  • Page 1 12 Place Stainless Steel Dishwasher Model Number ON-DW12S INSTRUCTION MANUAL After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
  • Page 2: Table Of Contents

    Contents General Safety Instructions Product Overview Installation Features Instructions FAQs and Troubleshooting Guide Other Useful Information After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
  • Page 3: General Safety Instructions

    General Safety Instructions IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to.
  • Page 4: Usage Conditions And Restrictions

    General Safety Instructions (Cont.) • Inserting/removing the plug: Before you insert or remove the plug, make sure the appliance is switched off and the power is switched off at the electrical outlet. Remove by grasping the plug, do not pull on the cord. CAUTION! •...
  • Page 5 General Safety Instructions (Cont.) • Children should be supervised to ensure they do not play with the appliance. Close supervision is necessary when any appliance is used by or near children. WARNING! • Never leave the appliance unattended while in use. • Dishwasher door: Do not abuse, sit on or stand on the door or dish rack of the dishwasher, or use it for anything other than its intended purpose.
  • Page 6: Product Overview

    Product Overview Scope of delivery Dishwasher: front view, open Upper Basket Lower Spray Arms Upper Spray Arms Detergent Dispenser Cutlery Basket Rinse Aid Dispenser Lower Basket After Sales Support (AU) 1300 886 649 (NZ) 0800 836 761 | tempo.org/support...
  • Page 7 Product Overview (Cont.) Dishwasher: rear view 10 Drain hose 11 Water supply hose (to be installed) 12 Power cord and plug Documentation (Not Shown) Instruction Manual Warranty Certificate NOTE: Due to continued product improvement, images and illustrations in this manual may vary slightly from the product purchased.
  • Page 8: Control Panel

    Product Overview (Cont.) Control panel Intensive Rinse Aid Heavy Normal 60min Half-Load 30min Pre-wash Dry+ Half-Load Program Dry+ Operation buttons POWER Press this button to enter or exit the ready-to-use state. Press this button to select the appropriate washing Program program, the selected program indicator will be lit.
  • Page 9 Product Overview (Cont.) Display indicators Intensive For most heavily soiled crockery, such as pots, pans, casserole dishes and dishes that have been sitting with dried food on them for some time. Heavy For heavily soiled loads, such as pots, plates, and glasses, as well as lightly soiled pans, use the standard daily cycle.
  • Page 10: Installation

    Installation DANGER! Make sure your electrical power is disconnected before installing the dishwasher. Failure to do so can result in death or electric shock. IMPORTANT! All relevant pipes and electrical equipment should be installed by licensed plumbers, electricians or dishwasher installers. Make sure to use new water supply and drain hoses;...
  • Page 11: Levelling The Appliance

    Installation (Cont.) Levelling the appliance • Position the dishwasher on a level and sturdy floor. Fig. 1 • If the floor is uneven, adjust the adjustable feet until it reaches a horizontal position; just screw the feet in or out a little (Fig. 1). • The appliance should not be inclined more than 2°.
  • Page 12: Cold Water Connection

    Installation (Cont.) Cold water connection • Connect the cold water supply hose to a threaded 3/4” connector. During use, the dishwasher will heat up the water to the required temperature. Make sure the hose is not kinked or squashed and is fastened tightly in place (Fig.
  • Page 13: Electrical Connection

    Installation (Cont.) Electrical connection Make sure that the electrical voltage and circuit frequency in your home correspond to those indicated on the appliance rating label and that the electrical system is sized for the maximum voltage on the rating plate. This appliance requires a 10A fused, copper-wired electrical supply.
  • Page 14: Features

    Features Wash programs and cycles Program Suitability Cycles Intensive For most heavily soiled crockery, Prewash (40ºC) such as pots, pans, casserole Main Wash (55ºC) dishes and dishes that have been Rinse sitting with dried food on them for Hot Rinse (65ºC) some time.
  • Page 15 Features (Cont.) Detergent (pre / main) Running Time (min.) Energy (kWh) Water (L) 5 / 25 g 1.200 15.5 (or all-in-1) 5 / 25 g 1.150 15.0 (or all-in-1) 5 / 25 g 0.730 11.8 (or all-in-1) 5 / 20 g 0.900 15 g 0.500...
  • Page 16: Instructions

    Instructions the dishwasher Loading For best performance of your dishwasher, follow the loading guidelines in this manual. ATTENTION: Before loading the dishwasher baskets: It is not necessary to rinse the dishes under running water before you put them into the dishwasher.
  • Page 17 Instructions (Cont.) Adjusting the upper basket height The height of the upper basket can easily be adjusted in order to accommodate taller dishes in either the upper or lower basket. To adjust the height of the upper basket, please follow the steps below (Fig. 6): Fig.
  • Page 18: The Upper Basket

    Instructions (Cont.) The upper basket The upper basket is designed to hold more delicate and lighter tableware such as glasses, cups, small plates, bowls and shallow pans (as long as they are not too dirty). Position these items securely so they do not get moved by the spray of water (Fig. 8). Fig.
  • Page 19: The Lower Basket

