone number on the front cover of this manual.
For more information about the iFit workouts, During a competition workout, the console will please see www.iFit.com. show your progress in the race. As you race, the top line in the matrix will show how much of the When you select an iFit workout, the display will race you have completed.
Page 24
2. Select the optional screens. DEFAULT MENU—The default menu will appear when you insert the key into the console or when While the settings mode is selected, the matrix you press the Home button. Press the Enter button will display several optional screens. Press the repeatedly to select the manual main screen or the decrease button next to the Enter button to select iFit screen as the default menu.
Page 25
HOW TO USE THE SOUND SYSTEM HOW TO ADJUST THE CUSHIONING SYSTEM To play music or audio books through the console The treadmill features a cushioning system that sound system while you exercise, plug a 3.5 mm male reduces the impact as you walk or run on the treadmill. to 3.5 mm male audio cable (not included) into the jack on the console and into a jack on your MP3 player, Remove the key from the console and unplug the...
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE SYMPTOM: The power turns off during use Regular maintenance is important for optimal per- a. Check the power switch (see drawing c at the left). formance and to reduce wear. Inspect and properly If the switch has tripped, wait for five minutes and tighten all parts each time the treadmill is used.
Page 28
Next, locate the Reed Switch (52) and the Magnet SYMPTOM: The walking belt slows when walked on (50) on the left side of the Pulley (49). Turn the Pulley until the Magnet is aligned with the Reed a. Use only a surge suppressor that meets all of the Switch.
Page 29
d. If the walking belt still slows when walked on, see b. If the walking belt slips when walked on, fi rst the front cover of this manual. remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller SYMPTOM: The walking belt is off-center or slips screws clockwise, 1/4 of a turn.
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
PART LIST Model No. NTL17915.1 R1215A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Screw Drive Roller/Pulley #8 x 3/4" Screw Magnet Base Pad Reed Switch Clip 1/4" x 1/2" Screw Reed Switch #10 Star Washer 1/4" x 1 1/2" Screw...
