Navaio LIV60THC500FK Manual

Specification
Model
LIV60THC500FK
Image Sensor
1/2.5" 5MP CMOS sensor
Resolution 5MP
Signal System PAL / NTSC
Minimum Illumination 0.001Lux/F1.2
S/N Ratio More than 50dB
Synchronous System Internal
IR Distance 40 Meters
IR Power On Photodiode AUTO Control
CVBS / CVI / TVI / AHD
Video Output
Power DC12V(+/-10%) <12W
Lens 2.8-12mm Manual Zoom Lens
Weather Proof
IP66
Dimension (mm) 220(W) x 80(H) x 80(D)
Weight (g) 1400
Operating Conditions
-10~+50
Accessories list
Name
Camera
User Guide
RH95% MAX
Notes:
Number
Do not attempt to disassemble the camera. If the camera
1
can not work, please contact local franchiser or our company.
1
Varifocal Bullet Camera
Thank you for using our product.
Before providing power for the camera, please read
this manual carefully before use.
We adopt the latest technical of sensor and driver.
It owns the characters of high definition and stability,
strong anti-jamming, rich and real color. Fixing and
using this model are convenient too. It is very good
for you to apply to your CCTV system.
