Siemens HCU656A Installation Instructions Manual

400A & 600A Copper Lug Kit
Installation Instructions
Hazardous Voltage Hazardous Voltage Hazardous Voltage. Hazardous Voltage.
Will cause death or serious injury. Will cause death or serious injury.
Turn off and lock out all power supplying this device before Turn off and lock out all power supplying this device before
working on this device. working on this device.
Replace all covers before power supplying this device is Replace all covers before power supplying this device is
turned on. turned on.
Use only with Siemens certified components.
NOTE - These instructions do not purport to cover all details or
variations in equipment, or to provide for every possible
contingency to be met in connection with installation, operation contingency to be met in connection with installation operation
or maintenance. Should further information be desired or
should particular problems arise, which are not covered
sufficiently for the purchaser's purposes, the matter should be
referred to the local Siemens sales office. The contents of this
instruction manual shall not become part of or modify any prior
or existing agreement, commitment or relationship. The sales
contract contains the entire obligation of Siemens. The
warranty contained in the contract between the parties is the
sole warranty of Siemens. Any statements contained herein do sole warranty of Siemens. Any statements contained herein do
not create new warranties or modify the existing warranty.
TRADEMARKS - Unless otherwise noted, all names identified
by ® are registered trademarks of Siemens AG or Siemens
Industry, Inc. The remaining trademarks in this publication may
be trademarks whose use by third parties for their own
purposes could violate the rights of the owner.
Copper Lug, (1)
Tensión peligrosa. Tensión peligrosa. Tensión peligrosa Tensión peligrosa
Puede causar la muerte o lesiones graves. Puede causar la muerte o lesiones graves.
Desenergice totalmente antes de instalar o darle servicio. Desenergice totalmente antes de instalar o darle servicio.
Reemplace todas las barreras y cubiertas antes de Reemplace todas las barreras y cubiertas antes de
energizar el interruptor. energizar el interruptor.
Cat. #: HCU656A
Note: HCM65A, HNCM65A, HCM66A or HNCM66A
Field Installable Lug Kit must already be installed to use this kit.
1 / 4 (English)
Released Production, 0P v3, Jul 02, 2015
Item: HCU656A
For use with: 400A & 600A VBII Safety Switches,
Series "A"
Tension dangereuse. Tension dangereuse Tension dangereuse. Tension dangereuse
Danger de mort ou risque de blessures graves. Danger de mort ou risque de blessures graves.
Couper l'alimentation de l'appareil et barrer avant de Couper l'alimentation de l'appareil et barrer avant de
travailler. travailler.
Remplacez touts les couverts avant que Remplacez touts les couverts avant que
l'approvisionnement de pouvoir soit alimenté. l'approvisionnement de pouvoir soit alimenté.
Recommended tools:
5/16" socket,
Extension bar,
T Torque wrench
Copper Lug, Torque Label (1)
h
I.L. No. 508535A00
