JA Solar PV Single-glass Modules Installation Manual
晶澳太阳能科技股份有限公司

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JAP60S01 SC/1000V Series and is the answer not in the manual?

Questions and answers

Summary of Contents for JA SOLAR JAP60S01 SC/1000V Series

  • Page 1 晶澳太阳能科技股份有限公司 JA Solar PV Single-glass Modules Installation Manual 晶澳太阳能科技股份有限公司...
  • Page 2: Table Of Contents

    CONTENTS 1 Introduction .............................. 2 2 Codes and Regulations ........................... 2 3 General ..............................2 3.1 Product Identification ........................3 Conventional Safety ........................3 Electrical Performance Safety ...................... 3 Operating Safety .......................... 5 Fire Safety ............................ 5 Installation Condition ........................... 6 4.1 Installation position and working environment ..................
  • Page 3: Introduction

    JA Solar Modules. This Manual also contains safety information you need to be familiar with. All the information described in this Manual is the intellectual property of JA Solar and is based on the technologies and experience that have been acquired and accumulated by JA Solar.
  • Page 4: Product Identification

    3.2 Conventional Safety JA Solar Modules are designed to meet the requirements of IEC 61215 and IEC 61730, application class A. Modules rated for use in this application class may be used in system operating at greater than 50V DC or 240W, where general contact access is anticipated.
  • Page 5 Q/JASO-PMO-012 A/22 JA Solar PV Single-glass Modules Installation Manual tools and electrically insulated gloves when working with Modules in sunlight. Modules have no on/off switch. Modules can be rendered inoperative only by removing them from sunlight, or by fully covering their front surface with cloth, cardboard, or other completely opaque material, or by working with Modules face down on a smooth, flat surface.
  • Page 6: Operating Safety

    3.4 Operating Safety Do not open the package of JA Solar Modules during transportation and storing until they are ready to be installed. At the same time please protect the package against exposure to damage. Secure pallets from falling over.
  • Page 7: Installation Condition

    4 Installation Condition 4.1 Installation position and working environment JA Solar Modules are intended for use in terrestrial applications only-no outer space use. Do not use mirrors or other magnifiers to concentrate sunlight onto the modules. Modules must be mounted on appropriate mounting structures positioned on suitable buildings, the ground, or other structures suitable for modules (e.g.
  • Page 8: Mechanical Installation

    Dust building up on the surface of the Modules can impair Module performance. JA solar recommends installing the Modules with a tilt angle of at least 10 degrees, making it easier for dust to be washed off by rain.
  • Page 9 JA Solar PV Single-glass Modules Installation Manual following examples and recommendation. If not mounting the Modules according to these instructions, please in advance consult JA Solar and must be approved by JA solar, otherwise may damage Modules and void the warranty.
  • Page 10 Q/JASO-PMO-012 A/22 JA Solar PV Single-glass Modules Installation Manual B) tighten the screws C) The Modules clamps must not contact the front glass or deform the frame in any way, the contact area of the clamp with the front of the frame must be smooth, otherwise may damage the frame or break the modules.
  • Page 11 Q/JASO-PMO-012 A/22 JA Solar PV Single-glass Modules Installation Manual Figure 3 Clamp Details (Units: mm) 5.2.3 Installation position and corresponding static loads The low/normal level of load condition is applicable to the installation in most of environmental conditions: the maximum static load on the back of the modules is (1600 Pa, 1.5) (i.e. wind load), and the maximum static load on the front of modules is (1600 Pa, 1.5) (i.e.
  • Page 12 JA Solar PV Single...
  • Page 13: Electrical Installation

    (The maximum system voltage of JA Solar Modules is DC 1000V/1500V according to the safety appraisal of the IEC61730) of the Modules and all other electrical DC components will not be exceeded in open-circuit operation at the lowest temperature expected at the PV system location.
  • Page 14 Use field wiring with suitable cross-sectional areas that are approved for use at the maximum short-circuit current of the Modules. JA Solar recommends installers use only sunlight resistant cables qualified for direct current (DC) wiring in PV systems. The minimum wire size should be 4mm (12AWG).
  • Page 15 6.4 Bypass Diodes The junction boxes used with JA Solar Modules contain bypass diodes wired in parallel with the PV cell strings. In the case of partial shading, the diodes bypass the current generated by the non-shaded cells, thereby limiting Modules heating and performance losses.
  • Page 16 Q/JASO-PMO-012 A/22 JA Solar PV Single-glass Modules Installation Manual 7.1 Grounding by using grounding bolt There is a grounding hole with 4.2 mm diameter on the edge side closer to the middle of the back frame of the Modules. The middle line of the grounding mark is overlapped with the grounding hole, and the direction is same as the longer frame.
  • Page 17: Operation And Maintenance

    Figure 7: Installation Methods 7.3 Additional Third-party Grounding Devices JA Solar Modules can be grounded using third party grounding devices so long as they are certified for grounding modules and the devices are installed according to the manufacturer’s specified instructions.
  • Page 18 Q/JASO-PMO-012 A/22 JA Solar PV Single-glass Modules Installation Manual material is damaged during the installation or transportation. C) If there is burning vestige on the backsheet 8.3 Inspection of the connector and the cable It’s recommended to implement the following preventive maintenance every 6 months: A) Check the encapsulation of the connector with the cable.
  • Page 19 Q/JASO-PMO-012 A/22 JA Solar PV Single-glass Modules Installation Manual JAM72S12-xxx/PR/1000V 365-385 1979x996x40 JAM72S17-xxx/PR/1000V 380-400 2015x996x40 JAM72S18-xxx/PR 385-405 1979x996x40 JAP60S09-xxx/SC/1000V 270-290 1657x996x35 JAP60S10-xxx/SC/1000V 275-295 1689x996x35 JAP72S09-xxx/SC/1000V 325-345 1979x996x40 JAP72S10-xxx/SC/1000V 330-350 2015x996x40 JAM72S13-xxx/PR 370-390 1979x996x40 JAM72S10-xxx/MR/1000V 400-420 2015x996x40 JAM72S17-xxx/MR/1000V 390-410 2015x996x40 JAM60S09-xxx/PR/1500V...
  • Page 20 Q/JASO-PMO-012 A/22 JA Solar PV Single-glass Modules Installation Manual...
