HARTMANN TRESORE ZS 43 Operating Manual

Operating manual of the lock ZS 43
Battery insertion – 4 x LR03 AAA alkaline (included)
Keyboard and LCD display window
key C
key Start
1. First opening with the factory default code
Step 1 Press the C button.
Step 2 Enter the factory default code: 1 2 3 4 5 6.
Step 3 Press the # key. An acoustic signal and the display („OPEnd" message) confirm that the
correct code has been entered.
Step 4 During this signal, turn the handle clockwise and open the safe door.
ATTENTION: If the wrong code is entered, an error message will be displayed and there will be
a short warning signal.
If the wrong code is entered five times, the lock will stop working for five minutes, there will be
a warning signal and the display will show „dELAY".
2. Entering a new personal code
It is advisable to set and check the new code with the door open!
Step 1 Press the # key
Step 2 Enter the current code
Step 3 Press the # key
Step 4 Enter the new code (4 to 16 digits)
Step 5 Press the # key.
example:
If the current code is 123456 and a new 4-digit code 4242 is selected, press:
# 1 2 3 4 5 6 # 4 2 4 2 #
The message „EnTErd" appears and a 3-second beep confirms the code change to 4242.
key # battery position
under keyboard
Opening the battery compartment
upper lower
part part
1. Unscrew
keyboard
screw
2. Press the keypad opening catch to
release the retaining arm, and open the
keypad by sliding it up and to the left
