- Page 1 USER MANUAL MODEL NO:G3 Please read this manual carefully before using the lock Please take good care of this manual for reference after reading Unlock the Future with Our Smart Lock: Security Meets Convenience...
-
Page 2: Table Of Contents
Parts List manual, please refer to the actual products! 05-06 DEVO smart lock is popular among users for its unique appear- ……………………………………………………………………………………………..............ance, advanced and reliable technology and considerate Product Dimension 07-08 after-sales service. -
Page 3: Hardware Introduction
Hardware Introduction (1) Overview Fingerprint Scaner Battery Cover Touchscreen Keypad Cancel/Return/Lock Confirm/Enter Reset Button Doorbell Button Mechanical Key Hole ON/OFF Button Emergency Power Supply Port Plug Notes: The “Emergency Power Supply Port” is not for battery charging purpose and can only be used for emergency power supply to the lock. -
Page 4: Compatible Doors
(2) How To Open / Close Lock Cylinder Cover Compatible Doors Press and hold the Lock Cylinder Cover Compatible Doors and turn it clockwise/counterclockwise to open it. Backset / 60 mm or / 70 mm Door Hole Diameter Minimum l” / 25 mm Distance 4”/ 10cm Door... -
Page 5: Parts List
Parts List Exterior Assembly Screw B Screw A Screw D Screw C Plug Indoor Assembly Deadbolt/Strike Mounting Plate Screws 2 Keys Mounting Plate Interior Assembly Strike Plate and Box Deadbolt IC Card... -
Page 6: Product Dimension
Product Dimension 73mm 63.92mm 44.23mm 61.99mm... -
Page 7: Installation Overview
Installation Overview Battery Cover Interior Assembly Mounting Mounting plate plate Screws D KM3*6 Exterior Assembly Latch Screws C PM3*18 Mounting plate Screws A PM4*35 Mounting plate Screws B PM4*28 Strike Keys *45-55mm door thickness use *35-45mm door thickness use... - Page 8 Step 1. Install Deadbolt (2). Insert and screw the deadbolt into the doorframe. (1). Check your door to see if the deadbolt requires adjustment. If the backset is 70mm, turn the faceplate 180° to extend the length. / ” / 60 mm Make sure the word "UP"...
- Page 9 Step 3. Install Exterior Assembly Step 4. Install Interior Assembly Remember to attach the rubber gasket to the handle before Installation. (1). Measure your cross bore dimension and determine the installation steps accordingly If the cross bore of your door is 1 ½"" /38mm", please remove the adapter.
- Page 10 (3). Secure the back cover with screws. (5). Fix the exterior assembly by the double-sided tape. Important:Please select Screw A ,Screw B based on the thickness of the door(35mm-55mm) (6). Wire to the interior assembly. 1.Thickness of Screw A compatible doors:45-55mm 2.Thickness of Screw B compatible doors:35-45mm 45~55mm door thickness use A...
- Page 11 (7) Mount the interior assembly. Make sure the wire is tucked into the cabin on the back of the interior assembly. Screw D (8). Check if the deadbolt retracts by turning the thumbturn. Screw C...
- Page 12 Apart from being able to configure your door lock through the app, you can also directly set the relevant settings on the door lock following the (9). Install 8 AA batteries into the door lock and it is ready to be used. instructions below.
-
Page 13: Programming Instructions
Programming Instructions (1). User Type Description Type Capacity • Sequence ID 1 Administrator • Unlock • Management • Sequence ID 2-200, Regular User • Unlock, (Invalid when the Anti-lock is On) • Fingerprint Capacity: 100 Passcode Capacity: 50 Total • •... - Page 14 (2). Enter The Function Settings Mode (3). Setting Mode Function List Short press the "Settings" button. You will hear a voice prompt Add Keypad Password saying, "Please verify administrator 1 Add Password Add Fingerprint user." Enter the correct administra Add NFC Card tor password, then press the "unlock"...
- Page 15 (6). Others (4). Restore Factory Settings 1. There are 5 consecutive trial and error opportunities for fingerprints and passwords within 5 minutes, and will be locked for one minute after exceeding the limit 1. Press and hold the "Set" button. After 4 seconds, the lock will start to make a "dong"...
- Page 16 (7). App Operation Guidance 1). Connect The Lock To Internet Following the installation Download Smart Life App. instruction to install the smart lock. Tuya Smart Tuya Smart 2). Steps to Access System Networking Register and login to the Calibrate the smart lock and Press 5 Smart Life App.
- Page 17 Choose the same 2.4G Click“Done” Wi-Fi network as your phone and enter you password 3).Members Management Click‘Add Device’ Waiting for device seach Once the device is discovered click G3 device Member management Select the corresponding Add or delete fingerprints member and passwords...
- Page 18 5) . Password Settings 4). Settings Enter the setting page Open the dormant switch In sleep mode, the app does not support unlocking Notes：In sleep mode,the device cannot be woken up from the App and only be triggered from the device,which can greatly reduce the power consumption of the device.
-
Page 19: Troubleshooting
Troubleshooting Answers This device only supports 2.4 GHz network and does not support 5G network and mixed-band network. When connecting Wi-Fi to the device ， Please make sure that the lock is in paring mode (please refer to page28). Please make sure that your phone is connected to the 2.4G Wi-Fi network. Please make sure that your phone's Bluetooth is turned on. -
Page 20: Product Parameters
Product Parameters Power Supply 4.8V-6V Eight Cell No.5 Battery/2400 mAh Emergency Power Fingerprint Capacity Fingerprints 100MAX,Passcodes 50 MAX,IC Card 50 Max Identification Speed 0.25 Sec False Positive Rate ＜0.0001% Rejiection Rate ＜0.1% Working Temperature ＜-15°-50°C（5°F-122°F） Working Humidity 0%~85%(No Condensation) Standby Current 380uA Dynamic Power Consumption 450mA... - Page 21 20cm between the radiator & your body. For any questions, please feel free to contact us, we will DEVO reserves the final interpretation right of all terms send you a reply and solve the problem within 24 hours.
