Summary of Contents for Skinact 24571
- Page 1 CO2 Fractional Laser (SKU24571) USER MANUAL www.skinact.com Toll Free: 1.800.418.0830 International: 818.834.6640 www.spaandequipment.com...
- Page 2 Spa and Equipment/SkinAct shall not be liable for inci- dental or consequential damages arising out of the fur- nishing, performance, or use of this document and the program material which it describes.
-
Page 3: After Operation
This manual contains important information on the use and operation of this machine. Please read all the information carefully for optimal performance to prevent any damage or misuse of the machine. Any change or modification not expressly approved in this manual could void the warranty for this equipment. - Page 4 Fractional technology is a benchmark for efficiency and comfort in laser resurfacing procedures. Fractional resurfacing consists in the emission of tiny laser energy beams which penetrate into the skin in the form of thermal columns all the way to the dermis while leaving untreated tissue in-between them. Laser energy is deposited into the tissue with a pattern of random shots which alternate areas treated by laser with those of intact skin.
- Page 5 Skin renewal Smooth scars, such as Eliminate wrinkles; repaving, especially surgical scars, burned Skin tightening. recovery from scars, acne scars, etc. damage. Eliminate pigments, Vaginal stretching; Acne treatment, such intractable Vaginal whitening; chloasmas, age spots, Restore your beauty Urinary incontinence etc.
- Page 6 Fractional mode (aesthetic), pulse mode (surgery), Gynae mode (gynecology), 3 treatment modes can meet all the needs of beautician, plastic surgeon, gynecologist. South Korea imported 7-articulated arms with good quality lenses. Germany imported Mini-Stepper-Motors with the best quality makes the laser shoot faster and the energy more uniform and stable.
- Page 7 Picture Description Quantity Articulated arm Fractional head Treatment head (Gynae mode) Treatment head (Fractional mode) Treatment head (Pulse mode) Clips Foot pedal Protective glasses Protective goggles Power line Chain safeguard + Keys - 6 -...
- Page 8 Install articulated arm: Install treatment head of fractional mode: - 7 -...
- Page 9 Install treatment head of pulse mode: Install treatment head of gynae mode: Vaginal probe 1 for inner vagina - 8 -...
- Page 10 Vaginal probe 2 for uroclepsia Vaginal probe 3 for vulva Connect the power line: - 9 -...
- Page 11 Connect the chain safeguard: Connect foot pedal: - 10 -...
- Page 12 It is necessary that users should read the manual carefully prior to the application of this machine. Consult whether the client has the above contraindications. Pre-operative agreement signed, photographed and filed It is suggested that this machine is operated in a separated room. ...
- Page 13 Main interface 3. Click “FRACTIONAL MODE” to enter into the treatment interface: corresponding Fractional mode interface Choose scan graphic: “Round”, “Hexagon”, “ Rectangle” or “Triangle” optional according to the shape of treatment area. Adjust parameters from low to high depending on the size of treatment area and the feeling of patient. ...
- Page 14 There are FIVE groups of common parameters optional, you can edit and save. Choose scanning mode: “Order”, “Center” or “Random” Click “Preview” to make this machine emit a red laser. Put on protective goggles for the operator and patient to protect their eyes from the laser. ...
- Page 15 There are FIVE groups of common parameters optional, you can edit and save. Put on protective goggles for the operator and patient to protect their eyes from the laser. Press “READY”,and the machine will start. Place the treatment head firmly on the private parts and then trample the foot pedal. After scanning, release the ...
- Page 16 Put on goggles for the operator and patient to protect their eyes from the laser. Press “READY”, and the machine will start. Hold the treatment head close to the skin tissue needed to be cut, trample the foot pedal and move along the ...
- Page 17 1. Depressed scars, pigmented nevi, granulomas, scars: The wound will show varying degrees of redness, blistering, oozing, bleeding and crusting for 1 to 2 days after surgery. The scab will fall off naturally in about 1 to 2 weeks and should not be removed early to avoid unevenness or scarring of the skin after healing.
- Page 18 Fractional mode Power Pulse width Distance Energy Times Interval Sessions Applications (ms) (mm) (mj) (th) (month) (th) Acne Scars 7-10 17.5 Skin Rejuvenation 12.5 Wrinkle Removal 7-10 17.5 Pore expansion 12.5 Scar Removal 10-15 17.5 Hormonal Dermatitis 12.5 Gynae mode Power Pulse width Distance...
- Page 19 To protect personal safety of operator and patient, this machine adopts an excellent design and production plan, despite of which the energy output of laser may also cause serious harm like burn, blindness, fire and explosion if the operation is carried out by inexpert persons.
- Page 20 Put the machine on the flat and stable surface. Check the main machine, accessory and the power cable are intact well before use. The machine is fragile. Do not drop it. Clean the equipment with a wet cloth but make sure no liquid penetrates. ...
- Page 21 Problem Possible cause Solution Check the plug It is not plugged correctly Check the power cable The power cable is not well connected Press the power button The machine does not The power button is off Change the fuse The fuse is damaged start Contact the technical service The electrical circuit is damaged...
