IWP Infrared Wireless Programmer
Quick Start Guide
Welcome to your new SensorSwitch
TLS Twist-to-Lock Sensors quickly and ensure you understand the programmer's features.
Get to Know the IWP Programmer
™
IWP Infrared Wireless Programmer! This guide will help you program your
Infrared Write and Read Ports (do not cover)
Backlit Digital Display
Menu (On / Off / Return Home)
Light Meter Aperture
Navigation (allows movement between screens)
Send (use to upload / download sensor behavior)
Available Setting Options for Maximum Brightness
Available Setting Options for Hold Time (minutes)
Quick Selection Options for Daylighting Setpoint
Number Pad
• Additional daylighting setpoint entry values 1-50 fc
• Used for 6-digit security PIN
• BLE mesh Group ID formation (TLS SSA only)
Red Protective Cover for Programmer
www.sensorswitch.com
Advertisement
Summary of Contents for Acuity Brands SensorSwitch IWP
- Page 1 IWP Infrared Wireless Programmer Quick Start Guide Welcome to your new SensorSwitch ™ IWP Infrared Wireless Programmer! This guide will help you program your TLS Twist-to-Lock Sensors quickly and ensure you understand the programmer’s features. Get to Know the IWP Programmer Infrared Write and Read Ports (do not cover) Backlit Digital Display Menu (On / Off / Return Home)
- Page 2 IWP Infrared Wireless Programmer Quick Start Guide How to Use Your Programmer • Select Menu to turn on the programmer • The Home Screen allows entry into key programmer functions • Use the Navigation Arrows to maneuver between screens • When final selections are made, aim the remote toward the sensor and press Send to upload or download the desired action When luminaires are installed, aim the remote toward the luminaire and press “send”...
- Page 3 • The recess area on the cover has molded rings. Position the sensor (in or out-of-the-box) close to this location while unpowered within 3 inches or direct contact of the device. Recess area with molded rings One Lithonia Way, Conyers, GA 30012 | Phone: 800.535.2465 | www.acuitybrands.com ©2024 Acuity Brands Lighting, Inc. All Rights Reserved. | SSI_2079151.12_1224...
