TR 1000/-W
Shower Chair
Instruction for use - English
Always study this manual carefully before operating the
shower chair.
The operator/user must always have access to the operating
manual.
The shower chair is intended for professional use only where
the patient will be under supervision of trained personnel.
IFU Rev 2 2024-08-20
Max patient Weight: 200KG /440 lbs
Always read the user manual
Always make sure that you have the correct version of the manual and it is mandatory to read the
Instructions before the first time of using the equipment.
Operating instructions and recommended maintenance
procedures are explained in the following pages.
If you have any questions regarding the operation or
maintenance of your shower chair and cannot find the
answer in this manual, please contact us.
The shower chair is designed for years of trouble-free
operation, with proper use and maintenance.
Hygiene Equipment
Designed for People
Registered at Medical Products
Agency, Sweden as a MDR
Class 1 product according to
MDR 2017/745.
TR reserves the right to make
design changes and/or
improvements without notice.
Advertisement
Table of Contents
Summary of Contents for TR Equipment TR 1000
- Page 1 TR 1000/-W Hygiene Equipment Designed for People Shower Chair Instruction for use - English Registered at Medical Products Agency, Sweden as a MDR Class 1 product according to MDR 2017/745. TR reserves the right to make design changes and/or improvements without notice.
-
Page 2: Table Of Contents
• Measurements TR 1000/-W in mm Page 11 • Measurements TR 1000/-W in inch Page 12 User instructions Page 13 • Height & Tilt adjustment TR 1000/-W Page 13 • Emergency stop Page 13 • Charging instructions Page 14 •... -
Page 3: Manufacturer
Hygiene Equipment Designed for People Manufacturer TR Equipment AB Rundelgatan 2 SE-573 35 Tranås Sweden Phone: +46 (0)140 38 50 60 www.trequipment.com info@trequipment.se Group subsidiaries: TR Group Inc. Phone: +1 (800) 7526900 www.trequipment.com information@trequipment.com Germany: TranspoRehamed GmbH Phone: +49 (0) 212-645850-0 www.transporehamed.de... -
Page 4: Introduction
New users must be trained by qualified and experienced staff. TR Equipment AB requires that each user has read and understands the entire operating manual and that they can apply the instructions as specified. This applies to anyone who was not present at the in-service training. -
Page 5: Intended Use
The TR 1000/-W is intended to be used indoors in all types of care facilities and private homes, including hygiene areas. • The TR 1000/-W is only intended to be used for short term use <60min when in contact with breached or compromised skin. •... -
Page 6: Unpacking
Initialisation/Calibration: • If the TR 1000/-W is in the lowest position raise the chair by pressing the UP button on the hand control. • Press the UP and the DOWN button on the hand control simultaneously. Keep the buttons pressed. -
Page 7: Safety Instructions
Prompt service is required. In case of accident Note: In case of a serious incident when using the TR 1000/-W Shower chair, this should be reported to the manufacturer and to the local authorities where you are established. Warning •... -
Page 8: Features And Controls
Hygiene Equipment Designed for People Features and Controls Lifting columns Front closing arm rests (Option) Chair seat Castors with brake Chair backrest Handgrip Chair headrest Footrest (Option) Foldable armrests Emergency stop Leg rest Safety belt Bedpan incl. Lid (option) Chassis base Hand control Snap on/off buckle Battery pack... -
Page 9: Product Description
Designed for People Product description TR 1000/-W – Shower chair, battery operated Height and tilt adjustable shower chair. As standard equipped with 4pcs Castors with brake, 2pcs Lifting columns, 1pcs Tilt actuator, 1pcs Hand control, 1pcs Battery pack, 1pcs Battery charger, 2pcs Foldable arm rests and 1pcs Safety belt. -
Page 10: Technical Specification
Powder coated and Zink plated steel and stainless steel Protection class IP X5 Castors Twin castors Ø100mm TR 1000 – Dimensions and weights Length 860mm / 63” Height (Head rest) 1350 – 1750mm / 53” – 69” Height (Head rest, Incl. Spacer kit) 1403 –... -
Page 11: Measurements Tr 1000/-W In Mm
