akubela SL50 Installation Manual

Smart Lock SL50 Installation Guide
Before installation, be sure to read and fully understand all instructions.
Step 1 Reverse the latch bolt
If the latch bolt needs adjustment for the door's opening direction:
1. Position the mortise lock upright with the latch facing upward.
2. Follow these instructions shown in the figure:
Push the stopper to the right.
1
Allow the latch bolt pop out, and rotate it 180° to reverse.
2
Press the latch bolt back into place.
3
Step 2 Disassemble back body
Disassemble the back body of the lock into the following components:
 Rubber plugs
 Screen (Press the center bottom and push upward to remove)
 Screws
 Main body
 Rear mounting plate
NOTE: This end must be lower than the
latch plate when reversing the latch bolt.
1
