Northcom ProEquip PRO-BT570 User Manual

User's Manual – Wireless Speaker Mic
Model: PRO-BT570
Wireless Speaker Mic. , Heavy Duty, Rechargeable
Battery Powered, IP55, 3.5mm earpiece port
Art Nr. 30590
⚫
Product Overview:
No. Function No. Function
1 PTT 7 Status LED
2 Volume up 8 Function button
3 Volume down 9 Torch ON/OFF
4 Torch light LED 10 External earphone jack
5 Speaker / Microphone 11 Micro USB charging port
6 Power ON/OFF 12 Belt clip
⚫
Package contents:
⚫
Bluetooth speaker microphone
⚫
USB charging cable
⚫
User's Manual
⚫
Operation:
⚫
Power ON: Press power ON/OFF button
sound is heard and status LED
⑦
flashing blue.
⚫
Power OFF: Press power ON/OFF button
seconds until "Power off" sound is heard and status LED
flashes purple once.
⚫
Function Button: When the device is paired with a phone,
Function button can be used to answer/end/reject calls,
⑧
answer a waiting call, switch between active calls, and dial the
last called number.
⚫
Torch light LED: Power ON device, press torch ON/OFF
button for approx. 1 second to turn on torch light LED
⑨
Press and hold for 2 seconds to turn off.
⚫
Volume control: Press volume up
adjust volume. The device will produce a tone when volume
reaches the minimum or maximum level.
⚫
External earphone: Open external earphone jack
cover, plugging in a listen-only earphone with Ø3.5 2-pole or
3-pole connector will automatically mute the loudspeaker
⚫
Status LED:
Status LED Indicator
Power ON Flashes Purple once, followed by flashing Blue
Charging Solid Red
Charge complete Solid Blue
Low battery Flashes Red during power ON or after RX/TX
Pairing mode Alternating Red and Blue flash
Connection Flashes Blue once every 5 seconds
Unpaired or lost Flashes Blue twice every 3 seconds
link
⚫
Pairing Process for radio / phone
1. Make sure the microphone is OFF, press & hold power button
power ON the Bluetooth microphone.
2. The microphone is in pairing mode when the LED
between Red and Blue flash, and "Pairing" sound is heard.
3. Enter the Bluetooth menu on your radio / phone.
4. Find the device name "BTW-XXXX" under Bluetooth device list and
connect it. (XXXX generated via MAC ID)
5. Pairing process is completed.
⚫
General specification:
, "Power on"
⑥ Speaker
indicates purple, followed by
Microphone
Protection grade
, hold for 2
⑥
PTT key life
⑦
Talking Range
Battery
Charging time
Operation temp.
Operation time
⚫
Troubleshooting:
④.
or down button to
② ③
Does not power ON
Cannot charge
dust
⑩
⑤
Battery not holding
charge
Pairing issue
RX / TX issue
Unclear speech
⚫
Special features:
⚫
to
⑥
⑦ alternates
Ø36mm 8Ω 1W 89±3dB @1KHz (0.5m 1W)
-44±2dB@1KHz 0dB=1V/Pa
IP55 (dust cover properly closed)
≥1,000,000 Times
Bluetooth class 2, 10 meters
1500mAH Li-battery
About 3 hours (5V 500mA)
-20~50°C (-4~120°F)
>36 hours (TX:RX:Standby=5:5:90)
Check if device is charged
Check connections to the device and wall outlet.
Check if the device's charging contacts are in
contact with optional desktop charging cradle.
Check if charging status LED ⑦ is on (RED)
Check if battery is fully charged.
Battery has a definite service life; replace the
battery when it can't provide sufficient
operational time even when it's fully charged.
Contact dealer to replace battery.
Cannot find device, power off radio/phone for 5
seconds, restart and search again for device
Check Bluetooth connection and pairing.
Check if water is trapped in speaker grille, shake
mildly to get water out the speaker grille
RESET – Reset to factory default by holding volume up and
function button for 5 second until tone sound is heard, then
restart the device.
⑤.
