Page 1: Table Of Contents
Chiller M-series INSTALLATION - STARTUP - OPERATION - MAINTENANCE ........... 1 HILLER SERIES installation - startup - operation - maintenance ... 1 In general ........... 1 1.1. Reception of the unit: ......1 1.2. Unloading: ..........1 1.3. Guarantee:..........1 1.4.
Page 3: Chiller M- Series
1. IN GENERAL  This manual describes the main installation regulations concerning the M-version.  Specific model information as there are P&ID, electrical diagram, pump curve, bill of material and other specific model and version information you can find in the specific technical files. ...
Page 4: Identification Labeling
1.5. I DENTIFICATION LABELING  Generally you can find the manufacturer’s plate in the left or right upper corner of the machine on the side of the electrical cabinet.  CE - label. The unit meets the legislation regarding equipment under pressure PED directive 97/23 EC. ...
Page 5: Storage
2. STORAGE 2.1. S HORT TERM STORAGE  Store the units in a dry room, sheltered from inclement weather, at a temperature between 0 and 40°C, in such a way that they are not in contact with a wall, or directly in contact with the ground, protect them from knocks and ensure that they only support their own weight.
Page 6: Manipulation
 The MC & MH units are designed to be stationed outside.  The area where you place the unit has to be easily accessible and well lit to allow maintenance and service. The unit has to be placed in such a way that it can be encircled to replace all spare parts. ...
Page 7: Function Of The Unit
If the human, financial, and environmental consequences of the failure of the machine are extreme, take precautions to prevent worse !  For appliances and potentially heat recuperating, please consult Thermotec.  Legislation: the installation has to be in consensus with the standards and codes applicable in the country of installation.
Page 8: Initial Operation
4. INITIAL OPERATION 4.1. I NITIAL STARTUP 4.1.1. AUXILIARIES  Read attentively instructions of auxiliary equipment regarding settings and installation. 4.1.2. D AERATION  During the filling of the machine inevitable there will occur air bubbles in some places for example the pump. The air bubble can be removed manually through the de-aeration valve on top of the pump housing.
Page 9: Maintenance
N GENERAL  All work must be performed by qualified personnel.  Do not attempt any modifications or repairs without Thermotec written approval.  Information about maintenance work performed must be recorded.  Check that the materials used as spare parts are suitable for the conditions of use.
Page 10: Preventive Maintenance
5.2. P REVENTIVE MAINTENANCE  Annual or semi-annual (depending on the CO -equivalent) the unit has to be inspected to guarantee a proper operation of the security mechanisms. Also the condition of the isolation and external corrosion have to be checked.
Page 11: Spare Parts
Use the original lifting devices Thermotec unit are produced with CE-label. It decelerates that the product complies with the essential requirements of the relevant European health, safety and environmental protection legislation, in practice by many of the so-called Product Directives.