    Instructions (Cont.) The lower basket The lower basket is designed to hold dinner plates, larger items and the cutlery basket. To ensure the detergent dispenser lid can open freely, the maximum diameter for plates in front of the detergent dispenser is 19 cm. Pots, pans, serving dishes and bowls are often the most difficult to clean and fit best into the lower basket.
  • Page 20 Instructions (Cont.) The cutlery basket Your new dishwasher is equipped with a removable cutlery basket with anti-nesting grid (Fig. 12). You can use it with the anti-nesting grid up or down, as convenient, anywhere in the back section of the lower basket. Fig.
  • Page 21: Dishwasher Detergent

    Instructions (Cont.) Dishwasher detergent WARNING! • Only use detergent specifically made for use in dishwashers. • Always add detergent just before starting the dishwasher, otherwise it could get damp and will not dissolve properly. It is also a hazard to leave detergent in the dispenser where children can reach it when the door is open.
  • Page 22: The Detergent Dispenser

    Instructions (Cont.) The detergent dispenser Fig. 14: Push latch to open Fig. 15 Adding detergent The table on page 15 lists the recommended amounts of detergent, generally one heaped tablespoonful, or 25–30 g. However, water hardness and soiling levels affect the amount of detergent required, and there are various types of detergent tablet on the market, so always follow the detergent manufacturer’s recommendations on dosage.
  • Page 23: Filling The Rinse Aid Dispenser

    Instructions (Cont.) Rinse aid Rinse aid is automatically released during the last rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aid. CAUTION! Only use specific, branded rinse aid for your dishwasher.
  • Page 24 Instructions (Cont.) When to refill the rinse aid dispenser Fill the rinse aid dispenser when the warning light on the control panel comes on. Alternatively, you can estimate the amount of rinse aid left in the dispenser by the colour of the optical level indicator, which is located next to the cap (see Fig. 16-C on page 22). When the rinse aid container is full, the whole indicator will be dark.
  • Page 25: Running The Dishwasher

    Instructions (Cont.) Running the dishwasher Starting a wash program • Open the door and draw out the lower basket. Load your dishes and push the basket back into place. Then load the upper basket the same way (see pages 16–20 for details).
  • Page 26: Forgot To Add A Dish

    Instructions (Cont.) Forgot to add a dish? Additional dishes can be added any time before the detergent dispenser opens. • Press the START/PAUSE button to pause the washing. • Wait for 5 seconds, then open the door. • Add additional dishes. • Close the door.
  • Page 27: Faqs And Troubleshooting Guide

    FAQs and Troubleshooting Guide The table below lists possible causes and solutions for common problems you may encounter with the dishwasher. If you follow all the instructions below but still cannot solve a problem, please contact our after sales support centre. Problem Possible cause Solution...
  • Page 28 FAQs and Troubleshooting Guide (Cont.) Use only specific dishwasher detergent to avoid suds. If this occurs, open the dishwasher and let the suds evaporate. Add 3–4 litres of cold water to the tub, close the door securely, then run any Inappropriate detergent program.
  • Page 29: Error Codes

    FAQs and Troubleshooting Guide (Cont.) Improper loading Load the dishwasher as suggested in this manual. Increase the amount of rinse aid. Remove the cap Too little rinse aid from the rinse aid dispenser and set the dosage dial to a higher number. No rinse aid Refill the rinse aid dispenser.
  • Page 30: Other Useful Information

    Other Useful Information Cleaning the filter system The filter system in the base of the wash cabinet efficiently removes food particles from the wash water, allowing it to be recycled during the wash. It prevents larger remnants of food or other objects from getting inside the pump. The filter system consists of a coarse filter, a flat Fig.
  • Page 31: Cleaning The Exterior Of The Appliance

    Other Useful Information (Cont.) WARNING! • When cleaning the filters take care not to contort their shape, which could compromise the washing performance. • Do not overtighten the filters. Put the filters back in sequence securely, otherwise coarse debris could get into the system and cause a blockage. •...
  • Page 32: Looking After Your Dishwasher

    Other Useful Information (Cont.) Looking after your dishwasher • After every wash, turn off the water supply to the appliance and leave the door slightly ajar so moisture and odours are not trapped inside. • Before cleaning or performing maintenance, always unplug the dishwasher from the socket.
  • Page 33: Technical Specifications

    If the appliance is damaged, do not attempt to repair it yourself. Do not disassemble or modify the appliance. If it requires repair or service, please contact our after sales support centre to arrange for a service. Technical specifications Model Number ON-DW12S Capacity 12 place settings Rated voltage/frequency 220-240 V~ 50 Hz...
  • Page 34: Responsible Disposal

    Other Useful Information (Cont.) Responsible disposal Packaging materials are recyclable. Please dispose of them responsibly for recycling. At the end of its working life, do not throw this appliance out with your household waste. Electrical and electronic products contain substances that can have a detrimental effect on the environment and human health if disposed of inappropriately.
