- Page 1 Manual Canopy Installation Guide...
-
Page 2: Table Of Contents
Mounting the Drive Beam – Supplementary Notes Mounting the Drive Beam – Quality Inspection Step 2: Attaching the Canopy Step 3: Positioning the Stabilizers Step 4: Securing the Stabilizers Post-installation Considerations Winter Storage Wind Improper Use Lubricants Cleaning ShadeFX Installation Guide... -
Page 3: Introduction
Introduction Objective To provide clear and concise installation steps for your ShadeFX retractable canopy. Installing the canopy in accordance with this guide will ensure a successful deployment of your system. About the Product ShadeFX retractable canopies are available in three drive options: 1. -
Page 4: The Importance Of Proper Installation
ShadeFX retractable canopies can weigh more than 100lbs depending on size and drive type. The structure that the ShadeFX retractable canopy will be mounted to must be capable of supporting the weight load of the system. Before installation, identify the material of the structure. Depending on material type, certain tools (drills, drill bit, etc.) may be required to ensure the canopy is adequately secured to the structure. -
Page 5: Pre-Installation
The pre-installation section is intended to educate the installer of the various components of the system, recommended tools, and applicable hardware. Every ShadeFX retractable canopy will include a drive beam, canopy, and hardware. Stabilizers can either be purchased directly from ShadeFX or made on-site from a material that matches the structure (wood, steel, aluminum, etc.). -
Page 6: Recommended Tools And Hardware
• Chalk line or string line Hardware Each canopy drive option is made up of differing hardware kits. The items listed below will be included for a manual canopy. Quantity of hardware will vary with canopy size. Mounting Screws (Steel Structure) Mounting Screws (Wood Structure) -
Page 7: Installation
The following installation instructions are intended to assist with the installation of a manual canopy and should not be used as a guide to install rope or motor canopies. Please contact ShadeFX should you require installation instructions for a rope or motor canopy. - Page 8 If mounting to perpendicular rafters, mark and pre-drill two staggered 3/16” holes at every rafter location relative to the drive beam. Refer to Figure 1C Figure 1C _________________________________________________________________________________________________ 24” Spacing Front Rear Chalk Line Staggered Holes ShadeFX Installation Guide...
-
Page 9: Mounting The Drive Beam - Supplementary Notes
2” to the right, the drive beam will be installed 2” to the right of the center point of the structure. Factoring the offset, follow the same procedures as outlined in Step 1A. Refer to Figure 1E to see illustration of offset. Figure 1E _________________________________________________________________________________________________ Canopy Front Box Frame Centerline Right Side Left Side Canopy Rear ShadeFX Installation Guide... -
Page 10: Mounting The Drive Beam - Quality Inspection
Step 2, answer the following questionnaire to ensure the drive beam is appropriately mounted. • Is the drive beam level across its entire span? Refer to Figure Q1 Figure Q1 _________________________________________________________________________________________________ Perpendicular to Rafters Parallel to Rafters Shim Rafters as Needed ShadeFX Installation Guide... - Page 11 Left Side Right Side Centerline Chalk Lines Canopy Rear Curved Drive Beam Misaligned Drive Beam Canopy Front Canopy Front Left Side Right Side Left Side Right Side Chalk Lines Chalk Lines Centerline Centerline Canopy Rear Canopy Rear ShadeFX Installation Guide...
-
Page 12: Step 2: Attaching The Canopy
1. Raise wing into carrier assembly 2. Align hole in wing with hole in carrier assembly. Once holes are aligned, insert the G-Clip 3. Rotate the G-Clip downward to lock into position 4. Secured wing to carrier assembly ShadeFX Installation Guide... -
Page 13: Step 3: Positioning The Stabilizers
A flat orientation will deflect rain from the center of the canopy to both sides. Allow the canopy to rest in its natural position. Refer to Table 3A to determine deflection values. If you have received deflection values directly from ShadeFX for your system, please use those values. Table 3A Flat orientation deflections... - Page 14 A tilted orientation will help deflect rain to one side of the canopy. Allow the canopy to rest in its natural position. Refer to Table 3B to determine deflection values. If you have received deflection values directly from ShadeFX for your system, please use those values. Table 3B...
-
Page 15: Step 4: Securing The Stabilizers
Extend and retract the canopy a couple of times to ensure enough downward pressure is present to keep the system in place without creating unnecessary tension. Make any necessary adjustments to address downward pressure and tension and proceed to permanently secure the stabilizers every 24”. ShadeFX Installation Guide... -
Page 16: Post-Installation Considerations
Improper Uses of the Product Do not hang objects such as lights, fans, heater, etc. from any part of the ShadeFX canopy or drive beam. When operating a manual drive canopy, do not pull sideways (perpendicular to the drive beam) or downward with the handle. -
Page 17: Cleaning
If stubborn stains persist, you may use a diluted bleach/soap mixture for spot cleaning of mildew. For roof run-off or other similar stains, a strong degreaser may be required. Our fabric manufacturer provides a stain chart for specific recommendations. Refer to the URL below. https://global.sunbrella.com/en-us/how-to-clean ShadeFX Installation Guide... - Page 18 855-509-5509...
