  • Page 1 User Manual GETTING STARTED? EASY. ZWF8240WX ZWF81240SX EN User Manual Washing Machine...
  • Page 2: Safety Information

    SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 3: Safety Instructions

    areas for communal use in blocks of flats or in launderettes. – Do not exceed the maximum load of 8 kg (refer to the • "Programme chart" chapter). The operating water pressure at the water entry point from the • outlet connection must be between 0.5 bar (0.05 MPa) and 8 bar (0.8 MPa).
  • Page 4: Electrical Connection

    ELECTRICAL CONNECTION WARNING! Risk of fire and electric WARNING! Risk of injury, electric shock. shock, fire, burns or damage to the appliance. • The appliance must be earthed. • Follow the safety instructions on the detergent • Always use a correctly installed shockproof packaging.
  • Page 5: Product Description

    PRODUCT DESCRIPTION APPLIANCE OVERVIEW Worktop Rating plate Detergent dispenser Drain pump filter Control panel Feet for levelling the appliance Door handle CHILD SAFETY DEVICE This device prevents children or pets to be closed in the drum. Turn the device clockwise, until the groove is horizontal. You cannot close the door.
  • Page 6: Control Panel

    CONTROL PANEL CONTROL PANEL DESCRIPTION Brighter Whites Cottons Flex Allergy Stop Synthetics Blanket Delicates Quick Jeans Mixed Cottons Fabrics Silk Spin/Drain Wool/Handwash Rinse 9 10 Programme knob Extra rinse button (Extra Rinse) Temperature button (Temp) Start/Pause button (Start/Pause) Spin reduction button (Spin) Delay start button (Delay Start)
  • Page 7: Programme Chart

    • : The spin phase When a programme is set, all the F. The spin area: indicators of the phases related to the programme come on. • : The spin speed indicator When the programme starts, only the • : The no spin indicator indicator of the phase in operation flashes.
  • Page 8 Programme Maximum load Programme description Temperature range Maximum spin (Type of load and soil level) speed 2 kg Machine washable wool, hand washable wool and Wool/Hand- 1200 rpm delicate fabrics with «hand washing» care symbol. wash (wool/hand- wash) 40°C - (Cold) 1 kg Special programme for silk and mixed synthetic items .
  • Page 9 Programme options compatibility Programme Time Rinse Night Extra Easy Delay Spin Prewash Man- Spin Hold Cycle Rinse Iron Start ager Cottons Flex (cot- ■ ■ ■ ■ ■ ■ ■ ■ ■ tons flex) Synthetics (syn- ■ ■ ■ ■ ■...
  • Page 10: Consumption Values

    CONSUMPTION VALUES Stated values are obtained in laboratory conditions with relevant standards. Different cau- ses can change the data: the quantity and type of laundry and ambient temperature. Wa- ter pressure, the supply voltage and the temperature of inlet water may also affect the washing programme duration.
  • Page 11 Some advices to have the most efficient To drain the water refer to ‘At the end setting: of the programme’. • Set the Time Manager indicators • Set the possible lower washing temperature. • Do not set the Prewash option. TIME MANAGER When you set a washing programme, the display shows the default duration.
  • Page 12: Before First Use

    • To activate/deactivate this option, press To deactivate/activate the acoustic signals, Prewash and Extra Rinse at the same press Extra Rinse and Delay Start at the same time for 6 seconds. time until the indicator comes on/goes off. You can activate this option: If you deactivate the acoustic signals, they continue operate when the •...
  • Page 13 Detergent compartment for prewash or soak Never pour bleach and softener into phase. the compartment at the same time. The prewash and soak detergent must be added at the beginning of the wash pro- gramme. SETTING A PROGRAMME Compartment for powder or liquid detergent 1.
  • Page 14 OPENING THE DOOR WHEN THE DELAY 2. Press the button Start/Pause START OPERATES • The door is locked and the indicator While the delay start operates, the appliance door is locked and the display shows the indicator • The appliance starts the countdown. •...
  • Page 15: Hints And Tips

    STAND-BY 2. Press the button Start/Pause . If necessary, Once the programme has finished, after a few decrease the spin speed. minutes the energy saving system will be enabled. The appliance spins and drains or only drains. The brightness of the display is reduced. 3.
  • Page 16: Care And Cleaning

    To know the water hardness in your area, contact Use the correct quantity of the water softener. your local water authority. Obey the instructions that you find on the packaging of the product. CARE AND CLEANING CLEANING THE DETERGENT DISPENSER WARNING! Refer to Safety chapters.
  • Page 17: Cleaning The Drain Filter

    Close the drawer and run Clean the filter under a the rinse programme with- tap, to remove any traces out any clothes in the of fluff. drum. Remove foreign bodes and fluff from the filter CLEANING THE DRAIN FILTER seat and from the pump The pump should be inspected regularly and impeller.
  • Page 18: Troubleshooting

    CLEANING THE INLET HOSE AND THE VALVE 1. Put 2 litres of water in the main wash FILTER compartment of the detergent dispenser. 2. Start the programme to drain the water. FROST PRECAUTIONS If the appliance is installed in an area where the temperature can be less than 0°...
  • Page 19: Possible Failures

    POSSIBLE FAILURES Problem Possible solution The programme does not • Make sure that the mains plug is connected to the mains socket. start. • Make sure that the appliance door is closed. • Make sure that there is not a damaged fuse in the fuse box. •...
  • Page 20: Technical Data

    Problem Possible solution The appliance makes an • Make sure the levelling of the appliance is correct. Refer to "Instal- unusual noise. lation". • Make sure that the packaging and/or the transit bolts are removed. Refer to "Installation". • Add more laundry in the drum. The load may be too small. The cycle is shorter than •...
  • Page 21: Environmental Concerns

    ENVIRONMENTAL CONCERNS with the symbol with the household waste. Recycle materials with the symbol . Put the Return the product to your local recycling facility or packaging in relevant containers to recycle it. Help contact your municipal office. protect the environment and human health by recycling waste of electrical and electronic appliances.
  • Page 24 WWW.ZANUSSI.COM/SHOP...
  • Page 25 WWW.ZANUSSI.COM/SHOP...
  • Page 29 45° 20°...
  • Page 36 Time Delay Easy Extra Night Rinse Manag Prewash Spin Start Iron Rinse Cycle Hold Spin...
  • Page 37 Time Delay Easy Extra Night Rinse Manag Prewash Spin Start Iron Rinse Cycle Hold Spin...
  • Page 40 Brighter Whites Cottons Flex Allergy Stop Synthetics Blanket Delicates Quick Jeans Mixed Cottons Fabrics Silk Spin/Drain Wool/Handwash Rinse 9 10...
  • Page 44: Getting Started

    User Manual GETTING STARTED? EASY.

This manual is also suitable for:

Zwf81240sx
