STEP 17
Assure that our unit is square.
Distance from corner to corner
must be equal as shown.
systembuild.com
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT
5
AND MUST BE INSTALLED PROPERLY.
Carefully turn your unit on its front side.
Attached the back panel as shown nailing straight into the raw edges.
(x42)
I
raw
surface
B
24
5
F
Flush bottom edge of the
back panel with the bottom
edge of bottom (F).
You
Tube