Hygiene Equipment Designed for People Technical specification TR 1000/-W – Shower chair Dimensions in mm... -
Page 12: Measurements Tr 1000/-W In Inch
Hygiene Equipment Designed for People Technical specification TR 1000/-W – Shower chair Dimensions in inch... -
Page 13: User Instructions
Hygiene Equipment Designed for People User Instructions Height adjustment TR 1000/-W – Height & tilt adjustment UP & DOWN Always secure the resident with safety belt. The tilt will stop in a neutral position. Tilt adjustment The chair can be tilted forward to ease transfer using the same button/ symbol. -
Page 14: Charging Instructions
The extra removable battery shall immediately be put on charge to make the usage of the TR 1000/-W and the charging procedure more effective. Batteries in storage must be put on charge to maintain the capacity of the battery. -
Page 15: Battery Usage
Ideally if a battery is not in use, it should always be plugged into the charger. The battery pack cannot be overcharged. • If the TR 1000/-W is only used occasionally the battery shall be put on charge after each use and for at least 24 hours. •... -
Page 16: Castors
Warning • Never leave the patient unattended. • Always check the water temperature by hand before showering the patient. Important • The castor brake must always be activated during transfer of the resident onto and off the TR 1000/-W . -
Page 17: Patient Handling - Showering
• Lock the castor brakes • Use the hand control to raise the TR 1000/-W to a convenient height for both resident and caregiver. • Use the hand control to tilt/recline the TR 1000/-W to a convenient angle for both resident and caregiver. -
Page 18: Product Label
Hygiene Equipment Designed for People Product label UDI (Unique Device Identification) can be found within the barcode human readable text. It contains: • (01) EAN code • Date of Manufacture. The date is in the format YYYYMMDD Y = Year, M = Month and D = Date. •... -
Page 19: Table Of Symbols
Hygiene Equipment Designed for People Table of Symbols TR Equipment Logotype Visual inspection Medical equipment according to Read the manual MDR 2017/745 CE marking Maximum patient weight 200kg Manufacturing date WEEE Symbol May not be discarded in domestic waste Factory address... -
Page 20: Routine Maintenance
The recommended frequency of these maintenance procedures will depend on how often the equipment is used. It is good practice to establish these procedures and then adjust the frequency as your conditions indicate. Before every use Visual inspect the TR 1000/-W Shower chair: • Make sure that it stands securely on the floor. -
Page 21: Maintenance Every 3 Years
Maintenance recommendations for Maintenance every 3 years, Maintenance every 5 years, and Maintenance every 10 years are based on Home Care use and Public use from SS-ISO 17966:2016. If your TR 1000/-W will be used in an institution, contact TR Equipment for a customized maintenance schedule. Maintenance Every 3 years •... -
Page 22: Recycling
Hygiene Equipment Designed for People Disposal / Recycling Recycling of the equipment • PUR Seat and backrest shall be recycled as flammable materials. • Metal parts shall be recycled in Metal recycling • Grey cover and fenders are produced in ABS plastic and shall be recycled as flammable materials. •... -
Page 23: Cleaning Instructions
Hygiene Equipment Designed for People Cleaning instructions • Select cleaning interval according to the degree of contamination. • Contaminations should be removed as soon as possible to prevent material damage. • Do not clean material with tools which might damage surfaces. Use a towel, sponge, or a soft brush. •... -
Page 24: Maintenance Record
Hygiene Equipment Designed for People Maintenance record Date Description Signed by... -
Page 25: Training Record
Hygiene Equipment Designed for People Training record Date Description Signed by... - Page 26 If you have questions regarding operation or maintenance of your equipment and cannot find the answer in this manual, please do not hesitate to contact us! Head office Group Subsidiaries TR Equipment AB, Sweden TR Group Inc, US, Phone: +1 (800) 752 6900 Phone: +46 140 38 50 60 TRanspoRehaMed GmbH, Germany, Phone: +49 (0) 212 645850-0 info@trequipment.se...
