Manual for EPI7684, the wireless food probe system
1
General
The wireless food probe system consists of the radio module (EPI7684), antenna system and the wireless
food probe. This system enables the roasting process of the food to be monitored simple and reliably. The
wireless food probe will be here not described because it is a passive device and does not matter for the
installation of the system.
The wireless food probe system may be installed in the Miele domestic appliances like ovens or steam
cooker (host devices)
Integration instruction
The EPI7684 and the loop antenna must be integrated under consideration of the technical data. It is not
allowed to make any changes on the module or use another antenna.
2
Technical data EPI7684 and antenna
VCC in V
Current in mA
Ambient temperature in °C
Humidity max
Dimensions in mm
Wireless
Antenna type
Antenna gain
Frequency band
Method of transmitting radio signal
Channels
Transmission Power in mW
2.1
Interface to the control-/ power electronic of the host device
On the control-/ power electronic is a 4-pin rast 2.5 plug and on the EPI site is 8-pin rast 2.5 plug. This
connection includes communication and power supply wire (13 and 3,3V DC)
13,0 and 3,3 DC
170 max.
0-85
90%
Non condensation
105x80
external loop antenna
-7dBi
2400 MHz - 2483.5 MHz
FHSS
600
<100
2022-03-18
Advertisement
Summary of Contents for Miele EPI7684
- Page 1 (host devices) Integration instruction The EPI7684 and the loop antenna must be integrated under consideration of the technical data. It is not allowed to make any changes on the module or use another antenna. Technical data EPI7684 and antenna...
- Page 2 2022-03-18 Norms / Standards FCC / IC FCC regulation: FCC 47 CFR Part 15.247 Part 1.1310 Part 1.1091 IC regulation: RSS-247, Issue 2 RSS-Gen, Issue 5 RSS-102, Issue 5 Photos and Labels Antenna connector Picture 1: Module EPI7684...
- Page 3 Picture 2: label of the module Picture 3: loop antenna, FAKRA-connector Compliance Statement and Integration In accordance with FCC 47 CFR Part 15 and RSS-247, Issue 2, the EPI7684 (FCC ID: SSVNAEPI03; IC: 5669B-EPINA03) is listed as a Modular Transmitter Device. Notice: This device complies with Part 15 of the FCC Rules and contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS...
-
Page 4: Label Of The End Product
2022-03-18 Radiofrequency radiation exposure Information: This equipment complies with FCC radiation exposure limits set forth and Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void... - Page 5 Integration This EPI7684 Module will only be integrated on our responsibility into Miele appliances/endproducts. The host manufacturer is responsible for additional testing to verify compliance as a composite system. When testing the host device for compliance with the Part 15 Subpart B requirements, the host manufacturer is required to show compliance with the Part 15 Subpart B while the transmitter module(s) are installed and operating.
