  • Page 1 PM-9600 ® PENTIUM 75MHz to 233MHz PCI, Ultra DMA/33 & High Speed Multi I/O Chipset System Board User’s Guide Revision 1.0...
  • Page 2 International Inc, assumes no responsibilities for any inaccuracies that might be in this manual nor will it be liable for damage resulting from the use of this manual. Amptron International Inc, reserves the right to make changes to the manual at any time and without notice.
  • Page 3 PM-9600 MAINBOARD MANUAL CPUs SUPPORTED ® ® •Intel Pentium P54C (75MHz to 200MHz) ® ® •Intel Pentium with MMX™ Technology P55C (166MHz to 233MHz) ® ® •Cyrix /IBM 6x86MX (PR166) ® ® •Cyrix /IBM 6x86L (PR166+) ® ® •Cyrix /IBM 6x86 (PR120+ to PR200+) •AMD™...
  • Page 4 PM-9600 MAINBOARD MANUAL ATX POWER SUPPLY ZIF SOCKET CONNECTOR Plug the processor into this socket. Plug the single 20 pin connector into Make sure the cpu is correctly aligned the board connector. It should only fit before you insert it.
  • Page 5 PM-9600 MAINBOARD MANUAL BE SURE YOU KNOW WHAT YOU ARE DOING! •It’s easy to get overly excited about your purchase, and to jump right into installing the system board into your case. Too many times, people fail to read the manual or insist on installing it themselves, only to find out later that they’ve permanently damaged their...
  • Page 6 PM-9600 MAINBOARD MANUAL PWR1 - AT Power Supply Connector DESCRIPTION DESCRIPTION Power Good Ground Ground +12V -12V Ground Ground J3 - Optional ATX Form Card Bracket PINS DESCRIPTION +5V (USB Connector Pins 1-8 ) DATA - DATA - DATA +...
  • Page 7 PM-9600 MAINBOARD MANUAL J2 SPK - Speaker Connector DESCRIPTION Data Out Not Connected Ground J2 KEYLOCK - Keylock & Power LED DESCRIPTION LED Output Not Connected Ground Keylock Ground J2 TB-LED - Turbo LED Connector DESCRIPTION Signal Ground J2 HDD-LED - HDD LED Connector...
  • Page 8 PM-9600 MAINBOARD MANUAL JP1 - CMOS RAM Discharge Selector DESCRIPTION Normal Mode (default) Clear CMOS JP4 - DIMM Voltage Selector JP4A JP4B DESCRIPTION 1 - 2 1 - 2 2 - 3 2 - 3 3.3V (default) DSW1 (1-3) - CPU Clock Multiplier...
  • Page 9 PM-9600 MAINBOARD MANUAL DSW1 & DSW2 CPU Configuration Jumpers CPU TYPE DSW1 DSW2 ® INTEL ® PENTIUM P54C INTEL ® PENTIUM ® MMX™ P55C CYRIX ® PR150+ 6x86 (3.5V) PR166+ 6x86L PR166+L 6x86MX PR166 PR100 PR120 AMD™ PR133 (3.5V) PR150...
  • Page 10: Memory Considerations

    PM-9600 MAINBOARD MANUAL JP8 - Memory Bank Selector JP8A JP8B DESCRIPTION 1 - 2 1 - 2 3 Memory Banks 2 - 3 2 - 3 4 Memory Banks 3 BANK MEMORY INSTALLATION CONFIGURATION BANK# DESCRIPTION MEMORY MODULE SIMM3 & SIMM4...
  • Page 11 PM-9600 MAINBOARD MANUAL The ACPI functions that described in this chapter will not be available unless the ATX power connector is being used. PWR2 - ATX Power Supply Connector DESCRIPTION 3.3V 3.3V Ground Ground Ground Power OK 5VSB +12V 3.3V...
  • Page 12: Default Settings

    PM-9600 MAINBOARD MANUAL After you have configured the mainboard and have assembled the components, turn on the computer and run the software setup to ensure that the systems information is correct. WARNING •Due to the frequent upgrades of the AMI WINBIOS, this manual may not include descrip- tions of all the features available to you in your current BIOS.
  • Page 13: Primary Master & Slave, Secondary Master & Slave

    PM-9600 MAINBOARD MANUAL PRIMARY MASTER & SLAVE, SECONDARY MASTER & SLAVE •Choose these icons to configure the hard disk drive named in the option. When you click on an icon, the following parameters are listed: Type, LBA/Large Mode, Block Mode, 32-bit Mode and PIO Mode.
  • Page 14: Power Management/Apm

    PM-9600 MAINBOARD MANUAL POWER MANAGEMENT/APM •Set this option to ENABLED to enable power management and APM features. GREEN PC MONITOR POWER STATES •This option specifies the power state that the green PC compliant video monitor enters when BIOS places it in a power saving state after the specified period of display inactivity has expired.
  • Page 15 PM-9600 MAINBOARD MANUAL WHAT TO DO FIRST... •The most overlooked and common problems are actually the easiest to solve. Even if you are the most seasoned of all computer technophiles and you can tell Bill Gates a thing or two, make sure you double check the following three most frequently repeated mistakes: (1) The power cable is not plugged firmly into the power supply in the back of the computer.
  • Page 16 Trademark Acknowledgment Pentium is a trademark of the Intel Corporation. AMI is a trademark of American Megatrends Inc. MS-DOS, Windows 95 are trademarks of the Microsoft Corporation. Other trademarks belong to their respective owners. Specifications are subject to change without notice. Though the information presented in this User’s Guide has been reviewed carefully, no responsibility is assumed for inaccuracies.
