Roland VIDEOCanvas V-5 Owner's Manual

Roland VIDEOCanvas V-5 Owner's Manual

Video mix/title processor
Hide thumbs

Advertisement

Quick Links

Download this manual
Before using this unit, carefully read the sections entitled: "IMPORTANT SAFETY
INSTRUCTIONS" (p. 2), "USING THE UNIT SAFELY" (p. 3), and "IMPORTANT
NOTES" (p. 4). These sections provide important information concerning the proper
operation of the unit. Additionally, in order to feel assured that you have gained a
good grasp of every feature provided by your new unit, this manual should be read
in its entirety. The manual should be saved and kept on hand as a convenient refer-
ence.
The Roland V-5 NTSC is designed for use exclusively with NTSC (National
Television System Committee) standard video signals. The Roland V-5 PAL can
likewise only be used with PAL (phase-alternation by line) standard video signals.
MIC
AUX
PHONES
0
10
0
10
0
GPI OUT
GPI / MIDI IN
VIDEO
AUX
1
2
STROBE
STILL
SOLARIZE
COLORIZE
CENTER
MONO
SEPIA
NEGA
USER 1
USER 2
USER 3
USER 4
VIDEO 1
VIDEO 2
PC
AUX INS
AUX MIX
PRE START
AUDIO FOLLOW
NORMAL
COLOR INSERT
EFFECT 1
EFFECT 2
MAIN
MAIN
+SUB
WHITE / BLACK
AUTO FADE
Copyright © 1998
All rights reserved. No part of this publication may be reproduced in any form with-
out the written permission of ROLAND CORPORATION.
Owner's Manual
10
TOTAL
CURSOR
VALUE
TAP
P in P
PICTURE/TITLE
WIPE
PGM
MIX
TITLE IN
TITLE OUT
ROLAND CORPORATION
1
2
3
4
5
6
7
8
GROUP
A
B
REVERSE
ONE-WAY
SETUP
UTILITY
EXIT / NO
ENTER / YES
WHITE LUMI
BLACK LUMI
CHROMA
COLOR
CAPTURE
COLOR
GROUP
FILES
