CONVERTER ProtoPixel-to-DALI and ProtoPixel-to-0/1÷10V
●
Input: 230 Vac @50/60 Hz
●
Remote control: ProtoPixel App
●
Local Control: N.O. Push Button
●
Signal converter from ProtoPixel to DALI
●
Signal converter from ProtoPixel to 0/1-10V
●
Possibility to control DALI or 0/1-10V devices via the ProtoPixel App
●
Provides power supply to the DALI bus
●
Extended temperature range
●
100% Functional test
●
PRODUCT DESCRIPTION
SLIM-PPX-DALI is a protocol converter and can be used as ProtoPixel to DALI or ProtoPixel to 0/1-10V signal converter. The device
receives a command signal from the ProtoPixel App
10V analog command. SLIM-PPX-DALI can be controlled remotely via ProtoPixel App
pushbutton.
The ProtoPixel App
©
can be downloaded free of charge from the Apple App Store (iOS 16 or later) and the Google Play Store
(Android OS 11 or later).
⇢ For the most up-to-date manual, please visit our website
⇢ For the correct functioning of the ProtoPixel App
https://www.protopixel.io/solutions/products
DALCNET S.r.l.
36077 Altavilla Vicentina (VI) – Italy
Via Lago di Garda, 22
SLIM-PPX-DALI
Device Manual
©
(WiFi and Bluetooth)
©
and converts it into a DALI (DT6 and DT8) digital commando or 0-10V or 1-
www.dalcnet.com
©
, visit the Protopixel website:
©
©
or locally via N.O. (Normally Open)
or scan the QR Code.
www.dalcnet.com
Made in Italy
Phone +39 0444 1836680
–
info@dalcnet.com
Rev. 18/02/2025 - Pg.1/10
Advertisement
Table of Contents
Summary of Contents for DALCNET SLIM-PPX-DALI
- Page 1 100% Functional test ● PRODUCT DESCRIPTION SLIM-PPX-DALI is a protocol converter and can be used as ProtoPixel to DALI or ProtoPixel to 0/1-10V signal converter. The device receives a command signal from the ProtoPixel App © and converts it into a DALI (DT6 and DT8) digital commando or 0-10V or 1- 10V analog command.
-
Page 2: Product Code
Over Voltage Protection AC IN Table 2: Detection and Protection functionalities REFERENCE STANDARDS SLIM-PPX-DALI follows the regulations shown in the table below. STANDARD TITLE EN 55015 Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar... -
Page 3: Technical Specifications
SLIM-PPX-DALI Device Manual Made in Italy TECHNICAL SPECIFICATIONS Values Unit of Description Name Note Measure INPUT (AC IN) Nominal Supply Voltage Supply Voltage range ÷ IN-RNG Mains frequency MAINS Nominal power @230V Maximum Standby power absorption < 0.5 STBY OUTPUT (DALI) -
Page 4: Wiring Diagram
SLIM-PPX-DALI can control remotely other devices via DALI digital bus by a simple two-wire cable (untwisted and unshielded). The control is conducted by SLIM-PPX-DALI, which provides commands to the devices in the DALI network and, if necessary, power supply to the network itself. - Page 5 IRING SLIM-PPX-DALI can be powered by 230 Vac @ 50Hz mains voltag. Once the 0/1-10V signal and remote control (DALI bus) are connected, connect the AC power supply respecting the Live (L) and Neutral (N) conventions to the "L" and "N" terminals of the AC IN terminal.
-
Page 6: Mechanical Dimensions
8-bit channels, whose values can be set in the range (0 ÷ 254), each of which stands for a light characteristic (e.g. brightness, colour, temperature, etc.). SLIM-PPX-DALI supports both DT8 and DT6 profiles to provide adjustment of all light parameters allowed by the protocol. -
Page 7: Technical Notes
During installation, it is recommended to reserve adequate space around the device to facilitate its accessibility in case of future maintenance or updates (e.g. via smartphone). The SLIM-PPX-DALI has an integrated DALI power supply. Before connecting the SLIM-PPX-DALI to a DALI line, please make sure that no other DALI Power Supply is powering the bus. -
Page 8: Legal Notes
ERMS OF Dalcnet Srl (hereinafter referred to as "the Company") reserves the right to make changes to this device, in whole or in part, without prior notice to the customer. Such changes may affect technical aspects, functionality, design, or any other element of the device. The company is not required to notify you of such changes and that your continued use of the device will constitute your acceptance of the changes. - Page 9 Made in Italy PROTOPIXEL APP ProtoPixel App © is the official mobile app through which it is possible to configure, in addition to the functions of the SLIM-PPX-DALI, also all the different ProtoPixel © products. ProtoPixel App © can be downloaded free of charge from the Apple App Store and Google Play Store.
- Page 10 Dalcnet DALI Slim. Once you spot nearby Dalcnet Slim Devices, tap one to identify it. The physical device will blink, helping you pinpoint it before connecting to your WiFi network. Then you can start adding all the elements you need to your new installation. After you added all the luminaires, you'll land on the main screen of your new installation.
