AudioCodes 425HD IP Phone
1. Before Installing
Congratulations on purchasing your AudioCodes 425HD IP Phone!
Before installing your phone, make sure the following items are included in the shipped box:
425HD IP Phone
AC power adapter (optional)
Cat 5e Ethernet cable
Handset
Handset cord
Desktop stand with two screws
2. Physical Description
Softkeys
Navigation Control
Back Key
Volume Keys
Mute Key
Headset Key
Speakerphone Key
Quick Guide
P a g e
Alphanumerical Keypad
| 1
Screen
Programmable
Keys
Menu
Voicemail
Contacts
Smart Button
Transfer
Hold
Microphone
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AudioCodes 425HD
Summary of Contents for AudioCodes 425HD
- Page 1 AudioCodes 425HD IP Phone Quick Guide 1. Before Installing Congratulations on purchasing your AudioCodes 425HD IP Phone! Before installing your phone, make sure the following items are included in the shipped box: 425HD IP Phone AC power adapter (optional) ...
-
Page 2: Cabling The Phone
3. Cabling the Phone To cable phone: Connect the short, straight end of the handset cord to the handset. Connect the longer straight end of the cord to the phone’s handset jack. (Optional) Connect a headset to the phone’s USB port. Connect the phone’s RJ-45 LAN port to your LAN network (LAN port or LAN switch/router), using a CAT 5/5e Ethernet cable. - Page 3 4. Mounting Phone on a Desktop Your phone is shipped with a desk stand for desktop mounting. To desk-mount phone: Align the two hooks of the desk stand (supplied) with the corresponding slots on the phone base: Gently push the stand down until it snaps securely into place. Secure the stand to the phone by fastening the two screws (supplied): P a g e...
- Page 4 5. Mounting Phone on a Wall Use AudioCodes wall-mounting bracket kit (separate orderable item) to mount the phone on a wall or to hang it on your Ethernet wall plate. To wall-mount phone: Align the two clips of the wall-mounting bracket (separate orderable item) with the corresponding slots on the bottom of the phone.
-
Page 5: Basic Phone Operations
The holes in the wall-mounting bracket (attached to the phone) comply with many mounting standoffs on Ethernet wall plates available in the market. 6. Basic Phone Operations For basic phone operations, refer to AudioCodes’ 425HD User’s and Administrator's Manual. P a g e... - Page 6 7. Warnings FCC Caution Part 15.21 Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Part 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 7: Notice Information
Information contained in this document is believed to be accurate and reliable at the time of publishing. However, due to ongoing product improvements and revisions, AudioCodes cannot guarantee accuracy of material after the Date Published nor can it accept responsibility for errors or omissions. Updates to this document can be downloaded from https://www.audiocodes.com/library/technical-documents.
