Summary of Contents for RED ROOSTER RRI-BA70S4
- Page 1 RRI-BA70S4 Manual www.rami-yokota.com...
- Page 2 Before taking into use Read and understand the contents of this manual before installing, operating, repairing, maintaining, changing accessories of this tool. Only qualified and trained operators should install, adjust or use the tool. Charging the battery Slide the battery in the charger, this should go smoothly otherwise the alignment isn't correct or the battery / charger grooves are damaged.
- Page 3 Removing the battery:...
- Page 4 Battery charger Lamp Indication: Do not ignore safety precautions! Safety Do not modify this tool in any way, this can cause danger for the operator. Make sure that this manual is accessible at all times for any relevant person, in case of loss of this manual ask your dealer for a new copy or refer to our website.
- Page 5 Always wear safety glasses during operation of the tool. The grade of protection must be in relation to the risk of the operation. Rotating mounted accessories can be easily entangled by rubber coated or metal reinforced gloves. Wear suitable gloves. Keep fingers out of reach of the inserted tool or accessory.
- Page 6 A risk assessment related to the vibration exposure to determine the maximum working hours per day for the operator. Vibration can cause damage to blood vanes and nerves (white finger disease). Hold the tool with light but safe grip, higher grip force can increase vibration effects. Battery Safety Do not disassemble or modify the battery pack and battery charger, doing so may result in heat generation, fire, electric shock, or injury.
- Page 7 Be sure to use the provided power supply cord. Use of other power supply cord may cause malfunction, heat generation, or fire. Be sure to fully insert the power plug. Failure to do so may result in electric shock or fire due to heat generation. If you do not use the product, unplug from the receptacle.
- Page 8 Torque adjustment. Remove the battery before adjusting. Pistol model: open the cover. Insert the adjust wrench in the shaft and rotate the shaft until the adjust hole is seen. Push the adjust wrench in the hole and rotate the adjust wrench. Angle model: open the cover.
- Page 9 LED indicator and beeper on the tool shows the following status: Status of the LED indicator and beeper Status of the tool Action to be taken Light up in red, yellow and green together for one scond. The motor is switched on A long beep for one second.
- Page 10 Warranty covers material or construction mistakes of the manufacturer, which are clearly definable. Replacement of parts or repair by an official Yokota/Red Rooster service workshop is free of charge, when the tool is covered by warranty. Freight or postage is for the account of the buyer. Damage attributable to a normal wear, overloading or incorrect use is excluded from warranty.
- Page 11 Declaration of Conformity Brand: RedRoosterIndustrial Product: Type: RRI-BA70S4 Capacity: WE, RAMI YOKOTA B.V. , hereby declare that this product is conform the European Directive 2006/42/EG and, the standard EN ISO 11148-6 Technical file available from Rami Yokota BV: RAMI YOKOTA BV...
- Page 12 www.rami-yokota.com...
