USE AND CARE GUIDE
TM
7 FT VICTORIAN VAMPIRE
Questions, problems, missing parts? Before returning to the store, please have a copy of your receipt
ready and email the SVI customer experience team (customerservice@svius.com) within 90 days of
the date of purchase or call Home Accents Holiday Customer Service 8 a.m. - 7 p.m., EST,
Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HOLIDAY (1-855-434-6543)
HOMEDEPOT.COM
PARTS LIST
A. Base x 1
B. Lower Leg Poles x 2
C. Shoes x 2
D. Left Upper Leg Pole x 1
E. Right Upper Leg Pole x 1
F. Leg Foam x 2
G. Pants x 1
H. Lower Body Frame x 1
I. Hip Hoop x 1
J. Upper Body Frame with Control Box x 1
K. Jacket x 1
L. Left Arm x 1
M. Right Arm x 1
N. Left Hand x 1
O. Right Hand x 1
P. Head x 1
Q. Back Frame x 1
R. Collar x 1
S. Adaptor x 1
Power Adapter * Spec
Input: 120V~60Hz
Output: 5.9V 2.0A
Wattage: 11.8W
NOTE: Throughout the instructions, Right and
Left are from the character's point of view.
B
B
BACK
LEFT
A
RIGHT
FRONT
A
H
N
C
B
B
C
A
1.1
IMPORTANT TIPS:
• Ensure that the item's adapter is plugged in at the Function Control Box and in
the wall.
• Ensure that the switch on the function control box is on the desired setting.
• If not functioning properly (ex: Mouth doesn't move, eyes don't light up, body
doesn't move), ensure that cables are connected to their corresponding cable as
shown in the instruction sheet.
• Be sure nothing is blocking movement or caught in moving parts.
• Ensure that the floor or surface that the item sits on is flat and level.
• Ensure that the volume is not all the way down.
• Be sure nothing is blocking the sensor.
B
C
I
J
O P Q
E
B
1.2
USA Item 1010830997
Model 24SV24279
D
E
F
K
L
R S
F
D
E
B
B
2 1
.
G
M
D
F
2.2
1/3
