TCE22 - TROLLEY ASSEMBLY INSTRUCTIONS

CONTACT INFORMATION

Thermofilm Australia Pty Ltd

For spare parts order or service warranty and Natural

8 Lakeview Drive Scoresby

Gas Conversion queries call (03) 9562 3455 or email

Victoria 3179, Australia

Sales@crossray.com.au Your purchase receipt is

Telephone: (03) 9562 3455

required for all warranty claims.

Email: Sales@crossray.com.au

Retain manual for future reference.

DATE: 26.Feb.2025

Need help?

Do you have a question about the Crossray TCE22 and is the answer not in the manual?

Page 1 TCE22 - TROLLEY ASSEMBLY INSTRUCTIONS CONTACT INFORMATION Thermofilm Australia Pty Ltd For spare parts order or service warranty and Natural 8 Lakeview Drive Scoresby Gas Conversion queries call (03) 9562 3455 or email Victoria 3179, Australia Sales@crossray.com.au Your purchase receipt is Telephone: (03) 9562 3455 required for all warranty claims.
Page 2: Parts List
Parts list Trolley Side Left (1Pcs) Trolley Side Right (1Pcs) Bottom Panel (1Pcs) Door (1Pcs) Front Panel (1Pcs) Back Panel (1Pcs) Door Stop Plate Phillip Screws Part Thread Screws M6X55 Plastic (1Pcs) (1Pcs) M6X15 (10Pcs) (4Pcs) Spring Washer (2Pcs) Castor Wheels (2Pcs) Wrench (1Pcs)
Page 3 Attach door plate to screw inserts Add spring washer before installing castor wheels Note: When attaching the sides to the bottom panel, make sure door hole is located on the top.
Page 4 Use 4 screws to attach the panel. (1) Fit the front door panel in place. (2) The top front panel will slot into bracket on the top of the front door panel.
Page 5 Attach the top fixed fornt panel on each side with 4 screws Lift the Trolley up Side shelf unfold: a-b-c-d Note: The side shelves are already attached and can fold up or down.
Page 6 Remove the bottom bracket from the BBQ (If Applicable only) Note: These 4 small screws need to be reinstalled after the bottom bracket is removed. The BBQ is sold separately BBQ Leg Carefully slide the BBQ into position within the Trolley from the top, ensuring it is properly aligned.
