Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
Cascais Industrial
Bench
REV - 10/2023
Assembly Instructions
support@grainwoodfurniture.com
Model #
CA6008
Top
CA6010
CA6015
CA7208
Industrial
CA7210
Base
CA7215
Made in Brazil
1-person assembly
Finish
Blonde Oak
Brown Oak
Black Oak
Blonde Oak
Brown Oak
Black Oak
page 1/7
Advertisement
Related Manuals for GrainWood Cascais Industrial CA7208
Summary of Contents for GrainWood Cascais Industrial CA7208
- Page 1 Assembly Instructions 1-person assembly Model # Finish CA6008 Blonde Oak CA6010 Brown Oak CA6015 Black Oak CA7208 Blonde Oak Industrial CA7210 Brown Oak Base CA7215 Black Oak Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or support@grainwoodfurniture.com...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
- Page 3 BOX 1 BOX 2 Description Qty. Description Qty. Part # Part # Legs Upper Crosspiece Lower Crosspiece Center Crosspiece Hardware page 3/7...
- Page 4 HARDWARE LIST 1/4x60 1/4x40 Ø20X7 50x50 ATTENTION Before starting assembly please verify the hardware set is complete. For missing hardware please contact us at grainwoodfurniture.com/help WARNING: CHOKING HAZARD Small parts, not for children. To be assembled by an adult. page 4/7...
- Page 5 Tip: Use a rug or cardboard for floor protection. This side Larger holes facing inward Larger holes facing outward This side down floor Repeat step 2 for both legs. 1/4x40 50x50 page 5/7...
- Page 6 1/4x60 1/4x40 page 6/7...
- Page 7 Tip: Use a rubber mallet or a piece of wood to protect the finish when hammering the wood cap. The wood caps should be flush with the post surface Ø20X7 page 7/7...
