- Page 1 TDS20065 (CoolMasterNet) Universal HVAC Master on LAN Quick Installation Guide Version 3.8...
-
Page 2: Warning
Warning Read these Safety Precautions carefully to ensure correct installation. This manual classifies precautions into WARNING and CAUTION. Failure to follow WARNING is very likely to result in such grave consequences as death or serious injury WARNING Only qualified personnel must carry out the installation work. •... -
Page 3: Caution
Caution Failure to follow CAUTION may result in serious injury or property damage, and in certain circumstances, may result in a grave onsequence. CAUTION Do not allow children to play with the TDS20065 and supervise them not to get access to the appliance. •... - Page 4 Caution Failure to follow CAUTION may result in serious injury or property damage, and in certain circumstances, may result in a grave consequence. DO NOT INSTALL THE COOLMASTERNET IN THE FOLLOWING LOCATIONS: Where a mineral oil mist or oil spray or vapor is produced, for example, in a kitchen. Plastic parts may deteriorate and fall off or result in water leakage.
-
Page 5: Table Of Contents
Contents Warning HVAC Gree/GMV4 VRF (Lennox, Tica, Innovair) HVAC Midea VRF Caution (Intensity, Trane, Carrier, Lennox, Comfort Star, Kentatsu, Electra ,Voltas, Bryant, Maxxa, Contents Ecox, Clivet, Bosch ,SystemAir, Lessar, NED, Dantex, What's in the box Sanys) HVAC Samsung VRF CoolMasterNet (Trane) Preconfigured CoolMasterNet HVAC Chigo VRF... -
Page 6: What's In The Box
What’s in the box AC Power supply adapter TDS20065 Universal HVAC Master on LAN Interface 100V-240V 50/60hz to 12V TDS15200 1 USB-Mini USB 1 Ethernet Airco interface license cable cable... -
Page 7: Coolmasternet
TDS20065 Universele HVAC Master op LAN... -
Page 8: Preconfigured Coolmasternet
Preconfigured TDS20065 Type label with Configuration sticker Type label This label uniquely identifies the manufacturer’s configuration A preconfigured label example: configured for LG on L7 TDS20065. Located on the back of the enclosure. -
Page 9: Hvac Line Configuration
HVAC Line con iguration... -
Page 10: Hvac Daikin Vrv
HVAC Daikin VRV HVAC Communication Terminals HVAC outdoor connection * For Heat Recovery systems the connection is at oudoor units only. * Polarity is not required on the HVAC communication line. ** Centralized (group address required. Connecting to the line plug Secure the cables in the L1 line plug. -
Page 11: Hvac Daikin Non-Vrv
HVAC Daikin Non-VRV HVAC Communication Terminals HVAC Indoor connection * Polarity is not required on the HVAC communication line. ** Centralized (group) address required. If no 14-16V DC voltage Go to HVAC lines Go to DC Out turn on for TDS20065 (CoolMasterNet) and connect it to HVAC line. Daikin Non-VRV HVAC Terminal... -
Page 12: Hvac Mitsubishi Electric Vrf (Trane)
HVAC Mitsubishi Electric VRF HVAC Communication Terminals HVAC outdoor connection * For Heat Recovery systems the connection is at outdoor units only. * Polarity is not required on the HVAC communication line. Connecting to the line plug Secure the cables in the L1 line plug. Plugging to the CoolMasterNet Insert the plug in to the TDS20065 L1 socket. -
Page 13: Hvac Mitsubishi Electric Non-Vrf
HVAC Mitsubishi Electric Non-VRF HVAC Communication Terminals HVAC Indoor connection * Polarity is not required on the HVAC communication line. If no 28-30V DC voltage Go to HVAC lines Go to DC Out turn on for TDS20065 and connect it to HVAC line. Mitsubishi Non-VRF HVAC Terminal... -
Page 14: Hvac Panasonic/Sanyo Vrf
HVAC Panasonic/Sanyo VRF HVAC Communication Terminals HVAC outdoor connection * For Heat Recovery systems the connection is at outdoor units only. * Polarity is not required on the HVAC communication line. Connecting to the line plug Secure the cables in the L1 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L1 socket. -
Page 15: Hvac Toshiba Vrf (Carrier)
HVAC Toshiba VRF HVAC Communication Terminals HVAC outdoor connection * For Heat Recovery systems the connection is at outdoor units only. * Polarity is not required on the HVAC communication line. Connecting to the line plug Secure the cables in the L1 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L1 socket. -
Page 16: Hvac Hitachi Vrf (Hisense, York, Jci)
HVAC Hitachi VRF HVAC Communication Terminals HVAC outdoor connection * For Heat Recovery systems the connection is at outdoor units only. * Polarity is not required on the HVAC communication line. Connecting to the line plug Secure the cables in the L1 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L1 socket. -
Page 17: Hvac Haier Vrf (York, Trane, Ciac)
HVAC Haier VRF HVAC Communication Terminals HVAC outdoor connection * For Heat Recovery systems the connection is at outdoor units only. * Polarity is not required on the HVAC communication line. Connecting to the line plug Secure the cables in the L1 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L1 socket. -
Page 18: Hvac Mitsubishi Heavy Vrf
