CALCA A3 DTF PRINTER
Thank you very much for choosing our CALCA brand series DTF printer, please read
the manual carefully, including the operation and maintenance to ensure the best
output and the lifetime of the machine.
DIRECT TO PRINTING
We are looking for distributor, please ask us for better offer!
Sample and self-pickup service are available.
User Manual
Item Code: DTF-XSC-A3-US
Print Width
CMYK W
0-12.2inches
6 Color
EPSON
XP600
HEAD
Print Cost
$0.007/inch²
1
Advertisement
Table of Contents
Related Manuals for Calca DTF-XSC-A3-US
Summary of Contents for Calca DTF-XSC-A3-US
- Page 1 Print Width CMYK W 0-12.2inches 6 Color Thank you very much for choosing our CALCA brand series DTF printer, please read the manual carefully, including the operation and maintenance to ensure the best output and the lifetime of the machine.
-
Page 2: Machine Information
Sample and self-pickup service are available. I. Machine Information At just A3 wide, the DTF printer fits into any size print shop. And with CALCA DTF film, powder and Inks, you can easily and quickly create custom t-shirts and apparel. -
Page 3: Installation Precautions
DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. 6 Pass and 8 Pass Print Resolution Speed: 6 pass: 4.5m² / h; 8 pass: 3.5m² / h 1 Liter per color ink bottle capacity Printing Software: Flexi PhotoPrint Rip / Maintop 6.1 Rip Printing Resolution: 720 / 1080 / 1440dpi Print Head Cleaning: Automatic... -
Page 4: Parts Identification
DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. III. Parts Identification 1. Emergency Button: Turn on / off printer. 2. Control Panel: Change language, Manual pump. Print head clean, Nozzles check..etc.. - Page 5 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Gigabit Network Card Data Cable White Ink Buffer Bottle Store White Ink. ON / OFF Buttons AC 110V / 220V Grounded Power - 5 -...
- Page 6 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. These two white ink circulation tubes, one for white ink in, then another for out. White ink stirring and circulation controllers - 6 -...
- Page 7 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Main board Power board Your Computer should be Gigabit network card Before network connection, first check the computer network card to a certain Gigabit network card to connect properly, The differences between 100 megabit network card and Gigabit Network Card: A Gigabit Network Card contains these characters: Gigabit, GBE, 10 / 100 / 1000M,...
- Page 8 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Install film and film holder like this The pinch rollers can be lifted up and down Make the film like this print on matte side of film..
- Page 9 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Install two xp600 print heads on the pots.. When insert dampers.. If liquid go inside pins... Put dry napkin at both will short circuited between sides..
- Page 10 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. After all dampers are inserted into print heads, turn off the printer (if now machine is ON) and plug the flat cables into the ports on carriage board. Left Right White head left cable...
-
Page 11: Driver Installation
DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. 2. Then do print head cleaning 1~2 times (Press”Enter”--select Maintenance---”enter”- -clean nozzle--enter). 3. Print a nozzles check, make sure all nozzles come out normally (Press”Enter”-- select Maintenance---”enter”--nozzle test--enter). -
Page 12: Software Installation
DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Click “Connect” → if the grey unchangeable values turn to black changeable values, means connect of the printer is ok. Later, need keep it connected while the printer is working. - Page 13 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Send “Maintop” and “Maintop Print Manager” two programs to desktop. ↓ Open “Maintop Print Manager” Click “Manager” → “Config Port” → “Config TCP/IP Port...” ↓ - 13 -...
- Page 14 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Click “Add” → Set 127.0.0.1 at IP Address Then Click “Check” → 9100 port number shows, Click “Ok” → Click “Close” → - 14 -...
- Page 15 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Open “Maintop”, If this notice → shows, Plug maintop dongle into your computer. Click “File” → “Printer Setup” → Click “Install” → Click “Custom”...
- Page 16 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Find this icc driver location → Then find the “printX.inf” file, open it. → Click “Set As Default Printer” → The driver name is “#XP600-W-Print X”...
- Page 17 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Click “Properties” → Presolution is “V360x2160”dpi ↓ Size is “Auto” ↓ - 17 -...
- Page 18 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Print port is “127.0.0.1” ↓ Print media: “V360 x 2100 6pass” ↓ White Ink Setting White Invaginate → Select “Custom”, change the value you want.
- Page 19 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. White mode: Both select “Spot Color” “Cover” and select white ink density you want... → Click “File” → “New” → Size according to your printer printable width, like 300mm.
- Page 20 DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. Import Picture → Import Tif file created from PS, which already have two white spot channels “W1 W2”. Adjust to Picture Size → The image width should be less than 300mm.
-
Page 21: Maintenance
DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. When your printer is working, press “ENTER” button to pause it, press “EXIT” button, the control panel display screen will pop up “whether to continue printing”, select Yes to continue printing, select No to cancel printing. -
Page 22: Warranty Card
DIRECT TO PRINTING We are looking for distributor, please ask us for better offer! Sample and self-pickup service are available. WARRANTY CARD MODEL LOT # BUYER DATE SELLER Notes The warranty card should be filled by seller and kept by buyer. Alterations are prohibited. ii.
