Stylish MODENA K-131R Installation Manual

Shut off Flush hot and cold
water supply water supply lines
1
C
B
A
Remove the mounting
nut (A) and washer (B) from the
threaded shroud (C)
Remove RO Connector (D)
5
Secure weight on lowest vertical
point on pull-out hose side.
(not on quick connect side).
CARE AND CLEANING
Clean the faucet frequently using mild soap or an on-abrasive
cleaner and then quickly rinse with water and dry with soft cloth
only.
Using abrasive cleaners, solvents, acid cleaners or any scrubbing
detergent, polisher or scraper will damage the finish and void the
warranty.
Stylish International Inc.
Products and specifications shown are subject to change without notice. Please contact our technical support at care@stylishkb.com for any further queries, replacement parts requests, etc. ©2021 Stylish ® all right reserved.
BEFORE YOU BEGIN YOUR INSTALLATION
Required tools
FAUCET INSTALLATION
2
CUT-OUT HOLE
Ø35mm
Ø35mm
D
Ensure there is a Ø35mm
through-hole on the kitchen
counter.
Position faucet on the installation
surface. Fit flexible hoses through
hole on countertop or sink.
6
Before connecting supply hose,
flush supply valves to clear any
debris. Place a bucket under-
neath valves and run water for 5
to 10 seconds. Turn water off.
Follow us on Instagram! Check out and let us know your comments
MODENA
KITCHEN AND WATER FILTER FAUCET
Installation by License Flush the water pipe
Professional Plumber before installation
3
Position faucet on the installation
surface. Fit flexible hoses through
hole on countertop or sink.
Slide washer and thread the
mounting nut onto threaded
shroud. Turn faucet to desired
handle position. Securely tighten
clamp screws (E).
7
Connect hot and cold water
lines to the inlet pipe and tighten
with a wrench until snug.
Do not over tight.
For additional technical assistance or for
any questions or concerns about your
kitchen faucet's warranty, please contact
us.
www.stylishkb.com/warranty
K-131R
Drawings are for
reference only
4
E
C
(A) Attach RO Connector to
inlet port.
(B) Connect pullout hose to
quick connect.
(C) Insert weight (loose install).
8
Unscrew spray head by hand.
Hold the tip of the spray hose
down and turn on the faucet
and let the water run 60 seconds
to flush any debris,
the re-connect spray head.
Ensure gasket is present.
WARRANTY
www.stylishkb.com
care@stylishkb.com
+1-855-789-5352
TOLL
TOLL
FREE
FREE
stylish.international.inc
Do not disassemble
the body
A
Reverse osmosis
filter installation
B