HVAC Mitsubishi Heavy VRF Mitsubishi Heavy HVAC Terminal HVAC Communication Terminals HVAC outdoor connection Connecting to the line plug Secure the cables in the L7 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L7 socket. Check DIP Switches are set correctly Dip switches setup for VRF HVAC system on L7. -
Page 19: Hvac Lg Vrf
HVAC LG VRF LG HVAC Terminal HVAC Communication Terminals HVAC outdoor connection Cent A Cent B Connecting to the line plug Secure the cables in the L7 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L7 socket. Check DIP Switches are set correctly Dip switches setup for VRF HVAC system on L7. -
Page 20: Hvac Aux Vrf (Rheem, Igc)
HVAC AUX VRF AUX HVAC Terminal HVAC Communication Terminals HVAC outdoor connection Connecting to the line plug Secure the cables in the L7 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L7 socket. Check DIP Switches are set correctly Dip switches setup for VRF HVAC system on L7. -
Page 21: Hvac Gree/Gmv4 Vrf
HVAC Gree/GMV4 VRF Gree HVAC Terminal HVAC Communication Terminals HVAC outdoor connection Connecting to the line plug Secure the cables in the L7 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L7 socket. Check DIP Switches are set correctly Dip switches setup for VRF HVAC system on L7. -
Page 22: Hvac Midea Vrf
HVAC Midea VRF Midea HVAC Terminal HVAC Communication Terminals HVAC outdoor connection Connecting to the line plug Secure the cables in the L7 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L7 socket. Check DIP Switches are set correctly Dip switches setup for VRF HVAC system on L7. -
Page 23: Hvac Samsung Vrf (Trane)
HVAC Samsung VRF Samsung HVAC Terminal HVAC Communication Terminals HVAC outdoor connection Connecting to the line plug Secure the cables in the L7 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L7 socket. Check DIP Switches are set correctly Dip switches setup for VRF HVAC system on L7. -
Page 24: Hvac Chigo Vrf (Rheem, Sharp)
HVAC Chigo VRF Chigo HVAC Terminal HVAC Communication Terminals HVAC outdoor connection Connecting to the line plug Secure the cables in the L7 line plug. Plugging to the TDS20065 Insert the plug in to the TDS20065 L7 socket. Check DIP Switches are set correctly Dip switches setup for VRF HVAC system on L7. -
Page 25: Hvac Blue Star Vrf
HVAC Blue Star VRF Blue Star HVAC Terminal HVAC Communication Terminals HVAC outdoor connection Connect DVRF Modbus Converter Secure the cables from Outdoor in RS485 Secure cables in Output 3 / Modbus to CoolMasterNet. DVRF MODBUS Converter RS485 ODU Plugging to the TDS20065 Output3/MODBUS Insert the plug in to the TDS20065 L7 socket. -
Page 26: Hvac Gree Gmv5, Gmv6 (Gree) Vrf
Connecting to the CMNET-GR-GMV5/6 USB Network Interface (CMNET-GR-GMV5/6) adapter is required for connecting up to two Gree GMV5/6 VRF lines. (Contact TELETASK specialist for more information) This adapter includes a CAN bus 120 Ω resistor. Plugging to the TDS20065 Insert the plug in to the TDS20065 L8 (USB). -
Page 27: Hvac Fujitsu Vrf (Rheem, Atlantic)
HVAC Fujitsu VRF HVAC Communication Terminals HVAC outdoor connection Connecting to the Echelon adapter Adapter is required for connecting to Fujitsu (General) VRF. (Order separately as item TDS20066) Connect Echelon via USB Extension cable Connect the USB Extension cable (A-Male to A-Female) to the adapter TDS20066 Plug in to the TDS20065 L8 Insert the USB cable in to the L8 USB host. -
Page 28: How To Change The Brand Of A Specific Line
How to change the brand of a specific line In order to change the HVAC brand type on a specific line, please follow the below procedure on TDS20065 screen: Configure the HVAC line type Go to Settings Go to HVAC Line Make sure the DIP switches are set properly for the brand (according to the details in the brand relevant section above) Select the HVAC Line you want to configure... -
Page 29: Coolmasternet Installation Complete
CoolMasterNet installation complete TDS20065 Unit screen After successful installation, unit’s screen will show all the detected indoor units and their statuses. Active HVAC line (DK 9/10) (Groups/Units) Inactive HVAC line All ON/OFF operation button Scrollbar Connected indoor unit with it’s address and Set-Point temperature indication. -
Page 30: Home Automation, Bms & Coolremote App
TELETASK Home Automation and TELETASK app... -
Page 31: Power Supply
Power Supply Option A Option B AC Power supply adapter Direct DC power supply (Included in the Box) -
Page 32: All On/Off Operation By External Signal
All On/Off operation by external signal All On All Off... -
Page 33: Mounting On Din Rail
Mounting on a DIN rail... -
Page 34: Mounting On A Wall
Mounting on a wall TDS20065... -
Page 35: Online Documentation And Support
Online Documentation and Support For complete installation guide go to TELETASK Professional: https://professional.teletask.be Or scan the QR code below https://professional.teletask.be/TDS20065+Universal+HVAC... -
Page 36: Need More Help
Need more help? Contact you local supplier https://teletask.be/en/contact/...
